- Page 1 ООО "Индастриал Партнер" www.skf.indpart.ru mail@indpart.ru Авторизованный дистрибьютор SKF 8(495)223-07-69 SKF TIH L MB Instructions for use Техническая поддержка: mail@indpart.ru, 8(495)223-07-69...
- Page 2 Figure 1: TIH L MB as delivered Figure 2: TIH L MB after bearing supports assembly Figure 3: TIH L MB with open yoke Figure 4: TIH L MB with horizontal workpiece heating Техническая поддержка: SKF TIH L MB mail@indpart.ru, 8(495)223-07-69...
-
Page 3: Table Of Contents
5.4 TIME MODE ........................12 5.5 Temperature measurement ..................12 5.6 Change of temperature unit ..................12 5.7 Demagnetisation ......................12 5.8 Power level selection ....................13 Safety features ....................13 Troubleshooting .....................14 Spare parts ....................15 Original instructions Техническая поддержка: SKF TIH L MB mail@indpart.ru, 8(495)223-07-69... -
Page 4: Ec Declaration Of Conformity
3439 MT Nieuwegein The Netherlands herewith declare that the following product: SKF Induction Heater TIH L MB Series has been designed and manufactured in accordance with: EUROPEAN LOW VOLTAGE DIRECTIVE 2006/95/EC EMC DIRECTIVE 2004/108/EC as outlined in the harmonized norm for... -
Page 5: Safety Recommendations
• Ensure the yoke is applied with the ground faces pointing downward, and in proper contact with the core uprights. • Do not modify the TIH L MB. • The TIH L MB must not be exposed to condensing humidity or direct contact with water. Техническая поддержка: SKF TIH L MB mail@indpart.ru, 8(495)223-07-69... -
Page 6: Introduction
8(495)223-07-69 1. Introduction The SKF TIH L MB induction heaters are designed to heat work pieces others than bearings such as gears, couplings, bushings, pulleys, etc. The heat causes the workpiece to expand, which eliminates the need to use force during installation. A 90 °C (162 °F) temperature difference between the workpiece and shaft is generally suficient to enable installation. -
Page 7: Distinguishing Features
The remote control electronics and the internal electronics, control the operation of the heater. A sliding yoke allows the workpiece to be placed onto the heater. A temperature probe is included with the heater. Heat-resistant gloves are also included. Техническая поддержка: SKF TIH L MB mail@indpart.ru, 8(495)223-07-69... -
Page 8: Technical Data
Exc. legs 1 320 ™ 600 ™ 1 150 mm (52 ™ 23.6 ™ 45.3 in.) Inc. legs 1 850 ™ 1 330 ™ 1 150 mm (72.8 ™ 52.4 ™ 45.3 in.) Техническая поддержка: SKF TIH L MB mail@indpart.ru, 8(495)223-07-69... - Page 9 Workpiece maximum Bearing TIH L 33 MB: 700 kg (1 543 lb) weight Bearing TIH L 44 MB & TIH L 77 MB: 1 200 kg (2 600 lb) Solid component: consult SKF Maximum heating approx. 400 °C (752 °F) temperature Standard yoke TIH L 33 MB: 80 ™...
-
Page 10: Installation Of Mains Plug
Place the magnetic end of the probe on the innermost surface of the workpiece. • Switch on the TIH L MB with the main switch of the heater electrical cabinet • Observe the self-test of the remote control display and signal tone. Техническая поддержка: SKF TIH L MB mail@indpart.ru, 8(495)223-07-69... -
Page 11: Operation
The remote control display shows the current temperature of the workpiece. • During heating the selected temperature can be displayed for 1 second by pressing MODE. • When the selected temperature has been reached, the heater demagnetises the Техническая поддержка: SKF TIH L MB mail@indpart.ru, 8(495)223-07-69... -
Page 12: Time Mode
To use the TIH L MB for demagnetisation only, select TIME MODE and set the time to 0,1 minute (6 seconds). Техническая поддержка: SKF TIH L MB mail@indpart.ru, 8(495)223-07-69... -
Page 13: Power Level Selection
1 °C (1.8 °F) every 1 minute (1.00 minute). To increase the interval to 2 minutes (2.00 minute). press MODE and DOWN at the same time. • Flashing warning light indicates ongoing heating process in the heaters TIH L44MB and TIH L77MB. Техническая поддержка: SKF TIH L MB mail@indpart.ru, 8(495)223-07-69... -
Page 14: Troubleshooting
E10E Electronics communication Switch the heater OFF and then back problem ON. If problem remains return the TIH to SKF for repair E11E Electronics communication Switch the heater OFF and then back problem ON. If problem remains return the TIH... -
Page 15: Spare Parts
Circuit breaker 100A for TIH L44/LV and L77/LV TIH CB100A TIH CB32A Circuit breaker 32A for TIH L33/MV TIH CB63A Circuit breaker 63A for TIH L33/LV TIH P20 Temperature probe K type incl. cable and plug Техническая поддержка: SKF TIH L MB mail@indpart.ru, 8(495)223-07-69... - Page 16 SKF Maintenance Products ® SKF is a registered trademark of the SKF Group. © SKF Group 2015/07 mapro.skf.com skf.com/mount MP5454EN Техническая...
