Generac Power Systems 1277-0 Owner's Manual page 17

Generac Portable Products 7200 Watt Mobile Backup Power System
PARTS LIST – MAIN UNIT
Item Part # Qty Description
1 HB4545 1
2 H92531 1
3 H92731 1
4 92247 1
5 B1342G 1
6 B1897G 1
7 65791 1
8 96796 1
9 22129 2
10 86307 4
11 47481 1
12 92609 2
13 82857 4
14 40976 2
15 66476 2
16 92532 1
17 22142 2
18 91153 1
19 90239 1
20 81917 1
21 78289 1
22 22127 2
23 22097 2
24 22287 2
25 66825C 1
26 74908 4
27 66449L 4
28 65795 1
29 66849A 1
30 67022 1
31 84132 1
32 66386 1
33 66849 2
34 B4871 1
35 22769 1
36 86494 1
37 86292 1
38 77395 4
39 83465 4
40 78831B 4
41 80270 1
42 78299 1
43 B4363 1
CRADLE
SUPPORT, Engine
SUPPORT, Engine & Muffler
HOUSING, Engine Adapter
ASSEMBLY, Rotor (Inclds Item 7)
ASSEMBLY, Stator
BEARING
WASHER, Grommet Retainer
LOCKWASHER, M8
HHMS, 5/16-24 x 3/4 SEMS
HHCS, 5/16-24 x 10.625
MOUNT,Vibration
MOUNT,Vibration
SCREW, M8 - 1.25 x 20
CAPSCREW, M6 - 1.0 x 12mm
BRACKET, Muffler
SCREW, 5/16 - 18 x 3/4
MUFFLER
GASKET, Muffler
PIN, Roll 4mm x 10
BRACKET, Starter Switch
NUT, 1/4 - 20 Hex
LOCKWASHER, M6
SCREW, 1/4 - 20 x 3/4
CARRIER, Rear Bearing
TAPTITE, M5-0.8 x 10
BOLT, Stator M6-1 x 165mm
RECTIFIER, Battery Charge
TAPTITE, M5-0.8 x 20
GROMMET, Rubber
ASSEMBLY, Power Regulator
ASSEMBLY, Brush Holder
TAPTITE, M5-0.8 x 16
COVER, Bearing Carrier
WASHER, Shakeproof Int. #10
SCREW, M6-1.0 x 16 Wing
HHCS, - #10 Self Driller
NUT, Flange Lock - M6
GROMMET,Tank
HHMS, M6-1.0 x 60, SEMS
VALVE,Tank
BUSHING, Plastic Tank
CAP, Fuel Gauge
Item Part # Qty Description
44 B1998 1
45 BB4675 1
46 92665 1
47 85000 1
48 14353621 1
49 26850 2
51 92982 1
52 B2153 7
53 189160 12
54 B5051 2
57 B4553 1
58 B4690 1
59 NSP 1
60 22531 2
62 93826 1
63 BB4674 1
64 56893 5
65 77282 1
66 B4986 1
68 45771 2
69 H96925 1
70 96924 2
71 58443 4
72 HB4672 1
73 11353621 1
74 52618 2
75 19953621 1
76 52856 2
77 23897 2
78 22145 2
79 B4489 1
Items Not Illustrated:
72347 1
73111 1
B4177 1
B4678 1
A8927 1
84882 1
BB3061 2
NSP 1
17
TANK, Fuel Assy.
(Includes Items 41 & 42)
SHIELD, Heat
INSULATION, #2-1/4" Thick
CLIP, Insulation
WIRE, Ground
LW, EXT, Shakeproof M6
DECAL, Danger
SELF DRILLER, 12 - 14 x 7/8"
NUT, 5/16 - 18 Serrated Flange
DECAL, Heat Shield
DECAL, Control Panel
ASSEMBLY, Control Panel
ENGINE
HHCS, 5/16-18 x 1-3/4"
DECAL, Start Instructions
SHIELD, Heat
CRIMPTITE, 10-24 x 1/2
SWITCH, Starter
DECAL, Ground
NUT, M8 Hex
BRACKET, Battery Tie-Down
J-BOLT, M8
CRIMPTITE, 1/4 - 20 x 5/8
TRAY, Battery
BATTERY CABLE, Negative
HHCS, M5 - 0.8 x 12
BATTERY CABLE, Postive
NUT, M5 Hex, Flange
WASHER, M5 Flat
WASHER, M8 Flat
BATTERY
PLUG, Spark
ELEMENT, Air Cleaner
CHARGER, Battery 12V
MANUAL, Generator Owner's
MANUAL, Engine Owner's
WRENCH, Spark Plug
OIL, 28 oz.
FLASHLIGHT
