Zero Appliances GFR260DB Installation, Service And User Instructions Manual

Double bin freezer refrigerator 2-way: l.p. gas & 230v electric
Hide thumbs
Table of Contents

Advertisement

Quick Links

Installation, Service and User
INSTRUCTIONS
FOR THE
ZERO MODEL: GFR260DB
DOUBLE BIN FREEZER REFRIGERATOR
2-WAY: L.P. Gas & 230V Electric
ZERO APPLIANCES (PTY) LTD
Cat. I
& I
3+ (28–30/37)
3B/P (30)
WARNING: THIS APPLIANCE MUST BE
EARTHED
ENSURE THAT THE GAS SUPPLY HOSE IS NOT IN
CONTACT WITH OR NEAR THE BURNER BOX

Advertisement

Table of Contents
loading

Related Manuals for Zero Appliances GFR260DB

Summary of Contents for Zero Appliances GFR260DB

  • Page 1 Installation, Service and User INSTRUCTIONS FOR THE ZERO MODEL: GFR260DB DOUBLE BIN FREEZER REFRIGERATOR 2-WAY: L.P. Gas & 230V Electric ZERO APPLIANCES (PTY) LTD Cat. I & I 3+ (28–30/37) 3B/P (30) WARNING: THIS APPLIANCE MUST BE EARTHED ENSURE THAT THE GAS SUPPLY HOSE IS NOT IN...

  • Page 2: Technical Data

    TECHNICAL DATA Zero Appliances Model GFR260DB Double Bin Freezer Refrigerator Category: For use on Butane at 2.8-3.0 kPa 3+ (28-30/37) and Propane at 3.7 kPa. For use on Butane and Propane 3 B/P (30) mixtures (LPG) at 3.0 kPa Declared rate: Injector size 0.42mm diameter, marked ‘13’...

  • Page 3: Installation Instructions

    INSTALLATION INSTRUCTIONS: IMPORTANT INFORMATION FOR THE USER Only a registered LP Gas installer may install a gas installation. All registered installers are issued with a card carrying their registration number. Ask to be shown the card before allowing the installation work to commence and make a note of the Installer QCC number. Upon completion of the installation, the installer is required to explain the operational details of the installation together with the safety instructions.
  • Page 4 NOTE: Any gas supply cylinder should have at least 250mm clearance if placed behind the appliance. GAS CONNECTION: The appliance inlet is to the 8mm plain straight tube, allowing connection by means of a gas-tight compression fitting to comply with both EC and local regulations.
  • Page 5 Do not smoke while checking for leaks. Do not check for leaks with an open flame. If the odour persists, contact your dealer or gas supplier immediately. Do not store or use gasoline or other flammable vapor and liquid in the vicinity of this or any other appliance.
  • Page 6 7. The appliance should be left running for a minimum of 12 hours before being loaded with products. To terminate the gas operation turn off the shut-off valve on the gas bottle or gas installation. USERS NOTE: The gas safety valve knob (A) should never be depressed for periods longer than 5 seconds with the burner unlit as this can cause a potentially dangerous build- up of unburnt gas.

  • Page 7: Some Useful Hints

    You have run out of gas. 7. The ambient temperature is too high. 8. Too many products are loaded into the refrigerator /freezer at one time – air must be able to circulate freely. 9. The lid is not properly closed or the lid seal is defective. 10.

  • Page 8: Cleaning Your Refrigerator Freezer

    6. You check the condition of the gas supply tube regularly: a) End fitting in good condition. b) Overall appearance etc. 7. You have switched on the appliance for approximately 12 hours prior to loading it with products. Avoid packing products in too tightly – air must be able to circulate freely 8.

  • Page 9: Prolonged Storage

     Do not try to accelerate defrosting by using any kind of heating appliance, as this might damage the internal surfaces of the freezer. ( No sharp object be used to scrape off the ice.)  Frost will gradually accumulate on the freezer surface. It must not be allowed to grow thick as it acts as an insulator and adversely affects freezer performance.

  • Page 10: In The Event Of Failure

    Examine the burner flame – ensure burning with a sharp blue flame and no yellow tipping or sooting. Check the door/lid seals are in good condition. IN THE EVENT OF FAILURE If the burner will not light: Check adequate gas supply – through to burner. Depress flame failure device for 15sec and try lighting with a match.
  • Page 11 GAS BURNER PARTS LIST 1. SANS BRASS HOSE TAIL. 2. FLAME FAILURE DEVICE. 3. M10 NUTS. 4. M10 x 3/8 UNF JET HOLDER. 5. M10 x 1 JET NUT. 6. JET. 7. MIXING TUBE. 8. BURNER BOX. 9. BURNER COVER. 10.
  • Page 12 Made in South Africa (Pty) Ltd Author: Rudi Version: 2.1 Revision: 1.2 Revision Date: June 2019...
