FS Cubers
English
ISO 9001
ISO 14001
Call: +44 (0)843 216 8800
Fax: +44 (0)843 216 4700
www.fosterrefrigerator.co.uk
By Appointment to
Her Majesty Queen Elizabeth II
Suppliers of Commercial Refrigeration
Foster Refrigerator, King's Lynn
Foster Refrigerator
Oldmedow Road
King's Lynn
Norfolk, PE30 4JU
United Kingdom
A division of ITW Ltd
Email:support@foster-uk.com
Advertisement
Table of Contents
Related Manuals for Foster FS Series
Summary of Contents for Foster FS Series
- Page 1 By Appointment to Her Majesty Queen Elizabeth II Suppliers of Commercial Refrigeration Foster Refrigerator, King’s Lynn FS Cubers English Foster Refrigerator Oldmedow Road King’s Lynn Norfolk, PE30 4JU United Kingdom A division of ITW Ltd ISO 9001 ISO 14001 Call: +44 (0)843 216 8800 Fax: +44 (0)843 216 4700 Email:support@foster-uk.com...
-
Page 2: Climate Class
• The gas in the system is under pressure and may explode if heated. Electrical safety Foster Refrigerator recommends that the equipment is electrically connected via a Residual Current Device; such as a Residual Current Circuit Breaker (RCCB) type socket, or through a Residual Current Circuit Breaker with Overload Protection (RCBO) supplied circuit. -
Page 3: General Safety
English General safety Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance. Keep all ventilation openings in the appliance or in the structure of a built in unit clear of any obstructions. The appliance is air tight when the door is closed therefore under no circumstances should any living body be stored or ‘locked in’... -
Page 4: Locating The Appliance
English Locating the appliance Max 32˚C ( 90˚F) Mi n 10˚C (50˚F) Max 0,5 M Pa (5bar) Mi n 0,1 MP a (1bar) Install the machine so that the ventilation of the cooling unit is not obstructed in any way. Avoid installation in a dusty enviroment, this can block the cooling condenser and prevent the machine from operating. -
Page 5: Connecting The Power Supply
English Before starting the machine ensure the following is carried out before starting the unit. Note: A minimum fall of 3% is needed to ensure adequete water flow from the machine. Care should be taken to ensure the drain pipes are not restricted in any way. Connecting the power supply. - Page 6 English Warning: When switching on for the first time or after a prolonged period without use or after cleaning, the tray in the evaporator area must be filled with water (Fig. 2). In order to carry out this operation , lift the door , slide back the curtainand pour clean water into the evaporator tray. For subsequent cycles this will not be necessart.
-
Page 7: Cleaning And Maintenance
English Malfunction In the event of a Fault, it is recommended to disconnect the electrical and water supply Check that the water supply tap is on. Check that power, that the plug is correctly inserted, and that it is switched on and the fuse has not failed Check that there are no abormal vibrations. - Page 8 English Cleaning the ice bin Remove the ice from the ice bin. Clean inside the bin with a sponge dampened with warm water and a little sodium bicarbonate. Rinse with clean water and dry carefully. Cleaning and Sanification The “Self Cleaning” function should be used regualary to remove the limescale build up. Cleaning should be carried out three to four times a year, howeverin areas of very hardwater more fre- quent cleaning maybe necessary Quantites of citric acid to be mixed with water in the bottle to obtain the mix-...
- Page 9 English Starting the wash & sanitation Cycle When handling citric acid and citric acid solution • Turn the machine off. • Remove all ice from the container • Prepare the solution by dissolving the citric acid in warm water (max 40°C), according to the quanities shown on the Previous table.
- Page 10 English Before calling your supplier or enginner please make sure that: a. The plug is located in the socket and the mains power supply is on i.e. is the controller illuminated?. b. Check to see if the unit is in standby. c.
- Page 11 English CODE CM96908583/0 Manuale di Istruzione/Instruction Manual/Notice d’ i n structions/Bedienungsanleitungen MODEL Serie CS / CS Series CMA1001500 CS 20 / CS 25 / CS30 / CS 40 / CS 50 / CS 70 / CS 90 380-415V/3 50Hz 13,0A 247W 220-240V 60Hz1 ,0A1...
- Page 12 UK Head Office Foster Refrigerator Oldmedow Road Kings Lynn Norfolk PE30 4JU a Division of ITW (UK) Ltd Tel: +44 (0)843 216 8833 Fax: +44 (0)843 216 4707 Email: support@foster-uk.com Website: www.fosterrefrigerator.co.uk...
