- Page 1 Safety and operating instructions Hydraulic power packs PAC E 6, PAC E 11 www.cp.com...
- Page 2 PAC E 6, PAC E 11 3392 5227 01b | Original instructions...
-
Page 3: Table Of Contents
PAC E 6, PAC E 11 Contents Contents Introduction............... 5 About the Safety and operating instructions. - Page 4 Safety and operating instructions PAC E 6, PAC E 11 3392 5227 01b | Original instructions...
-
Page 5: Introduction
PAC E 6, PAC E 11 Safety and operating instructions Introduction Thank you for choosing Chicago Pneumatic brand products. For over a century, the Chicago Pneumatic brand has represented performance and innovation in the pneumatic tool industry. Today the brand is found around the world on a range of pneumatic and hydraulic tools that includes breakers, rock drills, chipping hammers, clay-diggers, picks and busters, scabblers, pumps and a whole lot more. -
Page 6: Safety Instructions
Safety and operating instructions PAC E 6, PAC E 11 Drugs, alcohol or medication Safety instructions WARNING Drugs, alcohol or medication To reduce the risk of serious injury or death to Drugs, alcohol or medication may impair your yourself or others, read and understand the Safety judgment and powers of concentration. -
Page 7: Operation, Precautions
PAC E 6, PAC E 11 Safety and operating instructions Operation, precautions WARNING Dust and fume hazard Dusts and/or fumes generated or dispersed when using the machine may cause serious and permanent DANGER Explosion hazard respiratory disease, illness, or other bodily injury (for... - Page 8 Safety and operating instructions PAC E 6, PAC E 11 ► Select, maintain and replace consumables/ WARNING Slipping, tripping and working tools/ other accessories as recommended falling hazards in the operating and safety instructions. Incorrect There is a risk of slipping or tripping or falling, for selection or lack of maintenance of consumables/ example tripping on the hoses or on other objects.
-
Page 9: Maintenance, Precautions
PAC E 6, PAC E 11 Safety and operating instructions WARNING Nominal pressure Maintenance, precautions If the maximum nominal pressure for the hydraulic machine is exceeded, it can result in material damage WARNING Machine modification and personal injury. Any machine modification may result in bodily Always run the hydraulic machine with a tool that ►... -
Page 10: Overview
PAC E 11 is fitted with a 11 kW (14.8 HP) electric motor. The oil flow for PAC E 6 is 20 ± 2 l.p.m (5 US gal/min) continuous and for PAC E 11 30 l.p.m (8 US Made in xxxxxx gal/min). -
Page 11: Installation
PAC E 6, PAC E 11 Safety and operating instructions EHTMA Lifting point label The European Hydraulic Tool Manufacturers Association (EHTMA) has categorised hydraulic power packs and tools in terms of flow rate and working pressure. PAC E 6 PAC E 11 Flow rate 20 l.p.m. -
Page 12: Hydraulic Control And Connectors
Safety and operating instructions PAC E 6, PAC E 11 Standard mineral or synthetic oil can be used. Make Hoses and connections sure to only use clean oil and filling equipment. When the machine is used continuously, the oil Ensure that the machine you plan to use is... -
Page 13: Transport
PAC E 6, PAC E 11 Safety and operating instructions To set or check the hydraulic oil flow and the Operation pressure relief valve we recommend using Chicago Pneumatic or similar test equipment. WARNING Involuntary start 0-250 bar (0-3,600 psi) ♦... -
Page 14: Start And Stop
Safety and operating instructions PAC E 6, PAC E 11 Start and stop When taking a break Starting the motor ♦ During all breaks you must place the machine in such a way that there is no risk for it to be 1. -
Page 15: Every Three Months
PAC E 6, PAC E 11 Safety and operating instructions ♦ Check hydraulic couplings. Problem Cause Solution Machine defective Check and service Check hydraulic filter. ♦ the machine All fasteners and other threaded components to Motor does not start Insufficient power Check power supply ♦... -
Page 16: Technical Data
Safety and operating instructions PAC E 6, PAC E 11 Technical data Machine data PAC E 6 PAC E 11 Height, mm (in.) 585 (23) 705 (27.8) Width, mm (in.) 525 (20.7) 605 (23.8) Length, mm (in.) 710 (28) 745 (29.3) Temperature range, °C (°F) -
Page 17: Noise Data
PAC E 6, PAC E 11 Safety and operating instructions Noise data Noise Sound pressure Sound power Declared values EN ISO 11203 2000/14/EC Type r=1m dB(A) rel 20µPa guaranteed dB(A) rel 1pW PAC E 6 PAC E 11 3392 5227 01b | Original instructions... -
Page 18: Ec Declaration Of Conformity
Safety and operating instructions PAC E 6, PAC E 11 EC Declaration of Conformity EC Declaration of Conformity (EC Directive 2006/42/EC) We, Construction Tools EOOD, hereby declare that the machines listed below conform to the provisions of EC Directive 2006/42/EC (Machinery Directive) and 2000/14/EC (Noise Directive), and the harmonised standards mentioned below. - Page 19 PAC E 6, PAC E 11 3392 5227 01b | Original instructions...
