DMP Electronics 1108 Installation Manual

1108 DOORBELL MODULE
Installation Guide
Figure 1: 1108 Doorbell Module
DESCRIPTION
The 1108 Doorbell Module monitors
doorbell button presses. When
someone rings the doorbell, the
module sends a wireless signal
to annunciate at keypads or any
connected 1136 Wireless Sounders.
Compatibility
• All panels with firmware Version
192 and higher
• Any video or mechanical doorbell
with a standard transformer or a
16‑24 VAC wall transformer with
either a mechanical chime or
10 Ohm resistor in the circuit
• 7000/9000 Series Thinline Series
Keypads with Level J Hardware
or higher
• 7800/9800 Series Graphic
Touchscreen Keypads with
Firmware Version 110 or higher

What is Included?

• One 1108 Doorbell Module
• Hardware pack
1
PROGRAM THE PANEL
When programming the 1108 in the panel, refer to the panel
programming guide as needed. If you'll be using an 1106 Wireless
Transmitter for the LED survey, program the transmitter in the
panel while referring to the 1106 Installation Guide (LT‑1377).
After completing each of the following steps, press CMD to
advance to the next prompt.
Enter 6653 (PROG) at the panel keypad and go to ZONE
1.
INFORMATION.
2. At ZONE NO, enter the wireless zone number. Refer to
Figure 2 for serial number location.
At *UNUSED*, enter the zone name.
3.
4. At ZONE TYPE, press any select key or area and select DB
(Doorbell).
5. At the Area Assignment section, select the area.
At the NEXT ZONE prompt, select NO.
6.
7. When WIRELESS? displays, select YES.
8. At SERIAL#, enter the eight‑digit device serial number.
9. At SUPRVSN TIME, enter a supervision time. Default is 240.
10. At the NEXT ZONE prompt, select YES if you are finished
programming the zone. Select NO if you would like to access
additional programming options.
11. To save panel programming, go to STOP and press CMD.
2
SELECT A LOCATION
To select a location, use an 1106 Series Universal Wireless
Transmitter to perform an LED survey operation.
1. With the cover removed, hold the module in the desired
location.
2. Press the tamper switch to send a signal to the panel and
determine if communication is confirmed or faulty.
Confirmed: For each press or release of the tamper
switch, the LED blinks immediately on and
immediately off.
Faulty: The module LED remains on for about
8 seconds or flashes multiple times in quick
succession.
3. If the transmitter is not communicating with the panel,
start by looking for items that might cause interference,
such as metal objects or electronic equipment. Move the
transmitter or receiver and repeat the survey procedure
until communication is confirmed.
