® ZMOTION Intrusion Detection Development Kit User Manual DO NOT USE IN LIFE SUPPORT SYSTEMS. Warning: LIFE SUPPORT POLICY ZILOG’S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE EXPRESS PRIOR WRITTEN APPROVAL OF THE PRESIDENT AND GENERAL COUNSEL OF ZILOG CORPORATION.
® ZMOTION Intrusion Detection Development Kit User Manual Revision History Each instance in the table below reflects a change to this document from its previous edi- tion. For more details, refer to the corresponding pages and appropriate links in the table below.
® ZMOTION Intrusion Detection Development Kit User Manual Introduction ® Zilog’s ZMOTION Intrusion Detection Development Kit provides a general-purpose platform for evaluating the capabilities and operation of the ZMOTION Intrusion Detec- tion MCU, which features Zilog’s passive infrared (PIR) technology. The ZMOTION Family of Motion Detection products includes a series of high-performance microcon- trollers with integrated motion detection algorithms.
® ZMOTION Intrusion Detection Development Kit User Manual • Mounting hardware The contents of the kit are shown in Figure 1. Figure 1. ZMOTION Intrusion Detection Development Kit Contents Supported Operating Systems The ZMOTION Intrusion Detection Development Board supports the following operating systems: •...
® ZMOTION Intrusion Detection Development Kit User Manual Safeguards The following precaution must be observed when working with the devices described in this document. Always use a grounding strap to prevent damage resulting from electrostatic discharge Caution: (ESD). Download and Install the ZDSII Software and Documentation Prior to connecting the ZMOTION Development Board to your PC, observe the following procedure.
Page 8
® ZMOTION Intrusion Detection Development Kit User Manual 3. When the installation is complete, the ZMOTION documentation will be located in the following path, by default: C:\Program Files\Zilog\ZMOTIONS200ZCOG_<version>\ ZMOTION Product Documentation UM023302-1214...
® ZMOTION Intrusion Detection Development Kit User Manual ZMOTION Intrusion Detection Development Board Zilog’s ZMOTION Intrusion Detection Development Board is a development and proto- typing platform for the ZMOTION Intrusion Detection silicon and software as well as for lens/pyroelectric sensor/silicon and software bundled solutions. The Board provides the user with a tool to evaluate the many features of ZMOTION PIR technology, as well as the actual performance of each lens and pyro combination.
® ZMOTION Intrusion Detection Development Kit User Manual The upper set of holes on the board is used to attach the 1.2" lens holders (see Figure 2). Note: • Prototyping area • 2.7 V–3.6 V operating voltage with 5 V tolerant inputs MCU Features The Z8FS021 ZMOTION Intrusion Detection MCU combines the programmability and rich peripheral set of Zilog’s Flash Z8 Encore! XP Family of MCUs with built-in motion...
® ZMOTION Intrusion Detection Development Kit User Manual • Extended detection modes for occupancy sensing • Low power modes • White light detection and pet immunity ZMOTION Intrusion Detection Development Kit Lens and Pyroelectric Sensor The ZMOTION Intrusion Detection Development Kit includes three different types of lenses to fill a wide variety of intrusion detection and security applications.
Page 12
® ZMOTION Intrusion Detection Development Kit User Manual ZMOTION_Intrusion_Demo project demonstrates the basic motion detection func- ZMOTION_Intrusion_Demo tionality of the ZMOTION Development Board. The MCU included with the Board is programmed with this project. Each lens type is supported by an associated lens configuration header file which displays a name format of .
® ZMOTION Intrusion Detection Development Kit User Manual In the above output, when power is applied to the Board, it sends a title message and the software version, then waits for the pyroelectric sensor to stabilize, which can take between 10 and 60 seconds. A ‘.’ symbol is transmitted every second while it waits for sta- bility.
® ZMOTION Intrusion Detection Development Kit User Manual Installing the FTDI USB to Serial Driver Observe the following steps to install the FTDI USB to Serial Driver. 1. Make sure that the USB cable is not plugged into the ZMOTION Development Board. 2.
Page 15
® ZMOTION Intrusion Detection Development Kit User Manual open grey area below the menu icons and select to turn on the tabs at Workbook Mode the bottom of the editor and therefore make it easier to switch between files. 3. Click the icon to build the project.
Page 16
® ZMOTION Intrusion Detection Development Kit User Manual The Reset icon The Go icon Figure 6. The Location of the Rest and Go Icons 6. An information notice may appear, indicating that the silicon is not the latest version. This occurrence is normal and is not an issue. Click to continue.
® ZMOTION Intrusion Detection Development Kit User Manual Making Changes to the ZMOTION_Intrusion_Demo Project To change the duration of the LED on time, observe the following procedure. 1. Change the following line in the file: main.c unsigned int cMDDelayTime = DELAY_1SEC; // LED ON time...
Page 18
® ZMOTION Intrusion Detection Development Kit User Manual Appendix A. Board Design Information Figure 8 displays the schematics for the ZMOTION Development Board. VCC_5v VCC_3v3 Vout FERRITE BEAD FERRITE BEAD 4.7uF 4.7uF 0.1uF 0.1uF 4.75K 4.75K 4.7uF 4.7uF 0.1uF 0.1uF NCP582LXV33T2G NCP582LXV33T2G VBUS...
Page 20
® ZMOTION Intrusion Detection Development Kit User Manual Figures 10 and 11 display top- and bottom-view mechanical drawings, respectively, of the ZMOTION Development Board. Figure 10. ZMOTION Development Board Mechanical Diagram, Top View UM023302-1214...
Page 21
® ZMOTION Intrusion Detection Development Kit User Manual Figure 11. ZMOTION Development Board Mechanical Diagram, Bottom View UM023302-1214...
® ZMOTION Intrusion Detection Development Kit User Manual Appendix B. Installing the USB SmartCable Driver The USB SmartCable can be installed on PCs that run on Windows 7 (32- and 64-bit), Windows Vista (32- and 64-bit) and Windows XP operating systems. The procedures in this section will guide you through the USB SmartCable installation process.
® ZMOTION Intrusion Detection Development Kit User Manual Windows Vista 32/64 Systems Observe the following steps to install the USB SmartCable on a Windows Vista system. 1. Connect the USB SmartCable to a USB port on the development PC. 2. After the PC detects the new hardware, it will display the Found New Hardware Wiz- ard dialog box.
Page 24
® ZMOTION Intrusion Detection Development Kit User Manual <ZDS II Installation>\device drivers\USB\x32ƒn <ZDS II Installation CD>\Device Drivers\USB\x32 5. Click Next to locate the appropriate driver. 6. Click Next a second time, then click Finish to complete the installation. UM023302-1214...
® ZMOTION Intrusion Detection Development Kit User Manual Customer Support To share comments, get your technical questions answered, or report issues you may be experiencing with our products, please visit Zilog’s Technical Support page at http://sup- port.zilog.com. To learn more about this product, find additional documentation, or to discover other fac- ets about Zilog product offerings, please visit the Zilog Knowledge Base at http:// zilog.com/kb...
