Operating Instructions & Parts Manual
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
!
Obey all safety messages that follow this symbol to avoid possible injury or death.
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
© July 2017
Body Repair Kits
Model
BRK4T
BRK10T
Capacity
4 Ton
10 Ton
BRK4T
BRK10T
http://www.matcotools.com
MATCO TOOLS
Printed in China
BRK4T-M0_072017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BRK4T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Matco Tools BRK4T

Summary of Contents for Matco Tools BRK4T

  • Page 1 Operating Instructions & Parts Manual Body Repair Kits Model Capacity BRK4T 4 Ton BRK10T 10 Ton BRK4T BRK10T This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.

  • Page 2: Safety And General Information

    Labels and Operator's Manuals are available from the manufacturer. PRODUCT DESCRIPTION Matco Tools Body Repair Kits are designed to be used for pushing, spreading, and pressing of vehicle body panels as well as various component parts and assemblies. A variety of attachments are included.
  • Page 3 WARNING WARNING ADDITIONAL SAFETY MESSAGES pressure and/or temperature changes. for wear. a dangerous condition. 85% of the rated capacity. and adversely affect function.

  • Page 4: Before Use

    F = P x A, where F = lbs force, P = pressure in psi, and A = effective ram area in in Ram Area of Model BRK4T is: 0.998 in Ram Area of Model BRK10T is: 2.411 in Figure 3 - Variable Position (ref.
  • Page 5 Releasing Pressure on Work Piece: Slowly, carefully turn the release valve counter-clockwise until ram retracts to desired position. Never turn release valve more than 1/2 of a full turn. The ram return system is spring loaded and the release valve system is metered, allowing controlled retraction of the ram.

  • Page 6: Maintenance

    MAINTENANCE NOTICE: Adding oil Changing oil NOTICE: 3. Set pump in its level upright position. 5. Perform Bleeding/Air from System Lubrication A coating of light lubricating oil to pivot points and hinges will help to prevent rust and assure that pump assemblies move freely.

  • Page 7: Troubleshooting Guide

    TROUBLESHOOTING GUIDE The following information is intended as an aid in determining if problem exists. For repair service, contact Matco Tools service center in your area. Symptom Possible Causes Corrective Action Ram will not extend, or respond to Ram responds to pressurized pressure Service Center Secure load by other means.

  • Page 8: Replacement Parts

    Not all components of the jack are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence. When ordering parts, give Model number, serial number and description below. Call or write for current pricing: Matco Tools 4403 Allen Road, Stow, OH 44224-1096, U.S.A. Tel:(866)BUY-TOOL Matco Tools Website: http://www.matcotools.com...
  • Page 9 Oil Filler Screw F040-90009-K05 Hose Coupler, Male F040-90009-K04 Ram Coupler Assy, Female F040-20012-000 Dust Cover - Hose F100-90009-K01 Pump Handle F100-80001-000 Gauge F1000S-85 Repair Kit BRK10T-L0 Label ( not shown) BRK4T-M0 Manual Figure 5 - Replacement Parts Illustration for Model BRK10T...
  • Page 10 7,881 20,000 8,295 *For Model BRK4T, A = 0.998 in²; For Model BRK10T, A = 2.411 in² Example 1 Model BRK4T exerting 5,000 lbs of force will require what pressure? Pressure = Force / Ram Effective Area = 5,000 lbs / 0.998 in² = 5,010 psi...
  • Page 11 Matco Tools 4403, Allen Road, Stow, OH 44224-1096, U.S.A. Tel: (866) BUY-TOOL Matco Website: http://www.matcotools.com...

  • Page 12: One-Year Limited Warranty

    ONE YEAR LIMITED WARRANTY For a period of one (1) year from date of purchase, Matco Tools will repair or replace, at its option, without charge, any of its products, which fails due to a defect in material or workmanship under normal usage. This limited warranty is a consumer's exclusive remedy.
