- Page 1 User Guide E13C2 Transducer 16-01484-EN-01 For Professional Users Only June 2018...
- Page 2 Input from our customers helps us improve our products and services. Your opinions are important to us. You are always welcome to contact us via your BK Medical representative or by contacting us directly. E13C2 = Ref. Type 9029 © 2018 BK Medical Information in this document may be subject to change without notice.
-
Page 3: Table Of Contents
Contents Introduction ............5 Intended use . -
Page 5: Introduction
Introduction This is the user guide for E13C2 and must be used together with the Care and Cleaning user guide which contains important safety information. Caution Rx-c1 United States Federal law restricts this device to sale by or on the order of a physician. -
Page 6: Service And Repair
Complete details and procedures can be found in Care and Cleaning that accompanies this user guide. A list of reprocessing methods that the transducer can withstand are listed in the Product Data Sheet. Sterile covers are available. See the Product Data Sheet for more information. June 2018 E13C2 User Guide (16-01484-EN-01) -
Page 7: Starting Imaging
Connecting the Transducer WARNING GS-w4a It is essential for the patient’s safety that only the correct equipment is used. Do not use other manufacturers’ transducers with BK ultrasound systems. • Do not use BK transducers with other manufacturers’ systems. •... -
Page 8: Using The Transducer Control Button
The transducer makes a “beep” sound each time you press the button. Changing Orientation To change the orientation of the image on the monitor, refer to the applicable system user guide for instructions. June 2018 E13C2 User Guide (16-01484-EN-01) -
Page 9: Puncture And Biopsy Facilities
The needle guide is angled 0° towards the long axis of the transducer (i.e. towards the mid-axis of the scan image with E13C2). The distance from the entrance to the needle guide and the first puncture line dot on the scan image is 166 mm, as shown in Fig. -
Page 10: Performing Puncture And Biopsy
In case of any inconsistency, stop imaging, turn off the system, and contact your BK service representative. June 2018 E13C2 User Guide (16-01484-EN-01) - Page 11 Avoid unnecessary tissue damage. When performing a biopsy, always make sure that the needle is fully drawn back inside the needle guide before moving the transducer. Figure 4. Illustration of the puncture line for needle guides UA1339 and UA1349. E13C2 User Guide (16-01484-EN-01)
-
Page 12: Cleaning After Puncture And Biopsy
WARNING D-w1 For disposal of contaminated items such as transducer covers or needle guides or other disposable items, follow disposal control policies established for your office, department, or hospital. June 2018 E13C2 User Guide (16-01484-EN-01)
