Summary of Contents for Haswell Fitness T-202A
- Page 1 User Manual T-202A T-202TV T-202PAD T-203A T-203TV T-203PAD...
-
Page 2: Table Of Contents
CONTENTS SPECIFICATIONS ............................ 1 SAFETY INSTRUCTIONS ........................2 COMPONENT PARTS ..........................4 DESCRIPTION ............................5 INSTALLATION LOCATION ......................... 5 ASSEMBLY AND INSTALLATION ....................... 6 PART NAMES ............................13 CONSOLE – FEATURES AND FUNCTIONS ..................15 OPERATION INSTRUCTIONS ......................17 10. REPLACEMENT OF PARTS ......................... 19 11. -
Page 3: Specifications
200KG Power 220V/110V 50~60 HZ Models TV and MP3 Display / Screen N.W. / G.W. Remarking 210KG / 225KG T-202A T-202TV 19/17/15 inch External 212KG / 228KG ordinary Screen Support 15.6inch Android Pad 228KG / 232KG T-202PAD Interior Touch Screen... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS 2. SAFETY INSTRUCTIONS... - Page 5 SAFETY INSTRUCTIONS...
-
Page 6: Component Parts
COMPONENT PARTS 3. COMPONENT PARTS This product is packed and delivered as semi-assembled. Console Post Body... -
Page 7: Description
DESCRIPTION 4. DESCRIPTION T203 series is designed for use in Gyms or fitness centers with the most innovative design. Using powerful 3HP( continuous ) AC motor with the latest inverter control technology, it runs quietly, softly and safely. FEATURES • The most innovative design •... -
Page 8: Assembly And Installation
ASSEMBLY AND INSTALLATION 6. ASSEMBLY AND INSTALLATION After unpacking all the components, assemble and install the machine as per the following procedure. Power connection should be at standard voltage Treadmill should be mounted on level floor. Avoid uneven surface. After the installation, Treadmill should be grounded. - Page 9 ASSEMBLY AND INSTALLATION POST Attaching the Posts Assembly Insert posts (left & right) into the post guides at the front of the main frame body Loosely tighten 8 bolt washers fastening the bottom of the posts (4 each left & right) Use bolts and tool A.
- Page 10 ASSEMBLY AND INSTALLATION Console Assembly Use bolts and tool 2. Attaching the Console Assembly Insert the legs of Console Assembly into the left and right post Pushing 3 cords through the post. Loosely tighten 4 bolts with nuts fastening the bottom of the Console Assembly to the top of the posts (2 bolts each left &...
- Page 11 ASSEMBLY AND INSTALLATION Wiring of Console Wiring of Console the Actuator, Motor and Input cables on the Inverter are assembled to the Socket in the factory in advance 1. Pull 3 cords through the post out of a hole at the lower side of the post (A:UTP Cable, B:TV Antenna Cable C:TV power Cable) 2.
- Page 12 ASSEMBLY AND INSTALLATION TV Monitor This section applies only to models with TV Use bolts and tool A. Screwdriver B. M5 X 20 Pan head screw x 4pcs C. M5 X 10 Pan head screw x 4pcs Use bolts and tool...
- Page 13 ASSEMBLY AND INSTALLATION AC Power connection and TV Antenna Cable Insert the Antenna Cable to the Antenna Socket on the Front Cover (This section applies only to models with TV) T203 should use grounded socket and power cord. Insert the power cord provided to the power inlet at the front of main body and connect the power plug to the grounded socket Press the red lamp to turn on the main body.
- Page 14 ASSEMBLY AND INSTALLATION Note: Turn the belt adjustment screw-heads in end-cover using 8 mm hexagon wrench to adjust the belt as shown in the above Adjustment with T-Wrench and movement change of belt and roller Belt Section Wrench movement Roller shaft movement Side-drifting Left Left side backward...
-
Page 15: Part Names
PART NAMES 7. PART NAMES CONSOLE Console cabinet Display Main Control Urethane Handgrip(L) Urethane Handgrip(R) Emergency Stop HEADPHONE JACK HOUSING Console Cabinet Seal-Label for after-sales service Front Handgrip BODY Motor Cover Running belt Non-slip D Main frame Front-cover Front-wheel G End-cover H Level Foot... - Page 16 PART NAMES In side motor cover Motor Inverter Actuator TV Adapter Dust Block Plate POLY V-Belt Roller Front LCD TV monitor LCD TV monitor Connection bracket...
-
Page 17: Console - Features And Functions
CONSOLE – FEATURES AND FUNCTIONS 8. CONSOLE – FEATURES AND FUNCTIONS MAIN DISPLAY... - Page 18 CONSOLE – FEATURES AND FUNCTIONS CAUTION: Do not turn on power placing your hand on the main control. It may cause an error in the main control. (If necessary, turn off power and wait until remaining current gets depleted for more than 1 minute. And then, turn on power again.)
-
Page 19: Operation Instructions
OPERATION INSTRUCTIONS 9. OPERATION INSTRUCTIONS MANUAL WORKOUT 1. Turn the POWER on. Press POWER switch located on the front cover. 2. Press START button. Press START button. Then the running belt will start to move at the starting speed of 1.0km/h. CAUTION : The START/STOP button toggles between start and stop, i.e., first pressing starts operation and... - Page 20 OPERATION INSTRUCTIONS Power TARGET WORKOUT 1. Turn the power ON. Press POWER switch located on the front cover. 2. Select one of the workout targets. Press one of the WORKOUT TARGET buttons (TIME, DISTANCE, CALORIES) on the main display 3. Gender enter. Input gender with target +/_ button, and push ENTER 4.
-
Page 21: Replacement Of Parts
REPLACEMENT OF PARTS REPLACEMENT OF PARTS Replacement of Deck, Roller and Running Belt Running belt can be worn out and damaged from friction. In order to prevent it, check the oil condition frequently and ensure the oil is not dried. If the running belt or the deck is seriously worn out or damaged, it must be replaced as follows; STEP 1 : Turn the power off. -
Page 22: Lubrication
LUBRICATION STEP 9 : Detach the Motor Belt-pulley and front roller. STEP 10 : Detach the belt and the deck by pushing toward back. Assembling is in reverse order LUBRICATION Put the oil through injection hole at speed 1 km/h. If treadmill runs at high speed, oil will get out of belt. -
Page 23: Maintenance List
MAINTENANCE LIST MAINTENANCE LIST Your careful and routine maintenance of equipment including lubrication and cleaning is essential for long and problem-free operation Check point Check method Measure daily weekly monthly Inspection with unaided Sweat, dust and oil on 1.Cleaning with dried cloth eye (window, control board, surface 2.Cleaning with wet cloth... -
Page 24: Self-Check
SELF-CHECK SELF-CHECK Most Treadmill problems can be solved by following the steps below. Before calling the Service Center or our agent, please check first if your problem is one of those listed below. If further assistance is still needed, then please call our Customer Service Department. -
Page 25: Customer's Right
14.1. Customer’s right Customer is entitled to free warranty services for 1 year from the date of purchase. However, if service is required due to force majeure or customer’s misusage, service shall be charged even if It is within the warranty period. 14.2.
