Maybach Style Kids Ride on Car
Installation and Operation Instructions
Please read this instruction manual carefully. It is
important to read and follow all of the steps during
assembly to ensure proper operation and safety of the
child. Please keep this manual for future reference.
Scan this QR
Code to view our
assembly video
SPECIFICATIONS:
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Supertrax Maybach Style Kids Ride on Car
Summary of Contents for Supertrax Maybach Style Kids Ride on Car
- Page 1 Maybach Style Kids Ride on Car Installation and Operation Instructions Please read this instruction manual carefully. It is important to read and follow all of the steps during assembly to ensure proper operation and safety of the child. Please keep this manual for future reference.
- Page 2 Car Type: Maybach Style Battery Type: 12V7AH Electric Motor: 12V30W(Drive) Age Range: 2 – 5 Years Max. Weight: 65 lbs Product Size: 54”L x 29”W x 29”H Avg. Speed: 2 – 3 MPH Charging time: 8-12 hrs Avg. Use Time: 1-2 Hrs (depending on use) Remote Battery: 2 - AA (not included)
- Page 3 All assembly videos can be found on YouTube under SPORTrax...
- Page 5 ASSEMBLY INSTRUCTIONS: Remove car from box and plastic. Lay out all parts to be assembled. Unplug and remove both motor/gearboxes from the battery area. Turn car upside down so that the bottom of the car is facing up. Install rear wheels & motor/gearbox on rear axle: Right side - Slide motor/gearbox onto the rear axle while feeding the electrical connection through the hole in the body into the battery area and reconnect the electrical connection to the...
- Page 6 Install the Front Wheels: Slide a washer and then a black bushing onto the front axle. Slide the wheel onto the front axle. Slide another washer and then the nut onto the axle and secure assembly. Use the wheel nut wrenches to tighten down both sides.
- Page 7 Install Steering Wheel: Connect electrical connection between the steering wheel and the wires from the car. Slide steering wheel onto the steering shaft. Align the screw hole in the steering shaft and the steering wheel and slide the bolt through the hole.
-
Page 8: Charging And Battery Maintenance
Install the Seat: Slip tabs on back of seat into the slots in the body of the car. Attach seat to body through the two holes located in the front corners of the seat with 2 screws. See Fig. 10 Charging the battery: The charging port is located just under the front portion of the seat. - Page 9 REMOTE CONTROL BATTERY INSTALLATION: Open battery cover on the back of the remote control. Install 2 AA Batteries as indicated inside the cover. Replace battery cover and secure with screw. Once battery is fully charged, disconnect from charger. Depress power button to turn on the car.
-
Page 10: Troubleshooting Guide
TROUBLE SHOOTING GUIDE: Problem Possible Cause Possible Solutions Car will not move Battery voltage is low. Charge the battery Battery connector or wires Re-connect the battery are loose. connector to the car Battery is damaged or Replace battery dead. Electrical box or motor is Replace motor damaged The battery will not... -
Page 11: General Maintenance
GENERAL MAINTENANCE: It is the parent’s responsibility to check main parts of the toy before using. Regularly examine the car for potential hazard, such as damage to the battery, charger, cable or cord, and plug. Also, check that all screws are tightened throughout the car. In the event of such damage, the toy must not be used until that damage is repaired or replaced.
