Mect 04 Series User Manual

Hmi with plc
Hide thumbs
Table of Contents

Advertisement

Quick Links

USER'S MANUAL for
TPAC1007 04 series
HMI with PLC
ME7053_08
07/19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 04 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Mect 04 Series

Summary of Contents for Mect 04 Series

  • Page 1 USER’S MANUAL for TPAC1007 04 series HMI with PLC ME7053_08 07/19...

  • Page 2: Table Of Contents

    HMI with PLC: TPAC1007_04 Mect S.r.l INDEX 1. Introduction ......................2 1.1. Staff skill ......................2 1.2. Symbols ......................2 1.3. Terms ......................... 2 1.4. Security ......................3 1.5. REFERENCE MANUAL .................. 3 2. System description ....................4 2.1 Specification ......................5 2.2 Wiring description AA model ................

  • Page 3: Introduction

    Products described in this manual are devoted to PLC programmers or automation experts only. MECT S.r.l. declines any responsibility about malfunctioning or damage caused by incorrect use of MECT devices, due to noncompliance to this manual information. MECT S.r.l has an help desk.

  • Page 4: Security

    HMI with PLC: TPAC1007_04 Mect S.r.l 1.4. Security Attention Switch off devices before connecting them. ESD (Electrostatic discharge) Modules have electronic components that can be damaged by. electrostatic discharge. Be sure to be connected to ground when handle the devices.

  • Page 5: System Description

    USB-pen drive for software updates and data log. Through a GPRS/UMTS or Wi-Fi key (optionally sold by Mect) is possible to connect the operator panel to a Wi-Fi or Mobile network. Settings under MENU  OPTIONS  NETWORK_CFG ...

  • Page 6: Specification

    HMI with PLC: TPAC1007_04 Mect S.r.l Specification TPAC1007 is based on a multiprocessor system. PLC and HMI are based on a 454MHz ARM9 Table 1 PLC Hardware characteristics PLC Processor ARM926JE 454MHz 128MB FLASH 128MB Non volatile variables On FLASH memory...

  • Page 7: Wiring Description Aa Model

    HMI with PLC: TPAC1007_04 Mect S.r.l Wiring description AA model See table for wiring of model TPAC1007 04 AA: Table 2 TPAC1007 04 AA Expansion features Input type Resolution Note 0.005mA 12 Input impedance 8 020 mA 0.003V 12 Input impedance 0V...

  • Page 8: Wiring Description Ab Model

    HMI with PLC: TPAC1007_04 Mect S.r.l Wiring description AB model See table for wiring of model TPAC1007 04 AB: Table 3 TPAC1007 04 AB Expansion features Input type Resolution Note 0.005mA 12 Input impedance 8 020 mA 0.003V 12 Input impedance 0V...
  • Page 9 HMI with PLC: TPAC1007_04 Mect S.r.l 0.01V 12 Min impedance: 1K 010V PWM @250Hz Min impedance : 1K 0.01V 12 Min impedance: 1K Analogue N° 2 010V output (out3-out4) PWM @250Hz Min impedance: 1K Input type Resolution Note PNP o NPN (factory PLC cycle Digital input N°1...

  • Page 10: Wiring Description Ac Model

    HMI with PLC: TPAC1007_04 Mect S.r.l Wiring description AC model See table for wiring of model TPAC1007 04 AC: Table 4 TPAC1007 04 AC Expansion features Input type Resolution Note 0.005mA 12 Input impedance 8 020 mA 0.003V 12 Input impedance 0V...

  • Page 11: Mechanical Dimensions

    HMI with PLC: TPAC1007_04 Mect S.r.l Mechanical dimensions In the following figures see the TPAC1007 dimensions. Panel with frame mounting and hooks fastening: Encumbrance Front view Side view ME7053_08 07/19...
  • Page 12 HMI with PLC: TPAC1007_04 Mect S.r.l Mounting plate Panel with frame mounting and screws fastening: Encumbrance Front view Side view Mounting plate ME7053_08 07/19...
  • Page 13 HMI with PLC: TPAC1007_04 Mect S.r.l Panel without frame mounting: To mount it is necessary that the display is exactly at the same panel height, so for metal panels below 2,5mm it is necessary to insert a shim to reach the exact quote.

  • Page 14: Panel Mounting

    HMI with PLC: TPAC1007_04 Mect S.r.l 2.6 Panel mounting 2.6.1 Distance System must be installed with a space for heat dissipation and cabling. Avoid superimposing cabling to avoid EMC problems. Figure 6A – Horizontal mounting Figure 6B – Vertical mounting...

  • Page 15: Connections Tpac1007 04

    HMI with PLC: TPAC1007_04 Mect S.r.l 3. Connections TPAC1007 04 Power supply Isolation Device has a galvanic isolation between power supply and RS485 serial line. System power supply Il TPAC1007 04 has a 12Vdc to 36Vdc supply for the main board and the expansion board as well, according to the scheme in the below figure.

  • Page 16: Fuse

    HMI with PLC: TPAC1007_04 Mect S.r.l Fuse 3.2.1 System has no internal fuse , so it is suggested the use of an external 500mA fuse for the panel power supply. IO wiring Analogue and digital wiring 3 wire PT100 input. Wiring with too high resistance can cause measure errors.
  • Page 17 HMI with PLC: TPAC1007_04 Mect S.r.l TPAC1007 +24V Digital I/O. Terminals 21 ÷ 28 can be configured as digital input or output . See in the figure the 28 terminal connection. Terminals “17, 19 and 20” are high speed inputs...

  • Page 18: System Variables

    HMI with PLC: TPAC1007_04 Mect S.r.l 3.4 System variables Table 6 Variable name Description Description PLC_FWrevision Revision RO Expansion firmware revision PLC_HWconfig configuration PLC_DigDir_1 1 bit to 8 PLC_DigDir_2 1 output PLC_DigDir_3 0 input PLC_DigDir_4 bit 9 to 16 not used...
  • Page 19 HMI with PLC: TPAC1007_04 Mect S.r.l  8 TCS (S type thermocouple)  9 TCB (B type thermocouple)  10 TCR (R type thermocouple)  0 not configured  1 current Analogue output PLC_AnOutConf_1  2 voltage configuration 1  3 pwm ...
  • Page 20 HMI with PLC: TPAC1007_04 Mect S.r.l Conf 5: 0 ÷ 400 value: 0 ÷ 400°C resolution 1 digit Conf 6: -40 ÷ 800 value: -40 ÷ 800°C resolution 1 digit Conf 7: -400 ÷ value: -40.0 ÷ 200.0°C 2000 resolution 1 digit Conf 8: 0 ÷...
  • Page 21 HMI with PLC: TPAC1007_04 Mect S.r.l Input A = 1 counter down Input B counter PLC_EncoderReset Reset Encoder RW 1: encoder/counter reset PLC_ Heartbeat Heartbeat RO I/O board Heartbeat PLC_time Time RO time elapsed [s] PLC_timeMin Time min RO start window 10 seconds...

  • Page 22: Modbus Wiring

    HMI with PLC: TPAC1007_04 Mect S.r.l ModBus wiring ModBus on TPAC1007 is a optoisolated 2 wire RS485 serial line, on the terminal board on pins: Table 7 Signal Description GNDiso Line + Line - Example of a wiring of a system composed by: ...

  • Page 23: Peripherals

     data storage: data logger  connect USB peripherals as printers, mouse, etc.  connect a Wi-Fi or Mobile key (optionally supplied by Mect) to connect to a different network from LAN. Specific connection of external peripherals are implemented on request.
