- Page 1 FCVC8-R INTELLIGENT MULTIFUNCTIONAL FLUSH MOUNTED SENSOR Mounting and operating instructions...
-
Page 2: Table Of Contents
INTENDED AREA OF USE TECHNICAL DATA STANDARDS OPERATIONAL DIAGRAMS WIRING AND CONNECTIONS MOUNTING INSTRUCTIONS IN STEPS OPERATING INSTRUCTIONS VERIFICATION OF INSTALLATION INSTRUCTIONS MODBUS REGISTER MAPS TRANSPORT AND STORAGE WARRANTY AND RESTRICTIONS MAINTENANCE MIW-FCVC8-R-EN-000 - 28 / 08 / 2019 2 - 12 www.sentera.eu... -
Page 3: Safety And Precautions
In case there are any questions that are not answered, please contact your technical support or consult a professional. MIW-FCVC8-R-EN-000 - 28 / 08 / 2019 3 - 12 www.sentera.eu... -
Page 4: Product Description
FCVC8-R INTELLIGENT MULTIFUNCTIONAL FLUSH MOUNTED SENSOR PRODUCT DESCRIPTION The FCVC8-R series are intelligent sensors featuring adjustable temperature, relative humidity and T VOC / CO eq ranges. Based on this T VOC measurement, an equivalent CO level (CO eq) is calculated. The T VOC concentration is an accurate indicator for indoor air quality. -
Page 5: Operational Diagrams
Modbus RTU (RS485), signal A Modbus RTU (RS485), signal /B Spring contact terminal block, cable cross section: 2,5 mm Connections pitch 5 mm; shielded cable MIW-FCVC8-R-EN-000 - 28 / 08 / 2019 5 - 12 www.sentera.eu back to the table of contents... -
Page 6: Mounting Instructions In Steps
Sensistant configurator. For the default factory settings, see Modbus register maps below. For surface mounting Disconnect the power supply. Remove the frame cover of the enclosure. Take out the internal enclosure. MIW-FCVC8-R-EN-000 - 28 / 08 / 2019 6 - 12 www.sentera.eu back to the table of contents... - Page 7 On a Modbus RTU network, two bus terminators (NBTs) need to be activated. NO T E Mount the unit so that the terminal block and connections are at the lower side. MIW-FCVC8-R-EN-000 - 28 / 08 / 2019 7 - 12 www.sentera.eu...
-
Page 8: Operating Instructions
Blinking red LED indicates loss of communication with a sensor (Fig. 7 - 3). MIW-FCVC8-R-EN-000 - 28 / 08 / 2019 8 - 12 www.sentera.eu back to the table of contents... -
Page 9: Verification Of Installation Instructions
Humidity sensor state unsigned int 0—1 humidity sensor is lost 1 = Fault Dew point level signed int Calculated dew point -700—700 200 = 20,0°C MIW-FCVC8-R-EN-000 - 28 / 08 / 2019 9 - 12 www.sentera.eu back to the table of contents... - Page 10 500 5°C Min. temperature range — Minimum temperature alert unsigned int Minimum temperature alarm value Max. temperature alarm 500 = 50,0°C default: 0 MIW-FCVC8-R-EN-000 - 28 / 08 / 2019 10 - 12 www.sentera.eu back to the table of contents...
- Page 11 LED intensity (incrementing with step of 10 %) default: 5 5 = 50 % 10 = 100 % For more information about Modbus over serial line, please visit: http://www.modbus.org/docs/Modbus_over_serial_line_V1_02.pdf MIW-FCVC8-R-EN-000 - 28 / 08 / 2019 11 - 12 www.sentera.eu back to the table of contents...
-
Page 12: Transport And Storage
In case of heavy pollution, clean with a non-aggressive product. In these circumstances the unit should be disconnected from the supply. Pay attention that no fluids enter the unit. Only reconnect it to the supply when it is completely dry. MIW-FCVC8-R-EN-000 - 28 / 08 / 2019 12 - 12 www.sentera.eu...
