HTP TIMER-DIG Installation Instructions page 4

TIMER-DIG
HTP part number:
Digital Timer
ON TIME: from 0,5s to 99 s
OFF TIME: from 0,5min to 99min
Technical data
Product type
Supply Voltage
Max.Current
Current consumption
Switch holding voltage
Inrush current
Duty cycle
Switch life
Repeat accuracy
Operating temperature range
Design standard
Protection class
Connection
Earth h.
OFF time
ON time
Indicators
Flat Gasket
Fixing screw
Housing material
Housing colour
HIGH TECH PRODUCTS s.r.l
Via Grazia Deledda, 20 - 24040 - Lallio (BG) ITALY
Tel.+39.035.692509 - Fax.+39.035.203291 - http://www.webhtp.com - info@webhtp.eu
Digital timer
24...240V AC/DC
1A
4mA max
400V max
10A for 10ms
100% ED
8
3x10
±0.01%
-10°C...+50°C
VDE 0110-1/89
IP65 assembled
DIN43650/A/ISO4400
h.12
From 0min to 9.5min., step 0.5min.
From 10min. to 99min., step 1min.
From 0s. - 9.5 s., step 0.5 s.
From 10s. to 99s., step 1 s.
GREEN LED: OFF phase
RED LED: ON phase
NBR
M3X51,5mm
ABS V0
Black
