Americaloc GL300 W Manual

Welcome to AMERICALOC
IMPORTANT: Your complete satisfaction is our rst priority! If you have a problem or need assistance
please contact us at support@americaloc.com. Rest assured we will nd a solution for you. Our friendly,
knowledgeable customer service representatives are standing by to explain our services and to assist
you in getting the most from your GPS tracking service.
Your device's settings are optimized for vehicle tracking. Please reach out to our Support Team at
support@americaloc.com if you are tracking something other than a vehicle. We will gladly assist
you with con guring the device for maximum performance and battery life.
Before using our products or installing a device, carefully read our legal terms which you can nd at
http://us.americaloc.com/legal_info.html .
Activate your account and device GL300 W
Go to www.americaloc.com, select
1
United States and click the
Activate Now button.
Go to www.americaloc.com and
log in with the username and
password established in the
previous step.
5
Turn OFF and then ON the device after initial service payment. Your device already comes
with a SIM card installed.
Appearance
Power key
Function
key
Fill in the required information. The IMEI
2
code can be found below the bar code
that is printed on the back of your device.
Your account will now be ready to use.
Purchase one of our service plans by
4
clicking on the Click to pay service
A window will open to provide you with
payment instructions.
Please do not remove the SIM card.
The POWER key is in the upper side of the device.
POWER ON: Press the power key for 5 seconds.
Check LEDs are ON before using
POWER OFF: Press the power key for 5 seconds, release
the button and wait until the LEDs power o . It may take
up to a minute for the device to power down.
CHARGING: Fully charge your device before using it for
the rst time. A full charge takes about 8 hours.
FUNCTION KEY: You can con gure noti cations in your
Americaloc's account so every time this key is pressed
an email will be sent to the subscribed email warning
about this event.
Frequently asked questions
Dear Customer. This section contains very important information. Please do not skip it.
1. How long does it take to activate my device after processing a payment?
Your device will be active after the payment once you turn it o and turn it back on.
2. How does this technology work?
Your device reads data from satellites to nd its location; it then uses mobile networks to transmit its
location to our servers. Your device needs both: mobile network and GPS signals to work.
3. Do I need to purchase or provide a SIM card?
No, we ship the device with the SIM card it needs to transmit data. That SIM card only works with this
button.
device.
4. Do I need to install the SIM card?
No, the card is already installed. Please do not remove it.
5. I can´t see my device's location on the website.
If your device is powered ON, there are 2 reasons for this problem:
• Poor mobile network signal: Your device may be in a zone with poor mobile data coverage.
It will start transmitting again as soon as it gets into a better coverage zone. The device has an internal
memory to store locations in those cases. That information will be transmitted as soon as the device can
connect to the network again.
• Poor GPS signal: Your device may have lost GPS signal. That may happen when your GPS tracker is
covered by a thick surface or if your device is inside a building, underground or near tall buildings.
6. How long should I charge the device to fully charge the battery?
Eight hours of charge is enough. The device is fully charged after 8 hours or when the RED Power
LED is solid
7. My device reports a location that is slightly o from the actual location.
Accuracy depends on many factors beyond our control. For example: weather, clouds, tall buildings
or trees, bodies of water and device location.
Led behavior
GREEN (MOBILE NETWORK LED)
RED (POWER LED)
Fast ash: Charging
Fast ash: Searching for network
Slow ash: Low battery
Slow ash: Registered on network
Dark: Normal behavior or Device OFF
Dark: Device OFF
Solid: Charging completed
BLUE (GPS ERROR LED)
Will work for some minutes for testing
purposes and then it will go to sleep mode
to save battery.
