Assembly, Installation, Care, Maintenance and Use Instructions
Please read and retain this manual as it will assist with identification for parts and service.
Read these materials prior to assembling and using of this product
This trampoline is subject to 100kgs weight limit.
Usage of this trampoline is limited to persons weighing less than weights specified above.
Do not allow more than one person on the trampoline at a time.
Do not allow young children to use unless supervised by an adult.
Action Sports has reproduced extracts from AS4989-2006 Clauses 3.2.1 – 3.2.2; 3.3.1.2 & 3.3.2.1 and Appendices
A & B. These have been reproduced with permission from SAI Global under licence 1004-C016. The relevant
standard may be purchased online at www.saiglobal.com.
© ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au
Action Sports Equipment Pty Ltd.
72 Silverwater Rd, Silverwater, NSW, Australia, 2128
(Australia) or
Or visit our website: www.actionsports.com.au
8FT TRAMPOLINE COMBO
Model: S000435 / S000619
IMPORTANT
THIS PRODUCT IS FOR DOMESTIC USE ONLY.
- Warning -
orders@bernsport.co.nz
(New Zealand)
Page: 1
Advertisement
Table of Contents
Related Manuals for Action Sports Equipment S000435
Summary of Contents for Action Sports Equipment S000435
- Page 1 Action Sports has reproduced extracts from AS4989-2006 Clauses 3.2.1 – 3.2.2; 3.3.1.2 & 3.3.2.1 and Appendices A & B. These have been reproduced with permission from SAI Global under licence 1004-C016. The relevant standard may be purchased online at www.saiglobal.com. © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 1...
-
Page 2: Table Of Contents
TRAMPOLINE ASSEMBLY ......................15 Frame Assembly..........................15 Mat Assembly ...........................16 Frame Pad Assembly.........................18 ENCLOSURE ASSEMBLY ......................19 Pole Assembly...........................19 Net Assembly ............................20 CARE & MAINTENANCE OF YOUR TRAMPOLINE ..............23 DISPOSAL INFORMATION ......................24 LIMITED WARRANTY…………………………………………………………….…….……….25 © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 2... -
Page 3: Safety Information
(c) Avoid bouncing for too long. Do not bounce when tired. (d) Stop your bounce by flexing your knees as your feet come in contact with the trampoline bed. Learn this skill before you attempt any others. © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 3... -
Page 4: How To Use Your Trampoline
Smaller children may need assistance getting up on or down from the trampoline. Mounting and dismounting properly should be a strict rule from the very © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 4... -
Page 5: Fundamental Trampoline Skills
They should remain in this balanced position until you start down. Then they circle down and slightly behind the hips, ready to lift again as you bounce up (see Figure 1). © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 5... - Page 6 Practice these simple variations and concentrate on perfect form. Make sure that your toes are pointed and fingers are straight. These are simple variations to the basic bounce and are very important for gaining experience in coordinated movement. © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 6...
- Page 7 (c) From the standing position, prime the bed several times. Lift upward with your hips, reach forward with our hands, and land on all fours. Look slightly in front of your hands on landing. Push to © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 7...
- Page 8 (e) Push with your hands to return to the feet Step 3: (a) Start from a straight standing position. (b) Prime the bed several times. (c) Perform skill as in Step 2 (see Figure 7). © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 8...
- Page 9 (b) Finish standing with arms stretched overhead, facing the opposite direction (180 degree twist completed). Step 3: Perform as in Step 2. Just before contacting feet with the trampoline bed, lift your legs to land in a sitting position (see Figure 8). © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 9...
- Page 10 Seat drop Full twist Seat drop (Full barrel roll) Perform this as you would a half barrel roll but keep moving your shoulder in the direction of the twist so © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 10...
-
Page 11: Jumpers' Role In Preventing Accidents
When supervision is unavailable or inadequate, this may require that the trampoline be disassembled, placed © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 11... - Page 12 These instructions are issued in the interest of child safety, and we ask you to follow our advice. © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 12...
-
Page 13: Installation And Maintenance Instructions
Top Rail Tube (C) Leg Tubes (Left) Leg Tubes (Right) W-Shaped Tubes T-Joint Mat with Sewn-in V-Rings Frame Pad Springs Long Nut (Φ6mm x 30mm) Round Head Bolt (Φ6mm x 10mm) © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 13... -
Page 14: Parts List - Enclosure
Contact Customer Service at 1800 465 070 (Australia) or 09 477 6020 (New Zealand) if any parts are missing. Do not attempt to assemble the trampoline if any parts are missing. © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 14... -
Page 15: Trampoline Assembly
T Joint and follow this process around the trampoline to form the top rail loop. Push each section firmly to ensure both ends of the rail pieces are firmly in position within the T Joint. Please see Figure 3. © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 15... -
Page 16: Mat Assembly
To facilitate the assembly of the springs to the mat, please use the Spring Hook provided to pull the springs during assembly. Spread out the Mat (H) and have both the Springs (J) and Spring Hook ready for assembly. © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 16... - Page 17 4. Divide the Mat (H) into eighths and connect the springs as shown in Figure 4. 5. Connect the remaining springs to the mat. 6. When the Springs (J) have been properly connected, the trampoline should look like Figure 6. © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 17...
-
Page 18: Frame Pad Assembly
(facing the ground). Align the pre-sewn side straps with each T-joint on the main frame as shown in Figure 4. © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 18... -
Page 19: Enclosure Assembly
Attach the Upper Support Poles (B) and the Lower Support Poles which have both been pre-assembled with foam (See Figure 1). Ensure spring loaded locking pins are aligned with locking holes and pin locks into position. © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 19... -
Page 20: Net Assembly
The edge with the pre-sewn hanging loops is the top of the net. Working your way around the unit, place each hanging loop over the top of each ball cap (See Figure 1). © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 20... - Page 21 The assembly of the enclosure is now completed as shown below. There is a plastic warning placard enclosed with the enclosure package. Permanently affix this warning placard to the outside of the enclosure, next to the entrance. © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 21...
- Page 22 For normal weather conditions, “normal weather Anchoring kits” are also available for Action Trampolines. For more information please call 1800 46 50 70. © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 22...
-
Page 23: Care & Maintenance Of Your Trampoline
Any large trampoline, with or without an enclosure, can be blown around in high winds and cause injury or damage. We recommend that the Enclosure should be removed under these conditions and stored in a dry place. © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 23... -
Page 24: Disposal Information
Store safely & out of reach for children until it can be properly disposed of. Remember to dispose it in a safe place and manner so as not to present any hazards to any individuals. © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 24... -
Page 25: Limited Warranty
1800 465 070 (Australia) or email service@actionspares.com.au Standard Call 09 477 6020 (New Zealand) or email orders@bernsport.co.nz Opening Hours: 9am – 4:30pm Monday to Friday (excluding Public Holidays) 9am – 3pm Saturday www.actionsports.com.au © ACTION SPORTS EQUIPMENT PTY LTD – www.actionsports.com.au Page: 25...
