- Page 1 AXIS ELECTRIC HEIGHT ADJUSTABLE DESK Installation Guide (For 1500mm wide desk)
- Page 2 AXISELECTRIC HEIGHT ADJUSTABLE DESK Installation Guide (For 1500mm wide desk) Safety and Warnings Set-up and Installation When the table has been assembled (see assembly instructions on page 3-4) the adjustable feet are installed so that the table is level and does not shift. •...
-
Page 3: Technical Data
AXIS ELECTRIC HEIGHT ADJUSTABLE DESK Installation Guide (For 1500mm wide desk) Maintenance and Defects Parts The table does not require any maintenance by usage as described in the above section. The table is only to be maintained with a wrung cloth. In the event of the occurrence of jarring sounds during operation, STOP using the table and please contact the dealer. - Page 4 AXIS ELECTRIC HEIGHT ADJUSTABLE DESK Installation Guide (For 1500mm wide desk) STEP 1: STEP 2: Screw 2 modesty panel pins into each leg. Slide modesty panel into position on each leg, tighten cam to lock in place. Use a soft headed hammer as necessary to fit the plastic cover caps to each cam.
- Page 5 AXIS ELECTRIC HEIGHT ADJUSTABLE DESK Installation Guide (For 1500mm wide desk) 60mm 60mm 30mm 30mm STEP 5: STEP 6: Place worktop on a clean, flat surface and centre the frame as per dimensions provided. Secure the worksurface to each leg using the provided screws. STEP 7: STEP 8: Secure the power supply and controls in the locations pictured below.
- Page 6 AXIS ELECTRIC HEIGHT ADJUSTABLE DESK Installation Guide (For 1500mm wide desk) Optional: COMPLETED For desks 1500mm or wider, fix a worktop stiffening rail in the centre of the worksurface as pictured below.
