ITEM MDFY. INPUT DATA
19 P Numeric (%)
20 P Numeric (%)
Modification Code
D : No modification (writing) possible. Used only for monitoring (reading).
S : Modifiable at any time.
P : Modifiable only when the MAINTENANCE SWITCH is in the 'PRG' mode.
ROM Version Indication
[GROUP 00] [ITEM 99]
CHECKING
1) Terminal wiring: Check that all cables are correctly con-
nected according to the connection diagram.
2) Power input voltage: Check voltage across the terminal
7 – 8 with a multimeter.
3) Check input signal.
4) Sensor excitation: Check that the load for the sensor ex-
citation is within the permissible limit.
5) Output: Check that the load resistance meets the de-
scribed specifications.

LIGHTNING SURGE PROTECTION

M-System offers a series of lightning surge protectors for
protection against induced lightning surges. Please contact
M-System to choose appropriate models.
DISPLAY DEFAULT CONTENTS
FINZER XXX.XX
OUTPER XXX.XX
FINSPN XXX.XX
OUTPER XXX.XX
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
0.00 Fine zero adjustment
Indicates the output in % when data is input.
100.00 Fine span adjustment
Indicates the output in % when data is input.
JFR2
