Oar Assembly (Certain Models):
1. Insert "Shaft A" with the pin end first into the blade. Make sure the pin is securely
fastened to the blade.
2. Insert the assembled "Shaft A" through the oar-lock with the blade towards outboard
(water).
3. Place the retainer ring onto the other end of the assembled "Shaft A", from inside of the
boat.
4. Join "Shaft A" with "Shaft B" together by inserting them together into the coupler and
tighten the coupler covers securely.
5. When the oars are not in use secure the oars onto the oar holders located on each side
of the boat.
Pin
Blade
FRENCH OARS:
SAVE THESE INSTRUCTIONS
Coupler Cover
Retainer Ring
Coupler
Shaft A
