Summary of Contents for Telecom FM CELLROUTE-GSM
- Page 1 CELLROUTE-GSM Fixed Wireless Terminal www.discountcomms.co.uk Installation & User Guide Version .05 – Jan 2006...
- Page 2 Jan 2006 Notices & WEEE Directive symbol added Notices Note: The cellRoute-GSM unit must be connected to the mains power and allowed to charge for a minimum of 30 minutes before use. Emergency Calls This terminal operates using GSM signals, which cannot guarantee connection in all conditions.
- Page 3 CellRoute-GSM Introduction Thank you for the purchasing the Cell Route-GSM terminal. The CellRoute-GSM incorporates: • CellRoute-GSM terminal (1) • Internal Antenna (2) • RJ11 Telephone connector (3) • RJ45 Data port (4) • L.E.D Indicators (5) • Power Connection (6)
-
Page 4: Getting Started
• Check Signal Strength • Make a test call Note: The cellRoute-GSM unit must be connected to the mains power and allowed to charge for a minimum of 30 minutes before use. However for maximum battery standby performance the CellRoute- GSM must be connected to the mains for a minimum of 4 hours. - Page 5 Getting Started Location Of Cell Route For best reception locate your CellRoute-GSM close to a window or on an external wall within a minimum of 330mm from any metallic object. The unit must be a minimum of 1 meter from any other sensitive electronic equipment.
- Page 6 GSM Network the Red LED will come back on. Making a test call Make a test call with the phone connected to the CellRoute-GSM. On completion of dialled digits you will hear a confidence tone indicating the call is successful.
- Page 7 The CellRoute-GSM has a network lock feature. This is a network security function. (For further details please contact your service provider) SIM PIN Lock The CellRoute-GSM has a SIM card PIN lock feature. This is a SIM card security function. (For further details please contact your service provider) Confidence Tone...
-
Page 8: Troubleshooting
CELL ROUTE-GSM Troubleshooting • First Things to Check If No Operation 1. Check that Power is connected. 2. Check that SIM card is installed correctly. 3. Check that the telephone is connected correctly. • LED Status 1. If NO LED’s are lit. •... - Page 9 1 meter away from other telephones and other electronic devices. • Reception is Poor The CellRoute-GSM comes with a built in antenna. However If you are experiencing problems with poor reception, check that you are getting adequate signal strength. This can be achieved by moving the CellRoute-GSM to another location, for examples move closer to a window or higher up in the building.
-
Page 10: Technical Specification
CELL ROUTE-GSM Technical Specification Telephony Interface Features Overview Call Control DTMF High Ringer Equivalence POTS Interface Line Voltage 48v on hook Supports up to 4 additional extensions Loop Current 40mA off hook Line impedance 600-ohm complex Highly compatible POTS user interface Ring Voltage 70Vrms Ring Load...
