- Page 1 Owner’s Manual T-102A / T-102TV...
-
Page 2: Table Of Contents
Menu Caution ..................................1 1.1. Electrical Safety ..............................1 1.2. Machine Check ..............................1 1.3. Sport Attention ..............................1 1.4. Children and Pets: .............................. 1 Before Installation ..............................2 Components List ................................ 2 Technical Parameters ..............................2 Assembly and Installation ............................3 Debug .................................. -
Page 3: Caution
1. Caution (Safety Precautions) Note: Please read this instruction carefully before using this treadmill, and pay attention to the following safety matters. 1.1. Electrical Safety Always turn off and unplug the power after the use of the treadmill or before cleaning or maintenance to avoid electric shock. -
Page 4: Before Installation
2. Before Installation Please check if the ground surface is level and solid, otherwise it may cause noise, vibration, and tripping over. Please keep the location in door with low humidity and dust level, otherwise will let machine break-down. Please check if any solvent or inflammable substance is nearby, in case electric spark occurs within the machine due to electric leakage or static, it may lead to an explosion or fire. -
Page 5: Assembly And Installation
5. Assembly and Installation After unpacking all the components, assemble and install the machine as per the following procedure. Image 5-1 The control line in the host machine run through the vertical stands. Install both right and left vertical stands to the horizontal load / base. Joint the seven-core connecting cable. -
Page 6: Operation Instruction
7. Operation Instruction 7.1. Console Function List Image 7-1 Keys Function Slope Rises Press to adjust the elevation of the slope on a treadmill. Slope Decrease Press to adjust the slope of decline of the treadmill. Stop Press this key when treadmill is running, treadmills temporarily stopped, all date can’t be lost when you restart. -
Page 7: Program Mode Instruction
7.2. Program Mode Instruction There are 5 modes for choice Function Operation LED Light area Value Time Countdown Mode Press PROGRAM key 1 time TIME 30.00 Distance Countdown Mode Press PROGRAM key 2 time DISTANCE Calories Countdown Mode Press PROGRAM key 3 times CARLORIES Preset Mode... -
Page 8: Customize Mode
Now the Shows SP1, and TIME window reads 30.00 and twinkle, press to reduce and press to prolong the running time which between 5~99 Min. Press Start key , belt will begin to move at lowest speed, and Slope and Speed will changes minute-by-minute follow below tables. -
Page 9: Maintenance
8. Maintenance Keep clean will prolong service life treadmill, therefore clean the running belt and running deck regularly is encouraged, soft cloth with soapy water could be adopt to clean the belt but do not pour water to flushing or the motor and other electronics parts properly be damaged. -
Page 10: Quality Warranty
9. Quality Warranty Exemption Clause Any service due to one of the following shall be charged even within the warranty period. Malfunction caused by infiltrated External impurities (water, drink, coffee, toys etc.) Malfunction or breakage caused by putting or dropping heavy object onto the product Damage or distortion of exterior by organic solvent such as thinner and benzene Malfunction caused by using other parts not supplied by us.
