- Page 1 KR-04 RS232 - Ethernet converter USER MANUAL ITKU-92-01-07-16-EN www.radwag.com...
- Page 2 JULY 2016...
-
Page 3: Table Of Contents
CONTENTS 1. INTENDED USE ........................4 2. TECHNICAL SPECIFICATIONS .................... 4 3. DESIGN ..........................4 3.1. External view ........................5 3.2. Connectors ........................7 4. SETUP ........................... 9... -
Page 4: Intended Use
1. INTENDED USE KR-04 converter has been designed to be used with scales or terminals that are not equipped with Ethernet interface. It enables connection of scales with RS232 interface to LAN network. 2. TECHNICAL SPECIFICATIONS KR-04-1 KR-04-2 KR-04-3 Housing plastic stainless steel stainless steel... -
Page 5: External View
3.1. External view KR-04-1 converter 1 – Ethernet RJ45 port 2 – RS232 cable with DB9/F connector 3 – power supplier Dimensions of KR-04-1 converter (plastic housing) - Page 6 KR-04-2, KR-04-3 converter Dimensions of KR-04-2, KR-04-3 converter (stainless steel housing)
-
Page 7: Connectors
3.2. Connectors KR-04-1 interfaces 1 – Ethernet RJ45 port 2 – cable bush: power supplier 3 – cable bush: RS232 cable (cable with RJ45 connector) KR-04-2, KR-04-3 interfaces 1 – power cord cable gland 2 – RS232 cable gland (cable with a hermetic connector) 3 –... - Page 8 P0198 cable, KR-04-3 1- Ethernet hermetic connector 2- shielded twisted-pair wire 4x2xAWG26 3- RJ45 connector Ethernet cable, KR-04-2 1- shielded twisted-pair wire 4x2xAWG26 2- RJ45 connector 3- ring terminal 4- cable LgY 300/500V 0.35mm2...
-
Page 9: Setup
2. Establish communication between the computer and the converter via LAN, use crossed cable terminated with RJ45 connectors on both sides. For KR-04-3 converter use RADWAG-manufactured P0198 cable and a switch. 3. Connect the converter to the mains. 4. Run Network Enabler Administrator PC software. - Page 10 6. List of converters operating in LAN network is displayed. 7. Select the respective converter (double click using left mouse button). 8. Go to „Configuration” window, select „Network” tab. 9. Tick „Modify” box by field that is to be changed. 10.
- Page 11 12. Tick „Modify” box and select Port that is to be modified (double click using left mouse button). Default settings: Flow Control NONE FIFO Enable Interface RS232 Baud rate 9600 Parity NONE Data bits Stop Bits...
- Page 12 By default „Local TCP Port” is set to 4001. 14. Press „OK” button to confirm changes. 15. Exit Network Enabler Administrator PC software. Setup parameters may vary depending on individual needs. Network Enabler Administrator PC software is to be downloaded from www.radwag.com.
