Summary of Contents for CB Tech WATER GUARDIAN MPADC
-
Page 3: Table Of Contents
Index About the Water Guardian Water Guardian Features Before You Begin Water Guardian Drinking Water System Specifications Inspect Your Drinking Water System Connect The Hose To The Housing Connect The Hose And Diverter Valve To The Faucet Prepare Your System For Use Operation Maintenance •... -
Page 4: About The Water Guardian
About The Water Guardian Drinking Water System • The CB Tech Water Guardian Drinking Water System (Model# MPADC) is designed for use on the countertop next to the sink. It connects to the existing faucet with a diverter valve that allows free selection between filtered and unfiltered water. -
Page 5: Before You Begin
Before You Begin CB Tech Drinking Water Systems (DWS) have been extensively tested and certified by NSF International to provide the highest level of assurance that the device will perform as claimed. Please read this manual before proceeding with the installation and use of your system. Installation, operation, and maintenance requirements are essential to the performance of your system –... -
Page 6: Water Guardian Drinking Water System
Water Guardian Drinking Water System Housing Top (MCL-AD) Filter Cartridge (CBTAD) Black Gasket (MC357) Housing Bottom (MCB-AD) Hose and Diverter Valve (MC6400) Hand Tool (MC008) Specifications Model Name: Water Guardian (MPADC) Approximate Filter Capacity: 750 Gallons Replacement Filter Type: CBTAD Approximate Flow Rate: 0.75 gpm @60 psi House Composition:... -
Page 7: Inspect Your Drinking Water System
Installation Inspect Your Drinking Water System Inspect your DWS to confirm that it has been received in good condition and that all parts are included. Determine a countertop location for system placement, factoring in distance to the faucet for diverter valve and hose connection. Inspect the system housing to confirm that the housing top and bottom are securely connected. - Page 8 Attach the diverter valve directly to the faucet existing faucet spout. If the threads of the diverter valve do not match the threads of the faucet, use one of the swivel attachment included faucet adapters to connect the diverter bypass ring lever valve and faucet.
-
Page 9: Prepare Your System For Use
faucet, please contact your Dealer to request either part# MC109 or part# MC719 as possible adapter solutions. NOTE: When connected properly, the hose from the diverter valve should lead toward the back of the faucet and sink. The diverter valve features a bypass lever with a button on the left and right sides of the diverter valve. -
Page 10: Operation
Press the left button to select the unfiltered water spout, and then turn off the faucet. Check all connections to make sure that there are no leaks. Congratulations! Your system is now ready for use! Operation For unfiltered water, press the left button on the diverter valve. Water from the faucet will emerge from the unfiltered water spout. -
Page 11: Removing The Old Filter Cartridge
Removing The Old Filter Cartridge Before opening the DWS housing, place a pan or basin beneath the housing. With the faucet off, press the right button on the diverter valve to select the filtered water spout and flush water out of the DWS. When the flow of water stops, press the left button on the diverter valve to stop the filtered water spout. -
Page 12: Flushing / Disinfecting The System
Flushing / Disinfecting The System CB Tech recommends that you not allow water to sit in the system for extended periods of time without use. If a system is left unused for more than 10 days, it may need to be flushed / disinfected before resuming normal use. -
Page 13: Warranty
CB Tech. The remedy of repair or replacement as provided under this limited warranty is exclusive. In no event shall CB Tech be liable for any consequential or incidental damages to any person whether occasioned by negligence of the manufacturer, including without limitation damages of loss of use, cost of substitution, property damage, or other monetary loss. -
Page 14: Contaminant Reduction Performance
Contaminant Reduction Performance The Water Guardian is NSF-certified to reduce a broad array of contaminants of aesthetic and health concern. The following are contaminants treated by the Water Guardian. NSF/ANSI 42 - Aesthetic Effects Maximum permissible Percent Influent challenge concentration Substance product water concentration Reduction**... - Page 15 Maximum permissible Percent Influent challenge concentration Substance product water concentration Reduction** (mg/L unless specified) (mg/L unless specified) DINOSEB* 0.170 0.0002 EDB (see ETHYLENE DIBROMIDE)* >99% 0.044 0.00002 ENDRIN* 0.053 0.00059 99.95% reduction Entamoeba (see CYSTS) 99.95% minimum 50,000/L requirement ETHYLBENZENE* >99% 0.088 0.001...
-
Page 16: Standard 401 Incidental Contaminants
The CB Tech Drinking Water Systems have been certified by the State of California Department of Public Health for the reduction of specific contaminants listed herein. Chloroform was used as a surrogate for claims of reduction of VOCs. CB Tech Systems tested at >99.8% actual reduction of Chloroform. Percent reduction shown herein reflects the allowable claims for VOCs as per tables in the Standard. -
Page 17: Troubleshooting
Troubleshooting Water flow is frequently interrupted by air Purge any residual air from the system: Turn the system housing upside down. Turn on the filtered water faucet. Allow water to flow for one minute. Turn off the filtered water faucet. Odor –... - Page 18 When the water flow rate slows to the point of inconvenience, or at one year of use, it is time to replace the filter cartridge. If other water sources are on while using the DWS, turn them off to check if they are affecting the flow rate. Taste/Odor –...
-
Page 19: Frequently Asked Questions
Hand pump kits and emergency kits are available from CB Tech. What causes white particles to appear in CB Tech water when it is frozen or boiled? Because the Water Guardian does not reduce any natural minerals present in water, these minerals may solidify when the water is frozen and appear as white flakes or specks when the water is melted or boiled. - Page 20 Soft water is often desirable for bathing and laundering purposes, and may extend the life of hot water heaters and boilers. However, soft water is not recommended for use on plants or lawns. CB Tech recommends that you bypass a water softener when installing your CB Tech Drinking Water System.
- Page 21 Notes...
-
Page 22: Water Guardian Accessories
Water Guardian Accessories Water Guardian Replacement Filter (CBTAD) The Water Guardian replacement filter utilizes Solid Carbon Block technology for optimal performance, and is certified to treat aesthetic contaminants, health contaminants and emerging compounds. Water Guardian Hand Tool (MC008) Hand tool used to open Water Guardian Water Guardian Hose/Diverter Valve (MC6400) This hose and diverter valve connects your Drinking Water System directly to your existing faucet. - Page 24 7251 Cathedral Rock Drive, Las Vegas, NV 89128 866.622.9373 • www.CarbonBlockTech.com 0919...
