Software Setting - M-system JFR2 Instruction Manual

SOFTWARE SETTING

Please refer to the Operation Manual for Model PU-2x (EM-9255), Section B: (B-1) INTRODUCTION, (B-2) GENERAL OP-
ERATION DESCRIPTION, (B-3) OPERATION FLOW CHART for general information.
[GROUP 01]
ITEM MDFY. INPUT DATA
01 S
0
1
02 P Alphanumeric
03 P Numeric (%)
05 D No input
06 D No input
07 D No input
11 P
0
1
2
3
4
5
6
7
12 P Numeric
13 P
0
1
2
7
14 P Numeric
15 P Numeric
18 P Numeric
DISPLAY DEFAULT CONTENTS
MTSW: MON.MODE
MTSW: PRG.MODE
TG: XXXXXXXXXX
OUTPER XXX.XX
INPPER XXX.XX
INPFRQ XXX.XX
SW: IN_V 1/20
SW: IN_V 1/10
SW: IN_V 1/5
SW: IN_V 1/2
SW: IN_V 1/1
SW: IN_V 5/1
SW: IN_V 10/1
SW: IN_OC, mA
SW: no use
SW: no use
SW: IN_RS-422
INRNG: 10 mHz
INRNG: 100 mHz
INRNG: 1.0 Hz
INRNG: 10 Hz
INRNG: 100 Hz
INRNG: 1.0 kHz
INRNG: 10 kHz
INRNG: 100 kHz
INSPN XXXXXX
OUTRNG: 1 mHz
OUTRNG: 10 mHz
OUTRNG: 100 Hz
OUTRNG: 1.0 Hz
OUTRNG: 10 Hz
OUTRNG: 100 Hz
OUTRNG: 1.0 kHz
OUTRNG: 10 kHz
OUTSPN XXXXXX
(20.00)*
DRPOUT XXXXXX
SMPL RATE XXX
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
N/A MAINTENANCE SWITCH
0: Data indication only.
1: All 'P' marked parameters are modifiable.
N/A Tag name entry (10 characters max.)
N/A Output in % and simulated output
N/A Input in %
N/A Input frequency (unit as in ITEM 11)
N/A Input specification selected with the front rotary switch
SW = 0, Voltage pulse, Sensitivity scale = 1/20
SW = 1, Voltage pulse, Sensitivity scale = 1/10
SW = 2, Voltage pulse, Sensitivity scale = 1/5
SW = 3, Voltage pulse, Sensitivity scale = 1/2
SW = 4, Voltage pulse, Sensitivity scale = 1/1
SW = 5, Voltage pulse, Sensitivity scale = 5/1
SW = 6, Voltage pulse, Sensitivity scale = 10/1
SW = 7, Open collector, mechanical contact or two-wire
current pulse
SW = 8, (not used)
SW = 9, (not used)
DIP switch set to RS-422 line driver pulse
5 Input frequency range
0 – 10 mHz
0 – 100 mHz
0 – 1.0 Hz
0 – 10 Hz
0 – 100 Hz
0 – 1.0 kHz
0 – 10 kHz
0 – 100 kHz
1.0000 Input span frequency (unit as in ITEM 11)
6 Output frequency range
(5)* 0 – 1 mHz
0 – 10 mHz
0 – 100 mHz
0 – 1.0 Hz
0 – 10 Hz
0 – 100 Hz
0 – 1.0 kHz
0 – 10 kHz
*( ) Output code R: Noncontact AC/DC switch
1.0000 Output span frequency (unit as in ITEM 13)
*( ) Output code R: Noncontact AC/DC switch
0.3 Low-end cutout frequency (unit as in ITEM 11)
Deadband fixed at 1% (Low-end cutout is reset when
the input exceeds the setting by 1%.)
1 Averaging non-uniform pulses
Input pulses are divided and then multiplied by the
ratio so that the output waveform is uniform (stable).
Range ≤ 0 – 100 Hz : Ratio 1 – 255
0 – 1 kHz
0 – 10 Hz
0 – 100 Hz
: 1 – 25
: 1 – 2
: Not selectable (fixed at 1)
EM-1581 Rev.4 P. 7 / 8
JFR2
