Ernitec Eagle PIR-045 & 045H
Detectors for Perimeter Protection Outdoors
Standard Models
• PIR-045
Standard
Nominal Range 50 m (165 feet)
• PIR-045H High Performance
Nominal Range 60 m (200 feet)
Page 1 (15)
Installation Manual
Medium-Range Curtain
Version 2.0 and higher
Highlights
• Gap-Free Coverage with Creep Zones
• 4 Meter (13 Feet) Mounting Height
• Advanced Tamper Detection
• Low Power Consumption – Ideal for Wireless and
Solar Applications
• Wide Power Supply Range
• Heater & Heavy Duty Front Window (H version only)
• Integrated Bracket for Wall Mounting
• Remote Configuration and Alarm Management
www.ernitec .com
Advertisement
Table of Contents
Related Manuals for ERNITEC Eagle PIR-045
Summary of Contents for ERNITEC Eagle PIR-045
-
Page 1: Standard Models
Installation Manual Ernitec Eagle PIR-045 & 045H Medium-Range Curtain Detectors for Perimeter Protection Outdoors Version 2.0 and higher Highlights • Gap-Free Coverage with Creep Zones • 4 Meter (13 Feet) Mounting Height • Advanced Tamper Detection Standard Models • Low Power Consumption – Ideal for Wireless and •... - Page 2 Page 2 (15) www.ernitec .com...
-
Page 3: Table Of Contents
22 Appendix Two Way Communication RS 485...................12 22.1 Introduction ............................. 12 23 Appendix Installation Software......................13 23.1 Introduction ............................. 13 23.1.1 Application of the Installation Software ....................13 23.1.2 Software Installation ......................... 13 24 Appendix Specifications........................14 24.1 Mechanical Dimensions ........................15 Page 3 (15) www.ernitec .com... -
Page 4: Introduction
Output logic and function can be changed using the installation software. During turn-on time the relay output is in alarm state! Cover Switch To detect attempts to open the detector, a switch is fitted for the cover. Its contact opens when the cover is opened. Page 4 (15) www.ernitec .com... -
Page 5: Field Of View
4 m (13 ft) height. This means that special care has to be taken when mounting a detector onto a wall and aiming along the wall in order not to pick up disturbances caused by air turbulences along the wall. Page 5 (15) www.ernitec .com... -
Page 6: Sensitivity Settings
(on – on), the threshold level can be kept to its nominal value by changing the configuration of the ATD to „off“ for this test. The DIP – Switch 4 & 5 has no function in these detector models. Page 6 (15) www.ernitec .com... -
Page 7: Anti Vandal Function
Fine-tuning of the detector based on this data by changing the sensitivity settings may optimise the performance. Page 7 (15) www.ernitec .com... -
Page 8: Internal Heater (H Version Only)
Once the threshold level value has been exceeded, the microprocessor starts its signal shape analysis routine where a number of interdependent parameters are calculated and analysed. Only if a signal meets all the predetermined criteria an alarm will be generated. Page 8 (15) www.ernitec .com... -
Page 9: Accessories
Please see the PIRIF-485/2 Installation and Setup Manual, for further details. 16.2 Pole Mount Hardware Pole mounting bracket with two strap bands for poles up to 4 – 16 cm in diameter Page 9 (15) www.ernitec .com... -
Page 10: Maintenance
• Any liability f o r direct or indirect damage resulting from the use of the P IR as a detection device is explicitly disclaimed. • The information in this product manual is based on testing of samples taken at random from production and believed to be representative, and is subject to changes without notice. Page 10 (15) www.ernitec .com... -
Page 11: Appendix Electronic Board And Terminal Block
+ 10.5 ... 30 V DC / 24 V AC RS 485 * Relay shown in energised (non-alarm) condition 19.2 Dip Switches Sensitivity Function Switches Function SW Function SW settings HW setting 100% Pulse count HW setting 75% Test HW setting 40% Anti-vandal function Page 11 (15) www.ernitec .com... -
Page 12: Appendix Two Way Communication Rs 485
120 Ω . This can be accomplished by adding a resistor between the wires RS 485 A and RS 485 B. 120R Please see the PIRIF-485/2 Installation and Setup Manual, for further details. Page 12 (15) www.ernitec .com... -
Page 13: Appendix Installation Software
Please see the PIRIF-485/2 Installation and Setup Manual, for further details. Page 13 (15) www.ernitec .com... -
Page 14: Appendix Specifications
Wiring Terminal Block 0.34 mm … 1.5 mm (AWG 28 … 16) Environmental –20°C … +60°C –40°C … +60°C Operating Temperature (–4ºF … +140ºF) (–40ºF … +140ºF) Humidity 95 % RH max. Sealing IP 64 splash proof Page 14 (15) www.ernitec .com... -
Page 15: Mechanical Dimensions
22.1 Mechanical Dimensions Page 15 (15) www.ernitec .com...
