Summary of Contents for CB Tech CB-VOC

  • Page 3: Table Of Contents

    Index About the CB-VOC CB-VOC Features Before You Begin CB-VOC Drinking Water System Specifications Inspect Your Drinking Water System Install Your System Prepare Your System For Use Maintenance • Regarding Filter Capacity • Removing The Old Filter Cartridge • Installing The New Filter Cartridge...
  • Page 4: About The Cb-Voc

    CB-VOC User Guide About the CB-VOC Drinking Water System • The CB Tech CB-VOC Drinking Water System (CBVOC) is designed for use on the countertop next to the sink, below the sink, or inline with other devices. • The CB-VOC is third-party tested and verified by NSF under NSF/...
  • Page 5: Before You Begin

    Before You Begin CB Tech’s Drinking Water Systems (DWS) have been extensively tested and certified by NSF International to provide the highest level of assurance that the device will perform as claimed. Please read this manual before proceeding with the installation and use of your system. Installation, operation, and maintenance requirements are essential to the performance of your system –...
  • Page 6: Cb-Voc Drinking Water System

    CB-VOC Drinking Water System Outlet Inlet Housing Top V-Band V-Band Knob Housing Bottom Specifications Model Name: CB-VOC (CBVOC) Approximate Filter Capacity: 750 Gallons Replacement Filter Type: CBTVOC Approximate Flow Rate: 0.75 gpm @60 psi Pressure Vessel Composition: Stainless Steel Rubber Items:...
  • Page 7: Inspect Your Drinking Water System

    Install Your System The CB-VOC can be installed below the sink or on top of the countertop next to the sink. Please refer to the Installation Guide included with your Install Kit for step-by-step instructions.
  • Page 8: Maintenance

    With the CB-VOC housing in an upright position, unscrew the black knob on the Locking V-Band by turning it counter-clockwise. With the black knob removed, spread the Locking V-Band apart and let it drop off the bottom of the CB-VOC. Carefully set it aside.
  • Page 9: Installing The New Filter Cartridge

    Rinse out the inside of the system housing, hand washing if necessary. Inspect the black rubber cushion on the inside of the top half of the housing, making sure that it is not cracked or worn; CB Tech recommends that the cushion be replaced every two to three years.
  • Page 10: Flushing / Disinfecting The System

    CB Tech. The remedy of repair or replacement as provided under this limited warranty is exclusive. In no event shall CB Tech be liable for any consequential or incidental damages to any person whether occasioned by negligence of the manufacturer, including without limitation damages of loss of use, cost of substitution, property damage, or other monetary loss.
  • Page 11: Contaminant Reduction Performance

    Contaminant Reduction Performance The CB-VOC is NSF-certified to reduce a broad array of contaminants of aesthetic and health concern. The following are contaminants treated by the CB-VOC. NSF/ANSI 42 - Aesthetic Effects Maximum permissible Percent Influent challenge concentration Substance product water concentration...
  • Page 12 Maximum permissible Percent Influent challenge concentration Substance product water concentration Reduction** (mg/L unless specified) (mg/L unless specified) DINOSEB* 0.170 0.0002 EDB (see ETHYLENE DIBROMIDE)* >99% 0.044 0.00002 ENDRIN* 0.053 0.00059 99.95% reduction Entamoeba (see CYSTS) 99.95% minimum 50,000/L requirement ETHYLBENZENE* >99% 0.088 0.001...
  • Page 13: Standard 401 Incidental Contaminants

    VOCs reflects the allowable claims for Volatile Organic Chemicals/Compounds as per Tables. Chloroform was used as a surrogate for VOC reduction claims: the CB Tech Systems’ actual reduction rate of Chloroform was >99.8% as tested (at 200% of capacity). ***NSF Standard 401 has been deemed as “incidental contaminants / emerging compounds”.
  • Page 14: Troubleshooting

    Water flow is frequently interrupted by air Purge any residual air from the system: Turn the system housing upside down. Turn on the filtered water faucet (either through the CB-VOC faucet or the diverter valve). Allow water to flow for one minute.
  • Page 15: Frequently Asked Questions

    Does deionized water or soft water have an effect on CB Tech water? No. Because CB Tech filters do not treat the natural minerals dissolved in water, the hardness or softness of water has no effect on the resultant filtered CB Tech water.
  • Page 16 What causes white particles to appear in CB Tech water when it is frozen or boiled? Because the CB-VOC does not reduce any natural minerals present in water, these minerals may solidify when the water is frozen and appear as white flakes or specks when the water is melted or boiled.
  • Page 17: Cb-Voc Accessories

    The system connects to the cold water line with an included Adapta Valve, and the faucet requires a 0.5” hole available in the countertop or sink for installation. A below-sink CB-VOC can be removed and converted for countertop use with additional parts. Countertop Kit This installation kit includes a dual-hose diverter valve to connect to the sink faucet, providing push-button selection of either filtered or unfiltered water.
  • Page 18 Notes...
  • Page 20 7251 Cathedral Rock Drive, Las Vegas, NV 89128 866.622.9373 • www.CarbonBlockTech.com 600-60-6043/1116...
