1 Introduction

The APCI-8001 / APCI-8008 control units can be optionally fitted with a CanBus interface. The CAN
bus is connected at connector P2. RWMOS.ELF operating system software which contains the
"optionMSM9255" option must also be used. The APCI-8001 / APCI-8008 can only act as a master
and does not have an object directory itself.

2 Functions of the CanBus option

2.1 Initialisation

Access to the CAN function is via the "universal object interface" of the APCI-8001 / APCI-8008.
The following values for the universal object interface must be applied when using the CanBus
interface.
Table 1: Object descriptor elements
Object descriptor
element
Handle
BusNumber
DeviceNumber
Index
SubIndex
Further information on the object descriptor elements can be found in the document
"Universal Object Interface".
Value
Must be initialised with 0 when starting the application or
after rebooting the control unit and is then managed/used
by the system.
For PCAP programming: After the resource functionality
is cleaned, the handles for all elements must be reset to
zero.
400
8000 0000 hex index/subindex according to Table 2
or DeviceNumber according to Table 3
Parameters of the respective function according to
Table 2 or 3.
Parameters of the respective function according to
Table 2 or 3.
Unless otherwise specified = 0
