SWIMMING POOL HEAT PUMP UNIT
Head Office
New South Wales
62 Parkhurst Drive
Unit 1, 20-22 Foundry Road
Knoxfield VIC 3180
Seven Hills NSW 2147
T: 03 9887 2131
T: 02 9838 0000
Installation & Instruction Manual
X 19 | X 24
Queensland
Unit 1, 8 Reichert Drive
Molendinar QLD 4214
T: 07 5679 6821
sales@sunloverheating.com.au
sunloverheating.com.au

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Oasis X Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Sunlover Oasis X Series

  • Page 1 SWIMMING POOL HEAT PUMP UNIT Installation & Instruction Manual X 19 | X 24 Head Office New South Wales Queensland 62 Parkhurst Drive Unit 1, 20-22 Foundry Road Unit 1, 8 Reichert Drive sales@sunloverheating.com.au Knoxfield VIC 3180 Seven Hills NSW 2147 Molendinar QLD 4214 sunloverheating.com.au T: 03 9887 2131...
  • Page 2: Table Of Contents

    CONTENTS 1. PREFACE ................................. 3 2. SPECIFICATION ............................. 4 2.1 Performance data of Swimming Pool Heat Pump Unit................. 4 2.2 The dimensions for Swimming Pool Heat Pump Unit ................... 4 3. INSTALLATION AND CONNECTION ......................5 3.1 Installation illustration ..........................5 3.2 Swimming Pool Heat Pumps Location ......................
  • Page 3: Preface

    1. PREFACE In order to provide our customers with quality, reliability and versatility, this product has been made to strict production standards. This manual includes all the necessary information about installation, debugging, discharging and maintenance. Please read this manual carefully before you open or maintain the unit. The manufacture of this product will not be held responsible if someone is injured or the unit is damaged, as a result of improper installation, debugging, or unnecessary maintenance.
  • Page 4: Specification

    2. SPECIFICATION 2.1 Performance data of Swimming Pool Heat Pump Unit *** REFRIGERANT: R410A Model Oasis Oasis X 19 X 24 Performance Condition: Air 27°C / Water 26°C Heating Capacity 19.3 26.1 Running Current 13.0 17.5 Performance Condition: Air 19°C / Water 26°C Heating Capacity Heating Power Input Cooling Capacity...
  • Page 5: Installation And Connection

    3. INSTALLATION AND CONNECTION 3.1 Installation illustration Installation items: The factory only provides the main unit and the water unit; the other items in the illustration are necessary spare parts for the water system, that provided by users or the installer. Attention: Please follow these steps when using for the first time 1.
  • Page 6: Swimming Pool Heat Pumps Location

    3. INSTALLATION AND CONNECTION 3.2 Swimming Pool Heat Pumps Location The unit will perform well in any outdoor location provided that the following three factors are presented: 1. Fresh Air 2. Electricity 3. Pool filter piping The unit may be installed virtually anywhere outdoors. For indoor pools please consult the supplier.
  • Page 7: Swimming Pool Heat Pumps Plumbing

    3.4 Swimming Pool Heat Pumps Plumbing The Swimming Pool Heat Pumps exclusive rated flow titanium heat exchanger requires no special plumbing arrangements except bypass (please set the flow rate according to the nameplate). The water pressure drop is less than 10kPa at max. Flow rate. Since there is no residual heat or flame Temperatures, the unit does not need copper heat sink piping.
  • Page 8: Swimming Pool Heat Pumps Electrical Wiring

    3.5 Swimming Pool Heat Pumps Electrical Wiring NOTE: Although the unit heat exchanger is electrically isolated from the rest of the unit, it simply prevents the flow of electricity to or from the pool water. Grounding the unit is still required to protect you against short circuits inside the unit.
  • Page 9: Usage And Operation

    4. USAGE AND OPERATION 4.1 Function of controller sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL – X 19 | X 24 SWIMMING POOL HEAT PUMP UNIT...
  • Page 10 4. USAGE AND OPERATION Symbol Meaning Function Cooling It is showed when the unit in cooling mode. Heating It is showed when the unit in heating mode and flashed in defrosting. Automatic It is showed when the unit in automatic mode. Electric –...
  • Page 11: The Controller Usage

    4. USAGE AND OPERATION 4.2 The controller usage 4.2.A - Starting up and shutting down In the off interface, press" " for 0.5s can start up the unit, and aux. display-area shows water outlet temperature; In the running interface, press" "...
  • Page 12: C - Temperature Setting

    4. USAGE AND OPERATION 4.2.C - Temperature setting ”or“ ” and the current mode target-temperature In the main interface,press “ ”to increase the temp.value, or press “ ”to decrease it. flashes, then press “ ”can save setting parameter and back to the main interface; Press “...
  • Page 13: D - Clock Setting

    4. USAGE AND OPERATION 4.2.D - Clock setting ” twice,Hours start to flashing ,and press “ In the main interface,press “ ” ”to decrease value,and press “”to save setting; to increase value or press “ At the same time, minute start to flashing ,press “ ”to increase value or press “...
  • Page 14: E - Timer Setting

    4. USAGE AND OPERATION 4.2.E - Timer setting ”hold on 2 seconds and "on" is flashing, at this time, In the main interface,press “ ”again and hold on you can set the timer on(means the unit timer is on),then press“ 2 seconds and "off"...
  • Page 15 4. USAGE AND OPERATION sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL – X 19 | X 24 SWIMMING POOL HEAT PUMP UNIT...
  • Page 16: F - Cancel The Timer Setting

    4. USAGE AND OPERATION 4.2.F - Cancel the timer setting ”for 2s and "ON" is flashing,at this time, press “ ”to cancel the setting Press“ of timer on; It is the same way to cancel the setting of timer off. For example:...
  • Page 17: G - Keyboard Lock

    4. USAGE AND OPERATION 4.2.G - Keyboard lock To avoid mis-operation, please lock the controller after parameter setting. ”for 5 seconds, the keyboard will be locked. At the main interface, press “ ”for 5 seconds, the keyboard will be When the keyboard is locked, press“ unlocked.
  • Page 18: Parameter Table

    4. USAGE AND OPERATION 4.3 Parameter table Meaning Default Remark Heating inlet target temp. 28°C Adjustable Cooling inlet target temp. 28°C Adjustable Auto inlet target temp. 27°C Adjustable The wire controller can display the temperature unit as "℉" or "℃" according to the unit Model you bought.
  • Page 19: Maintenance And Inspection

    5. MAINTENANCE AND INSPECTION 5.1 Maintenance • Check the water supply device and the release often. You should avoid the condition of no water or air entering into system, as this will influence unit's performance and reliability. You should clear the pool/spa filter regularly to avoid damage to the unit as a result of the dirty of clogged filter.
  • Page 20: Trouble Shooting Guide

    5. MAINTENANCE AND INSPECTION 5.2 Trouble Shooting Guide Malfunction Display Cause Solution Water inlet temp. Sensor failure The water inlet temp. Sensor Check or change the is open or short circuit water inlet temp. Sensor Water outlet temp. Sensor failure The water outlet temp.
  • Page 21: Caution & Warning

    6.APPENDIX 6.1 Caution & Warning 1. The unit can only be repaired by qualified installer centre personnel or an authorised dealer. (for Europe market) 2. This appliance can used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 22: Cable Specification

    6.APPENDIX 6.2 Cable specification 1. Single phase unit Three phase unit When the unit will be installed at outdoor, please use the cable which can against UV. sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL – X 19 | X 24 SWIMMING POOL HEAT PUMP UNIT...
  • Page 23: Explosive View Of The X19 Unit

    6.APPENDIX 6.4 Explosive view of the X19 unit sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL – X 19 | X 24 SWIMMING POOL HEAT PUMP UNIT...
  • Page 24: Explosive View Of The X 24 Unit

    6.APPENDIX 6.5 Explosive view of the X 24 unit sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL – X 19 | X 24 SWIMMING POOL HEAT PUMP UNIT...
  • Page 25: Knoxfield Vic

    ENQUIRY SOURCE Sunlover Heating are the sole distributor of Oasis Heat Pumps in Australia Victoria New South Wales Queensland South Australia Auckland 62 Parkhurst Drive Unit 1, 20-22 Foundry Road Unit 4, 8 Reichert Drive Sahara Pools & Solar 5b Estuary Views...
