- Page 1 UHF SERIES | UHF 510-556MHz PROFESSIONAL WIRELESS MICROPHONE SYSTEM WU-419V User Manual...
- Page 2 All non-AMERICAN AUDIO ® brands and product names are trademarks or registered trademarks of their respective companies. AMERICAN AUDIO ® and all affiliated companies hereby disclaim any and all liabilities for property, equipment, building, and...
-
Page 3: Table Of Contents
A M E R I C A N A U D I O w w w . a d j . c o m C O N T E N T S General Information Warranty Safety Instructions and Guidelines Overview Installation Operation Troubling Shooting Tips Technical Specifications Optional Accessories WU-419V User Manual... -
Page 4: General Information
Please recycle whenever possible. BOX CONTENTS (1) 4 Channel UHF Wireless Receiver (4) Hand Held Wireless Microphones (2) UHF Antennas (1) ¼ inch Male to ¼ Male Audio Patch Cable (1) External Power Supply WU-419V User Manual... - Page 5 You may also visit us on the web at http://www.adj.com for any comments or suggestions. For service related issue please contact us. AMERICAN AUDIO SERVICE USA - Monday - Friday 8:00am to 4:30pm PST Voice: 323-582-3322 Fax: 323-725-6100 E-mail: support@americandj.com...
-
Page 6: Warranty
The consumer’s and or Dealer’s sole remedy shall be such repair or replacement as is expressly provided above; and under no circumstances shall American Audio® be liable for any loss or damage, direct or consequential, arising out of the use of, or inability to use, this product. -
Page 7: Safety Instructions And Guidelines
HIGH TEMPERATURE OR HIGH HUMIDITY ENVIRONMENTS! AMBIENT OPERATING TEMPERATURE: 23° to 113°F. (-5° to 45°C) DO NOT USE DEVICE IF BATTERIES ARE DAMAGED, DEFORMED, OR HAVE AN ODOR! DO NOT DISASSEMBLE BATTERIES! DISPOSE OF BATTERIES ACCORDING TO LOCAL, STATE, AND COUNTRY REGULATIONS! WU-419V User Manual... - Page 8 Users of this wireless system should also be aware that the FCC is currently evaluating the use of wireless microphone systems, and these rules are subject to change. FOR MORE INFORMATION, CALL THE FCC AT 1-888-CALL-FCC (TTY: 1-888-TELL-FCC) OR VISIT THE FCC’S WIRELESS MICROPHONE WEBSITE BELOW. www.fcc.gov/cgb/wirelessmicrophones WU-419V User Manual...
-
Page 9: Overview
19. CH-B Balanced 3pin XLR Audio Output 9. CH-C Volume Control Dial 20. CH-A Balanced 3pin XLR Audio Output 10. CH-C Audio LED Indicator 21. DC Power Supply Input 11. CH-C Signal LED Indicator 22. CH-A+B Antenna Input WU-419V User Manual... - Page 10 O V E R V IEW - H A N D H E LD M IC R O PH O N E TR A N SM ITTE RS 1. Grill 4. Battery Compartment Cover 2. Battery State Indicator 5. Antenna / Color Ring 3. Power and Audio Mute Switch WU-419V User Manual...
-
Page 11: Installation
Therefore it is highly recommended to position the wireless receiver away from the above-mentioned items and a minimum of 3.0 ft. (1m) above audiences and/or above ground level. Careful planning and testing of the selected installation location is critical to ensure optimum and reliable wireless operation. WU-419V User Manual... -
Page 12: Operation
3. To power on the microphone, switch the power switch to the far left ON position. 4. To mute microphone, switch the power switch to center MUTE position. 5. To power off the microphone, switch the power switch to the far right OFF position. WU-419V User Manual... - Page 13 1. Relocate the Receiver to a direct line of sight location to the Transmitter. If Momentary loss of sound at 1. Antenna location. dead spots persist, mark these areas some locations within performance area and avoid performing in or around them. WU-419V User Manual...
-
Page 14: Technical Specifications
Length: 19.0” (482.6mm) Width: 10.4” (260.35mm) Height: 1.9” (49mm) Weight: 4.25 lbs. (1.9 kg) ELECTRICAL DC13-18V Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. WU-419V User Manual... -
Page 15: Optional Accessories
. a d j . c o m OPTIONAL ACCESSORIES ORDER CODE ITEM XL-3 3 ft. (0.9m) 3pin Microphone Cable XL-6 6 ft. (1.8m) 3pin Microphone Cable XL-12 12 ft. (3.6m) 3pin Microphone Cable Additional Cable Lengths Available WU-419V User Manual...
