Cat.No.SBF1-1
Where Form Follows Function Where Form Follo
Follows Function Where Form Follows Function W
Function Where Form Follows Function Where Fo
Where Form Follows Function Where Form Follo
Follows Function Where Form Follows Function W
SkyBlade
Function Where Form Follows Function Where Fo
STOL Series
Patent pending
Where Form Follows Function Where Form Follo
12'-24'
Follows Function Where Form Follows Function W
Function Where Form Follows Function Where Fo
Where Form Follows Function Where Form Follo
Follows Function Where Form Follows Function W
Function Where Form Follows Function Where Fo
Where Form Follows Function Where Form Follo
Follows Function Where Form Follows Function W
Function Where Form Follows Function Where Fo
Where Form Follows Function Where Form Follo
Installation
Follows Function Where Form Follows Function W
Manual
Function Where Form Follows Function Where Fo
Custom Designed
Where Form Follows Function Where Form Follo
Reduced Maintenance
STOL Technology
Follows Function Where Form Follows Function W
Function Where Form Follows Function Where Fo
Where Form Follows Function Where Form Follo
Follows Function Where Form Follows Function W
www.SKYBLADEFANS.com
Function Where Form Follows Function Where Fo
Where Form Follows Function Where Form Follo
Follows Function Where Form Follows Function W
Function Where Form Follows Function Where Fo
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Skyblade STOL Series
Summary of Contents for Skyblade STOL Series
- Page 1 Where Form Follows Function Where Form Follo Follows Function Where Form Follows Function W SkyBlade Function Where Form Follows Function Where Fo STOL Series Patent pending Where Form Follows Function Where Form Follo 12’-24’ Follows Function Where Form Follows Function W...
- Page 2 électrique, la mort, un incendie et / ou des dommages matériels. Avant d’ e ntreprendre l’installation, l’ e ntretien ou un nettoyage, coupez l’alimentation électrique au panneau de service et ntelle. bloquez les dispositifs de sectionnement pour éviter une mise en marche accide Where Form Follows Function SKYBLADE FANS -...
- Page 3 Utiliser cet appareil uniquement de la manière prévue par le fabricant. Si vous avez des questions, contactez le fabricant. La garantie limitée ne couvre pas les dommages à l’ é quipement ou de l’ é chec qui est causé par une mauvaise installation. Where Form Follows Function SKYBLADE FANS -...
-
Page 4: Table Of Contents
Installing Airfoils, Motor Cover, and Motor Hub .......... 25-31 Electrical ......................32-38 Troubleshooting ......................39 User Servicing Instructions ................40-41 ® and SkyBlade Fans ® are the trademarks of Skyblade Fans. SkyBlade STOL Control and Power Assembly (patent pending) Model Description Length (Y) Width (X) - Page 5 Materials not included in the fan contents (e.g., Grade 5 hardware, etc.) are the responsibility of the installer. Notify your product representative or Skyblade Fan Company of any discrepancy or missing kit contents prior to installing unit.
-
Page 6: Fan Diagram
115 230 460 575 115 230 460 575 115 230 460 575 115 230 460 575 115 230 460 575 115 230 460 575 Model Number Ordering Format: SERIES-DIAMETER-BLADES-INPUT VOLTAGE-PHASE Sample Model Number: STOL-1649-623-1 Where Form Follows Function SKYBLADE FANS -... -
Page 7: Important Information
When mounting a fan in an area where objects may be lifted or moved into the path of the fan, Skyblade Fans recommends marking or painting hash lines on the floor to alert personnel of the above movement of the fan. -
Page 8: Mounting Considerations
The maximum torque that must be handed by the mounting system and the building structure will occur at the fans startup. For a 16 foot fan, maximum potential startup torque is 300 ft-lbs. Skyblade Fans use a soft-start technology which allows the rpm to ramp up as desired over 60 seconds. The event of this max torque being applied is unlikely and will only apply due to a failure of the variable frequency drive and its soft start technology. -
Page 9: Preparing The Work Site
Skyblade Fans can only be hung from an I-beam or angle irons. See installation instructions on the following page. Do not mount the fan to single purlins, trusses, or bar joists. Consult a structural engineer for installation methods not covered in the manual. -
Page 10: Mounting Method 1: I-Beam
650 lbs (295 kg). It is the sole responsibility of the customer to verify that the building’s structure is adequate for fan installation. Skyblade Fans recommends consulting with a structural engineer prior to fan installation. -
Page 11: Mounting Method 2: Angle Iron
.25”(.6cm) 3”(7.6cm) over 8’ (2.4m) - x 3”(7.6cm) 12’ (3.7m) x.25”(.6cm) *2 pairs of angle irons. Pairs should be placed back to back and fastened in center (see step 2). Height Thickness Width Where Form Follows Function SKYBLADE FANS -... - Page 12 Align the angle irons to each other and tighten the bolts to 90 ft-lb (122 N-m) using a 3/4” socket with torque wrench. Proceed to step 6.4b. Grade 5 Hardware (customer supplied) a. (2) 1/2”-13 GR 5 Bolt b. (4) 1/2” Flat Washer c. (2) 1/2” Nylock Nut Where Form Follows Function SKYBLADE FANS -...
- Page 13 (4) 1/2”-13 GR 5 Bolt b. (8) 1/2” Flat Washer c. (4) 2-1/2” Square Washer (see diagram) d. (4) 1/2” Nylock Nut 2.5” (6.4 cm) 9/16” Dia. (1.4 cm) 2.5” (6.4 cm) Where Form Follows Function SKYBLADE FANS -...
- Page 14 Fixer les cornières aux points de fixation de la structure du toit à chaque extrémité fourni par le client 5 e année du matériel comme indiqué. Grade 5 Hardware (customer supplied): a. (4) 1/2”-13 GR 5 Bolt b. (8) 1/2” Flat Washer c. (4) 2-1/2” Square Washer (see diagram) d. (4) 1/2” Nylock Nut Where Form Follows Function SKYBLADE FANS -...
- Page 15 (4) 1/2”-13x2-1/2” GR 5 Bolt b. (8) 1/2” Flat Washer c. (4) 1/2”-13 Nylock Nut 11 1/4: (28.32cm) Upper Yoke Top View 13 3/4” (34.9cm) x 8” (20.32cm) Upper Yoke Side View Where Form Follows Function SKYBLADE FANS -...
-
Page 16: Mounting Method 3: Purlins
Mounting Method 3: PuRlins NOTE: Purlin brackets and hardware are available from SkyBlade Fan Company upon request and not included standard. 6.6 Selecting Proper Angle Irons Select the proper angle irons based on the requirements stated under section 6.1. Pre-Drill Purlins Drill four 9/16”... - Page 17 Purlin Bracket Hardware (per set, supplied): a. (2) 1/4” Formed Steel Purlin Bracket b. (2) 1/4” Steel Purlin Backplate c. (16) 1/2”-13-1 3/4” GR 5 Bolt d. (16) 1/2” Nylock Nut e. (32) 1/2” Flat Washer Where Form Follows Function SKYBLADE FANS -...
-
Page 18: Mounting Method 3: Purlins
Calculs de masse doit être fait pour sélectionner le unistrut de taille appropriée. Défaut de le faire peut aboutir à dommages au ventilateur et de bâtiment ou même un préjudice personnel. Skyblade Fan Company est pas responsable de tout dommage ou blessure résultant d’une mauvaise installation. - Page 19 8”x 9”x 1/4” Flat Steel Plates b. (2) 1/4” Steel C Channel Bars c. (8) 1/2” Threaded Rods d. (16) 1/2” Nylock Nuts e. (16) 1/2” Washers f. (2) Steel Safety Cables g. (4) 1/8” Wire Rope Clips Where Form Follows Function SKYBLADE FANS -...
-
Page 20: Hanging The Fan
17/32” open hole on the top of the extension tube, and securing the ends with the gripple fastener as shown. The cable must have as little slack as possible. Securely tighten the gripple. Cable End Detail Where Form Follows Function SKYBLADE FANS -... - Page 21 Tighten bolts to 90 ft. lbs. (122 N-m) using a 3/4” socket with torque wrench. Motor Chassis Hardware (supplied): a. (4) 1/2”-13x1-1/2” GR 5 Bolt b. (8) 1/2” Flat Washer c. (4) 1/2”-13 Nylock Nut Where Form Follows Function SKYBLADE FANS -...
-
Page 22: Installing Guy Wires/Gripple
1. Slide the gripple fastener (as supplied) over the opposite end of the wire. 2. Feed the end of the guy wire through the guy wire loop on the fan and then through the gripple, removing any slack from the cable. Where Form Follows Function SKYBLADE FANS -... - Page 23 Assurez-vous que tous les câbles électriques ne soient pas obstruées par des haubans. Gripple Eye Hook a Beam Clamp a Chassis Eye Hook b Guy Wire b Eye Hook c Gripple Fastener c Gripple Wire Loop Gripple Maximum Angle Ceiling/Beam Guy Wire 45° Maximum Where Form Follows Function SKYBLADE FANS -...
-
Page 24: Pressure Relief Valve Installation
(a) using 5/8” wrench. Using a 7/16” wrench insert valve (c) into reducer (b). Failure to install pressure release valve will void manufacturer warranty. Pressure Release Valve Hardware (supplied): a. Gearbox b. Reducer c. Pressure release valve Where Form Follows Function SKYBLADE FANS -... -
Page 25: Installing Airfoils, Motor Cover, And Motor Hub
Ne pas insérer d’ o bjets étrangers entre les pales du ventilateur. Airfoil Hardware Kit (supplied): a. (6) 5/16”-18x2” GR 5 Bolt b. (6) 5/16”-18x1-3/4“ GR 5 Bolt c. (24) 5/16” Flat Washer d. (12) 5/16”-18 Nylock Nut Where Form Follows Function SKYBLADE FANS -... - Page 26 Airfoils 9.1a Attach Airfoils to Hub: Slide airfoil onto struts until airfoil holes and strut holes are aligned. Where Form Follows Function SKYBLADE FANS -...
- Page 27 9.1b Attach Airfoils to Hub: Airflow Leading Low Pressure Counter clockwise High Pressure rotation of blade Bottom Trailing NOTE: Fan turns in counter clockwise rotation when looking up. NOTE: Forward position on control blows air downward. Where Form Follows Function SKYBLADE FANS -...
- Page 28 Second, tighten the bolts along the inside to 29 ft-lb(39 N-m) using a 1/2” socket with torque wrench. Boomerang Bracket Kit (supplied): a. (6) 5/16”-18x2” GR 5 Bolt b. (6) 5/16”-18x1-3/4“ GR 5 Bolt c. (24) 5/16” Flat Washer d. (12) 5/16”-18 Nylock Nut Airfoil Boomerang Brackets Airfoil Straight Brackets Where Form Follows Function SKYBLADE FANS -...
- Page 29 Wingtip Wingtip Hardware Kit (supplied): a. (6) #6 x 5/8” Flat Phil Screw IMPORTANT: After installation is complete, replace plug on gear reducer elbow with pressure release valve provided by SkyBlade Fan Company. Where Form Follows Function SKYBLADE FANS -...
- Page 30 MOTOR COVER NOTE: Motor cover and hardware are available from SkyBlade Fan Company upon request and are not included standard. 9.4 Motor Cover Assembly 1. Orient the motor cover so that the three ventilation slots are on top. 2. Knock out the hole for the motor cable on the cover that is on the side of the motor electrical box.
- Page 31 HUB Cover NOTE: Hub cover and hardware are available from SkyBlade Fan Company upon request and are not included standard. 9.5 Hub Cover Assembly 1. Align the hub cover with the threaded hole on the reducer output shaft. 2. Screw in the provided hub cover bolt with the washer and tighten with a 9/16” wrench.
-
Page 32: Electrical
2. Proper grounding of panel and fan per the NEC is required for safety and proper operation. 3. Remote switch, remote cable, motor cable, and motor cable glands supplied by Skyblade Fans. 4. Length of cable from drive to motor to be 25 feet or less. - Page 33 à l’ é tat solide. The installation of a SkyBlade Fan must be in accordance with the National Electrical Code, ANSI/NFPA 70- 1999, and all local codes. The procedures and techniques outlined in this manual are merely a guide for proper installation.
- Page 34 The SkyBlade Fan product warranty will not cover equipment damage or failure that is caused by improper installation. La garantie des produits Skyblade Fan ne couvrira pas les dommages à l’ é quipement ou de l’ é chec qui est causé par une mauvaise installation.
- Page 35 Electrical Installation VS1ST - 1 Phase 115V/230V Wiring Diagram VS1ST - 3 Phase 230V/460V/575V Wiring Diagram Where Form Follows Function SKYBLADE FANS -...
- Page 36 Electrical Installation ACS250 - 1 Phase 115V Wiring Diagram ACS310 - 1 Phase 230V Wiring Diagram Where Form Follows Function SKYBLADE FANS -...
- Page 37 Electrical Installation ACS310 - 3 Phase 230V/460V Wiring Diagram ACS250 - 3 Phase 575V Wiring Diagram Where Form Follows Function SKYBLADE FANS -...
- Page 38 U2, V2, and W2 terminals. Use a tightening torque of 0.8 Nm. (7 lbf-in) for frame sizes R0...R2, 1.7 Nm (15lbf- in) for R3, and 2.5 Nm (22 lbf-in) for R4. 2. Secure the cables outside the drive mechanically. Job Site Installed Factory Installed Where Form Follows Function SKYBLADE FANS -...
-
Page 39: Troubleshooting
Do not run your controller and sensitive equipment on the same power line. c. Install properly sized EM/RFI filter. d. Contact Customer Service at 1-586-806-5107. 5. Error code appears on VFDs digital interface. Please contact Skyblade Fans customer service to resolve issue. Where Form Follows Function SKYBLADE FANS -... -
Page 40: User Servicing Instructions
3. Remove fuse carefully by pulling up on the exposed fuses. 4. Risk of fire. Replace fuse only with 25 Amp, 600 Volt ATMR25 Fast Acting Class C fuse. 5. Close fuse cover by pushing down on the top lever until completely closed. Where Form Follows Function SKYBLADE FANS -... - Page 41 I-beam or angle irons. 9. Administer proper cleaning techniques such as dusting airfoils, motor, reducer and chassis. If desired, used a water based cleaner to polish airfoils. Maintenance Log: Date: Maintenance Performed Replacement Parts Required Where Form Follows Function SKYBLADE FANS -...
- Page 42 Replacement Parts Replacement Part List: Part No. Description If you have any questions, please contact customer service at 1-586-806-5107. Where Form Follows Function SKYBLADE FANS -...
- Page 43 Notes Where Form Follows Function SKYBLADE FANS -...
- Page 44 www.SKYBLADEFANS.com 24501 Hoover Road Warren, MI 48089 USA Telephone: 1.586.806.5107 Fax: 1.586.806.5109 E-Mail: sales@skybladefans.om LIM.STOL.0416...
