- Page 1 Recorder & Encoder with HDMI & SDI input AV-REC200 www.avonic.eu User Manual | Version 1.0...
-
Page 2: Table Of Contents
Operating Instructions ....................6 1. Powering up and Initialization of the AV-REC200 ..........6 2.1 Operating the webinterface ................6 2.2 Live Service/ Streaming Setting. -
Page 3: Introduction
Contact For any questions or suggestions, contact your reseller or the local distributor of Avonic. Find the local distributor on the website of Avonic. For the most recent version of the manual or datasheet, look at the Avonic website: www.avonic.eu Join Avonic facebook.com/avonicPTZ... -
Page 4: Package Contents And Accessories
AV-PSU200 PRODUCT OVERVIEW The Avonic AV-REC200 is the ideal standalone USB/SD Card recorder and web streaming device. Users can simply connect an HDMI or SD/HD/3G-SDI input and in a few simple steps, they will be streaming and/ or recording. With support for UDP/HLS/RTMP/RTSP live output and USB/SD card recording the AV-REC200 enables corporate streaming, live streaming to various platforms and live high bitrate full HD 1080P60 re- cording. -
Page 5: Installation
Navigation buttons, for navigating through front panel display. Ok button Menu button Power and status indicator, changes color on basis of operational status of the REC-200. USB storage input for use with playback and/ or recording features Back to top www.avonic.eu... -
Page 6: Operating Instructions
Connect the supplied power transformer to the unit and wait until it is booted up. This process takes approxi- mately 35 seconds to 1 minute to complete. All of the features of the AV-REC200 can be accessed through the webinterface, in the now following part of this manual we will explain how to use it. -
Page 7: Live Service/ Streaming Setting
After logging in, you will be directed to the status page of the AV-REC200, with a live preview of the incoming video signal on top and information about the incoming signal, recording status and streaming status: Image 4 2.2 Live Service/ Streaming Setting... -
Page 8: Live Service / Streaming Setting Basic Options
Youtube in the example on the following page (image 7~10) and you click on ‘Start Streaming’ it can take one or two minutes before the little antenna symbol in the center of the screen turns green, indicating that the REC200 is live and streaming to the platform. Back to top www.avonic.eu... - Page 9 Image 7 authorization Image 8 authorization success Image 9 authorized and streaming Image 10 youtube dashboard Back to top www.avonic.eu...
-
Page 10: Live Service / Streaming Setting Advanced Options
Video Mode Constant Bitrate (CBR), Variable Bitrate (VBR). AUDIO: Audio Type MPEG1_Layer2 (MP2), AAC, AC3, EAC3 Audio Sampling Rate (KHz) Audio Bit Rate (kbps) 32, 48, 64, 80, 96, 112, 128, 160, 192, 224, 256, 320, 384 Back to top www.avonic.eu... - Page 11 Image 11 The last step on this page is to press Apply and after that the green Start streaming button to start broadcasting your stream. Back to top www.avonic.eu...
-
Page 12: Record Settings
Record Mode Loop, Size, Time Record Time/ Size Determine maximum recording Time or Size Loop enable/ disable loop recording when recording device is full Start recording click on green button Image 12 Back to top www.avonic.eu... -
Page 13: Playback Settings
‘add files’ button uppon which a window will be opened to select the files for the playlist. The way these files are played back is by using an identical set of settings as described under chapter 2.2.1. Image 13 Back to top www.avonic.eu... -
Page 14: Overlay Settings
2.2.5. Overlay Settings The Avonic REC-200 has the possibility to put a text and/or picture on its output as an overlay over the video output. After clicking on the menu Settings Overlay tab, the page looks like this: Image 14 Back to top www.avonic.eu... -
Page 15: How To Create Transparent Bmp File For Overlay
Select your imagefile in the layers windows holding the CTRL button Go to the channel window and save your selection as channel Uncheck the colors, leaving only the alpha channel selected Save the file as 32 bit Bitmap with alpha channel Back to top www.avonic.eu... -
Page 16: System Settings
The last page on the menu is the System Settings page, where you can find all the settings regar- ding licenses, network settings firmware upgrades etc. 1. Version information Image 15 2. License information Image 16 Back to top www.avonic.eu... - Page 17 3. Network Settings Image 17 4. System operation Upgrade, import or export license if available. Import or export a configuration file Image 18 Back to top www.avonic.eu...
- Page 18 5. Other Operation Reboot, Restore Factory Settings, Export logfile and Clear all logs. Image 19 Back to top www.avonic.eu...
-
Page 19: Maintenance
- Check the power supply WebGUI • Cannot enter WebGUI - Check network cable - Check if PC is in the same subnet as the recorder • Firmware update failed - Check firmware file integrity, download it again. Back to top www.avonic.eu... -
Page 20: Api Data
InputSrc Select HDMI or SDI as input source, and display input source status Syntax InputSrc X Parameter Description Range Value ON, OFF, sta Example Feedback InputSrc sta InputSrc HDMI AudioSw Enable/disable audio, and display audio status Syntax AudioSw X Parameter Description Range Value ON, OFF, sta Example Feedback AudioSw ON AudioSw ON Back to top www.avonic.eu... - Page 21 Feedback StreamSw ON StreamSw ON OverlayPicSw Enable/disable picture overlay, and display picture overlay status Syntax OverlayPicSw X Y Parameter Description Range Value ON, OFF, sta Select which picture 1~20 Example Feedback OverlayPicSw ON 2 OverlayPicSw ON 2 Back to top www.avonic.eu...
- Page 22 Set the content of overlay text and display content of overlay text Syntax OverlayTxt X Parameter Description Range Text content String (<30Bytes), sta Example Feedback OverlayTxt Avonic OverlayTxt Avonic Network Display status of network Syntax Network X Parameter Description Range Status...
