IMPORTANT
FOR FUTURE REFERENCE
Please complete this information
and retain this manual for the lie
of the equipment.
MODEL #
SERIAL #
DATE PURCHASED
OPERATOR'S MANUAL
INSTALLATION
OPERATION AND MAINTENANCE INSTRUCTIONS
w
COUNTERTOP
CONVECTION STEAMER
MODEL:
R2
AWARNING
improper installation, service, or maintenance can cause property damage,
injury or death. Read the installation, operation and maintenance instructions
thoroughly before installing and operating this equipment.
"Our Goal-First
Time Fix"
1100 Old Honeycult
Road
l
Fuquay-Varina,
NC 27526
(919) 562-9161
l
(800) 348-2568
FAX (800) 91@9915.
FAX (919) 552-8682
$18.00
COUNTERTOP CONVECTION STEAMER
(MANUAL SECTION R2)
