Q UI CK STA RT BARREL BARREL BLOCKER FILL TANK Unpack the eXTCy and its barrel. Screw the barrel into the front of Have your compressed air (HPA) or CO tank filled by the marker, hand tight. Take care not to strip the barrel threads or over- a person who is properly tighten.
• EYE PROTECTION DESIGNED FOR PAINTBALL USE MUST BE WORN BY THE USER AND ANY PERSON Table of Contents and Safety Warnings WITHIN RANGE OF THE eXTCy Getting Familiar • GOG PAINTBALL ® RECOMMENDS THAT T H E Barrel Blocker / Hopper...
GE T TIN G F AM ILI AR PLEASE READ CAREFULLY STATISTICS MAINTENANCE The eXTCy has been designed with WEIGHT: 1.85 lb simplicity in mind so that you can concentrate on your game instead of your OPERATING PRESSURE: 160 psi marker.
B ARR EL B LO C K E R/ HOP PE R PLEASE READ CAREFULLY BARREL BLOCKER IN USE FIG. 1 BARREL BLOCKER The Barrel Blocking Device is a critical piece of paintball safety equipment - nearly as important as paintball goggles.
GA S ES NEVER PUT OIL IN A COMPRESSED AIR REGULATOR OR TANK - ONLY APPLY MANUFACTURER RECOMMENDED LUBRICANTS. COMPRESSED AIR HPA TANK BEING FILLED FIG. 3 The eXTCy is a low-pressure paintgun. It operates at approximately 160 psi, which means it is capable of functioning well with either high-pressure compressed air or CO as a power source.
Page 8
GA S ES PLEASE READ CAREFULLY ANGLED CO FIG. 4 [CUTAWAY VIEW] USING CO is usually not recommended for electronic paintball markers. This is not the case, however with the eXTCy . The eXTCy can function extremely well with CO as a power source, but doing so does require the correct configuration.
BA TT ER Y OVER TIME BATTERIES MAY LEAK. ALWAYS REMOVE THE BATTERY FROM THE eXTCy WHEN STORING FOR FOR MORE THAN A MONTH. FIG. 6 BATTERY ALKALINE BATTERY The eXTCy is powered by a standard 9-volt alkaline battery. Lower cost “heavy duty” batteries will not consistently deliver the amperage needed to operate the eXTCy reliably.
VI S I ON O PE RATI ON VISION BYPASS VISION DE-ACTIVATION FIG. 8 The eXTCy is equipped with a Vision break-beam anti-chop system, allowing it to acheive the highest possible rates of fire without chopping or mis-feeding paintballs. The eXTCy circuit board is linked to a light emitting diode and detector installed in the marker’s breech.
ELE CT RON IC A DJU STME N T Pulls To Enter: (Power Button LED blinks slowly red) - For Rebound Mode, the Pulls To Enter determines how many times the trigger must be pulled before marker ramps up to more than one shot per trigger pull.
IMPORTANT T RI G GER A D J U ST ME NT THE TRIGGER MUST COME TO A STOP WITH ITS ADJUSTMENT SCREW AGAINST THE GRIP FRAME OR DAMAGE TO THE CIRCUIT BOARD AND OR TRIGGER SWITCH MAY OCCUR. FIG. 9 TRIGGER ADJUSTMENT POINTS The length of the eXTCy trigger pull is fully adjustable.
UNLOADIN G / D E- GAS SI NG PLEASE READ CAREFULLY At the end of each day’s use and before performing maintenance work on your eXTCy , it will EVEN WITH NO CO OR COMPRESSED need to be de-gassed, and all paintballs must be removed. SYSTEM ATTACHED, EXTCY...
FI ELD S TRI PPI NG CLEANING The valve system in the eXTCy has only one major moving part. Regular cleaning and lubrication is necessary to ensure accurate and consistent performance. The eXTCy should be field stripped, cleaned and lubricated any time it shows erratic performance, becomes contaminated with paint, dirt or other debris, or for general maintenance after 3 or 4 days of use.
VI S I ON/D ETE N T CL E A NI NG CLEANING The Vision eye covers of the eXTCy are easily removed to provide access to both the Vision sensors and the marker’s ball-detents. To remove the eye covers, first unload and de-gas the marker following the instructions in this manual, then use a 0.050-inch allen wrench through the eye-cover access hole to unscrew the eye cover retaining screw, then tilt the eXTCy to the side, and if necessary tap it lightly against one hand to work the eye cover out.
– however they are delicate and may be damaged by improper handling or re-installation. For this reason it is highly recommended that full disassembly of the eXTCy be performed by an airsmith with GOG Paintball factory training, and then only when necessary to fix a problem or install an upgrade.
AD V ANVED M A IN TE N ANC E CONTINUED The circuit board is removed from the body by first unplugging the Vision wiring harness from its socket. Take care to grasp the plug and remove it - do not pull by the wires or they plug may be damaged.
AD V ANVED M A IN TE N ANC E CONTINUED If removing the breech from the body cover, the Vision wiring harness must be removed first. Uncoil the Vision wires and remove both eyes from their pockets (see Vision /detent cleaning).
FIG. 21 REGULATOR DISASSEMBLY REGULATOR SERVICE Although explained here, regulator service should only be performed by a GOG Paintball trained airsmith. With the marker unloaded and de-gassed, unscrew the regulator from the marker and remove the grip frame following the instructions in this manual. Take care not to lose the filter screen that sits inside the vertical regulator’s ASA connection.
Page 24
EQUIPMENT FAILURE OR INJURY AND sure to inspect, and if necessary replace the inlet filter in the side of the velocity adjuster. INVALIDATING THE GOG PAINTBALL WARRANTY. The vertical regulator is reassembled in the reverse order of disassembly. The piston slides into the regulator body wide end first, followed by the regulator spring.
• Pneumatic hoses may be loose, damaged or not fully connected. Replace hoses with genuine GOG Paintball hoses only. • Hose has been disconnected and re-attached. Replace with a new GOG Paintball internal hose. Removing a hose streches it so that it cannot be re-used without leaking. MARKER IS LEAKING DOWN THE BARREL •...
Page 26
• Battery may be low. This will be most noticeable with velocity dropping and then entire shots not firing during rapid fire. Replace battery with a new name brand alkaline battery. • Regulator may be contaminated or damaged. Follow the instructions in this manual or see a GOG Paintball technician for service. • Liquid CO may be entering the regulator –...
Page 27
• The rear trigger limit adjustment screw may be set in too far, stopping the trigger before GOGPaintball.com it can fire the marker. See the trigger adjustment section of this manual for guidance. • Trigger switch may be damaged. Contact your dealer or GOG Paintball technical support.
P ART S DIA G RAMS OB9015 - REGULATOR OB9015 - REGULATOR ASA O-RING ASA O-RING OM7014 - SPRING PLATFORM OM7014 - SPRING PLATFORM O-RING O-RING OU7010 - REAR SEAL OU7010 - REAR SEAL XTC105 - ENVY REGULATOR XTC105 - ENVY REGULATOR VRG102 - SPRING PLATFORM VRG102 - SPRING PLATFORM BODY...
Page 29
P ART S DIA G RAMS BOLT SLEEVE ASSEMBLY BOLT ASSEMBLY BOLT STOP ASSEMBLY BREECH ASSEMBLY GOGpaintball.com...
Page 30
P ART S DIA G RAMS XTC-103 EXTCY BREECH XTCY104 OB9017 EXTCY BOLT SLEEVE OH7017 OB7018 OB7022 XTC110 BOLT STOP BOLT SLEEVE OB7018 FRICTION O-RING OU7010 XTC119 VISION OB7018 XTC109 EYES EXTCY BOLT OU7014 OH7M10 OU9015 GOGpaintball.com...
Page 31
P ART S DIA G RAMS XTC127 SSC014 9v Alkaline FIT002 ELBOW (NOT SHOWN) XTC136 SSC014 FIT001 HBR510 XTC137 ON/OFF KNOB OU9006 ON/OFF O-Ring REMOVE ON/OFF KNOB FOR (ON XTC137, NOT SHOWN) SSC011 ACCESS TO SCREWS SSC011 GOGpaintball.com...
Page 32
P ART S DIA G RAMS COMPLETE EXTCY TRIGGER ASSEMBLY MAGNET IS PRESS-FIT FLUSH WITH LEFT SIDE OF TRIGGER MAG003 - TRIGGER MAGNET (.250 x .100 RARE EARTH MAGNET) SSS001 - POST TRAVEL ADJUSTMENT SCREW XTC107 - ENVY TRIGGER XTC124 - ENVY TRIGGER PIN OB7M05 - TRIGGER PIN O-RING (SHOWN ON PIN) O-RING PROVIDES FRICTION TO KEEP PIN SCREWED INTO GRIP FRAME - DO NOT USE THREAD...
Page 33
P ART S DIA G RAMS SSB010 VISION COVER SCREW SSC009 FEED CLAMP SCREW XTC115 - EXTCY FEED TUBE CLAMP SPR036 - EXTCY BALL DETENT SPRING XTC112 - EXTCY VISION COVER (LEFT) XTC113 - EXTCY VISION COVER (RIGHT) XTC114 - EXTCY FEED TUBE XTC111 - EXTCY BALL DETENT XTC101 - EXTCY BODY COVER GOGpaintball.com...
