- Page 1 UHF SERIES UHF 540-590MHz (US) UHF 863-865MHz (EU) PROFESSIONAL WIRELESS MICROPHONE SYSTEM WM-219 User Manual A.D.J. Supply Europe B.V. Junostraat 2 6468 EW Kerkrade The Netherlands www.adj.eu...
- Page 2 ©2018 ADJ Products, LLC all rights reserved. Information, specifications, diagrams, images, and instructions herein are subject to change without notice. ADJ Products, LLC logo and identifying product names and numbers herein are trademarks of ADJ Products, LLC. Copyright protection claimed includes all forms and matters of copyrightable materials and information now allowed by statutory or judicial law or hereinafter granted.
-
Page 3: Table Of Contents
Contents GENERAL INFORMATION ................................ 4 SAFETY INSTRUCTIONS AND GUIDELINES ..........................5 OVERVIEW ....................................6 INSTALLATION LOCATION GUIDELINES ........................... 7 INSTALLATION | POWER | BATTERY REPLACEMENT ......................8 OPERATION ..................................... 8 TROUBLING SHOOTING TIPS ..............................9 TECHNICAL SPECIFICATIONS ..............................10 OPTIONAL ACCESSORIES ....................Fehler! Textmarke nicht definiert. ROHS - A great Contribution to the Conservation of Environment .................. -
Page 4: General Information
(1) External 12-15VDC Power Supply (2) Microphone Stand Clips CUSTOMER SUPPORT If you encounter any problems, please contact your trusted American Audio shop. We also offer the possibility, to contact us directly: You can contact us via our website www.adj.eu or via email: support@adj.eu... -
Page 5: Safety Instructions And Guidelines
SAFETY INSTRUCTIONS AND GUIDELINES To guarantee a smooth operation, it is important to follow all instructions and guidelines in this manual. The manufacturer of this device is not responsible for injury and/or damages resulting from the misuse of this device due to the disregard of the information printed in this manual. Any modifications to the device and/or the accessories included will void the original manufactures warranty and increase the risk of damage and/or personal injury. -
Page 6: Overview
OVERVIEW WIRELESS RECEIVER 1. Power Switch 8. CH-B Volume Control Dial 2. CH-A Volume Control Dial 9. DC Power Supply Input 3. CH-A Function Buttons 10. CH-B Antenna Input (BNC) 4. CH-A LED Control Display 11. CH-B 3pin XLR Balanced Audio Output 12. -
Page 7: Installation Location Guidelines
OVERVIEW (continued) HANDHELD MICROPHONE TRANSMITTERS 1. Frequency 2. Battery Level 1. Grill 2. LED Control Display 3. Infrared Receiver 4. Power Switch 5. Battery Compartment Cover* 6. Internal Antenna – Colored Ring INSTALLATION LOCATION GUIDELINES There are many factors that can affect and/or interrupt the wireless UHF signal. These factors can include walls, glass, metal objects and surfaces, other digital or electronic devices (CD/DVD/Media players, computers, laptops, Wi-Fi devices, cell phones, wireless phones, two-way radio communication devices, and wireless remote controls), electronic appliances, and people. -
Page 8: Installation | Power | Battery Replacement
INSTALLATION | POWER | BATTERY REPLACEMENT INSTALLATION AND POWER 1. Place receiver on a flat non-metal surface. 2. Connect both included UHF antennas to the back of the receiver. 3. Position both UHF antennas vertically and ensure they are fully extended. 4. -
Page 9: Troubling Shooting Tips
OPERATION (continued) AUTO FREQUENCY SETTING 1. Select one of the microphones and power it ON. 2. On the receiver, press the SCAN button for channel A or B and the receiver will begin to scan for the best available frequency. 3. -
Page 10: Technical Specifications
TECHNICAL SPECIFICATIONS PERFORMANCE Carrier Frequency: UHF 540-599MHz (US) / 863-865Mhz (EU) Frequency Stabilization: < ±20PPM Dynamic Range: >98dB Total Harmonic Distortion: <1% Frequency Response: 50Hz ~ 14Hz Audio Output Level: 0-300mV ¼ TRS I 0-2V XLR Balanced Range: 300 ft.* (980m) Unobstructed Line of Sight *May vary based on line of sight, UHF signal retention and/or interference. -
Page 11: Rohs - A Great Contribution To The Conservation Of Environment
– in short: each kind of electronics we have around us in our households or at work. As manufacturers of products of the brands of AMERICAN AUDIO, AMERICAN DJ, ELATION Professional and ACCLAIM Lighting, we are obligated to comply with the RoHS directive. Therefore, as early as two years prior to the directive coming into force, we started our search for alternative environmentally friendly materials and manufacturing processes. -
Page 12: Weee - Waste Of Electrical And Electronic Equipment
(Registration in Germany: DE41027552) That means that products of AMERICAN DJ and AMERICAN AUDIO can be left in the collection points free of charge and they will be used in the recycling program. Products of ELATION Professional, which are used only by professionals, shall be handled by us. -
Page 13: Notes
NOTES A.D.J. Supply Europe B.V. – www.adj.eu – WM 219 Instruction Manual Page 13... -
Page 14: Notes
NOTES ADJ Products, LLC 6122 S. Eastern Ave. Los Angeles, CA 90040 USA Tel: 323-582-2650 / Fax: 323-725-6100 Web: www.adj.com / E-mail: info@americandj.com Follow Us On: A.D.J. Supply Europe B.V. Junostraat 2 6468 EW Kerkrade The Netherlands facebook.com/americandj Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99 twitter.com/americandj Web: www.adj.eu/ E-mail: support@adj.eu youtube.com/americandj...
