- Page 1 Operating Instructions Key Adapter CKS-K-AS2A-U-C20-PC (Unicode)
-
Page 2: Table Of Contents
System status table .................... 12 Technical data ....................13 11.1. Technical data, key adapter CKS-K-AS2A-U-C20-PC ................13 11.1.1. Typical system times ......................14 11.1.2. Dimension drawing of key adapter CKS-K-AS2A-U-C20-PC............14 11.2. Technical data, key CKS-A-BK1-RD-113461 ..................15 11.2.1. Dimension drawing ......................15 Inspection and service ..................16 Service ...................... -
Page 3: About This Document
Key Adapter CKS-K-AS2A-U-C20-PC 1. About this document 1.1. Scope These operating instructions are valid for all CKS-K-AS2A-U-C20-PC. These operating instructions, the document “Safety information and maintenance” and any enclosed data sheet form the complete user information for your device. 1.2. Target group Design engineers and installation planners for safety devices on machines, as well as setup and servicing staff possessing special expertise in handling safety components. -
Page 4: Correct Use
EN 60204-1, Safety of machinery. Electrical equipment of machines. General requirements The key adapter must be used only in conjunction with the designated CKS keys from EUCHNER. On the use of different keys, EUCHNER provides no warranty for safe function. -
Page 5: Description Of The Safety Function
Prior to use, read the operating instructions and keep these in a safe place. Ensure the operating instructions are always available during mounting, setup and servicing. EUCHNER cannot provide any warranty in relation to the readability of the CD for the storage period required. For this reason you should archive a printed copy of the operating instructions. -
Page 6: Function
Operating Instructions Key Adapter CKS-K-AS2A-U-C20-PC 6. Function The key adapter CKS can, e. g., be used as a lockout mechanism. As soon as the key is in the key adapter, this is reported via the AS-Interface bus. Each delivered key possesses a unique electronic coding and so is a unique element in the system used. -
Page 7: Mounting
Operating Instructions Key Adapter CKS-K-AS2A-U-C20-PC 7. Mounting NOTICE Risk of damage to equipment and malfunctions as a result of incorrect installation. Ì To achieve the degree of protection IP 67, it is necessary to install the key adapter in a clean, flat metal plate at least 2 mm thick and to tighten the screws with a tightening torque of 0.25 ... -
Page 8: Electrical Connection
Operating Instructions Key Adapter CKS-K-AS2A-U-C20-PC 8. Electrical connection CAUTION Risk of damage to equipment or malfunctions as a result of incorrect connection. Ì Power devices which are a powerful source of interference must be installed in a separate location away from the input and output circuits for signal processing. The cable routing for safety circuits should be as far away as possible from the cables of the power circuits. -
Page 9: Setting The As-Interface Address
The key adapter is configured in the AS-Interface safety monitor with the AS-Interface address set as follows: Ì Dual-channel positively driven Ì With or without start-up test 8.4. Pin assignment key adapter CKS-K-AS2A-U-C20-PC View on rear of key adapter Figure 1: Terminal assignment, AS-Interface connection terminal 123914-01-05/15 (translation of the original operating instructions) -
Page 10: Setup
Operating Instructions Key Adapter CKS-K-AS2A-U-C20-PC 9. Setup 9.1. LED indicator You will find a detailed description of the signal functions in chapter 10. System status table on page 12. LED color Significance Green Key inserted Yellow Readiness for operation Fault 9.2. -
Page 11: Functional Check
Operating Instructions Key Adapter CKS-K-AS2A-U-C20-PC 9.3. Functional check WARNING Danger of fatal injury as a result of faults in installation and functional check. Ì Before carrying out the functional check, make sure that there are no persons in the danger area. -
Page 12: System Status Table
Operating Instructions Key Adapter CKS-K-AS2A-U-C20-PC 10. System status table CKS LED indicator Operating mode State Normal operation, key inserted Normal operation, no key taught-in Normal operation Normal operation, no key inserted AS-i bus connected and in operation 1 Hz Normal operation, key inserted but not taught-in, AS-i bus connected and in operation... -
Page 13: Technical Data
Operating Instructions Key Adapter CKS-K-AS2A-U-C20-PC 11. Technical data NOTICE If a product data sheet is included with the product, the information on the data sheet applies. 11.1. Technical data, key adapter CKS-K-AS2A-U-C20-PC Parameter Value Unit min. typ. max. Housing material... -
Page 14: Typical System Times
Switch-on time: The max. reaction time t is the time from the moment when the key is in the operating distance to sending the code sequence. 11.1.2. Dimension drawing of key adapter CKS-K-AS2A-U-C20-PC (Gummidichtung/ rubber seal) (translation of the original operating instructions) 123914-01-05/15... -
Page 15: Technical Data, Key Cks-A-Bk1-Rd-113461
Operating Instructions Key Adapter CKS-K-AS2A-U-C20-PC 11.2. Technical data, key CKS-A-BK1-RD-113461 Value Parameter Unit min. typ. max. Housing material Plastic PC Dimensions 42 x 25 x 18 Weight 0.004 Ambient temperature - 20 + 70 °C Degree of protection IP67 Power supply Inductive via key adapter 11.2.1. -
Page 16: Inspection And Service
Ì In case of damage, the entire device must be replaced. Ì Only accessories or spare parts that can be ordered from EUCHNER may be replaced. Regular inspection of the following is necessary to ensure trouble-free long-term operation: Ì Check the switching function (see chapter 9.3. Functional check on page 11) Ì... -
Page 17: Declaration Of Conformity
Operating Instructions Key Adapter CKS-K-AS2A-U-C20-PC 14. Declaration of conformity 123914-01-05/15 (translation of the original operating instructions) - Page 18 Operating Instructions Key Adapter CKS-K-AS2A-U-C20-PC (translation of the original operating instructions) 123914-01-05/15...
- Page 19 Operating Instructions Key Adapter CKS-K-AS2A-U-C20-PC 123914-01-05/15 (translation of the original operating instructions)
- Page 20 D-70771 Leinfelden-Echterdingen info@euchner.de www.euchner.de Edition: 123914-01-05/15 Title: Operating Instructions Key Adapter CKS-K-AS2A-U-C20-PC (translation of the original operating instructions) Copyright: © EUCHNER GmbH + Co. KG, 05/2015 Subject to technical modifications; no responsibility is accept- ed for the accuracy of this information.
