Getting started

Is your iPod player up-to-date?
Before you start, please check your player Firmware, and make sure it is upgraded to the latest version
available. For iPod firmware visit http://www.apple.com/support/ipod. Renault only guarantees correct
Audio Connection Box functionality with the latest version of firmware.
We recommend setting up playlists on the player for easier navigation of music with the car radio or
steering wheel controls. To do so, please check the corresponding operating guide.
Selection of the media devices connected to the Audio
Connection Box
Devices and priorities selection
Audio Connection Box automatically detects the iPod and the USB memory stick when connected to the
interface and selected as a source.
When both iPod and memory stick are connected USB has priority. To select the iPod, disconnect the
memory stick and AUX in.
When both iPod and AUX IN are connected, AUX IN has priority.To select iPod, disconnect AUX IN.
Warning, if the AUX IN extension remains connected, the iPod will remain paused.
When both USB and AUX IN are connected, to use AUX IN, disconnect the USB memory stick.
Playback control
Select CD Changer as a source on the head unit to start playback of the selected source device. To do
so, select the CD changer as a source by pressing the source button (A) on the radio headunit. Display
shows then TR—CD—
For commands please refer to the following table.
Due to the different charactericteristic of the playback devices (players), there are slight differences in
operation. See device specific sections for details.
Operating instruction
01/07/2009 26/144
Radio Control Functions
The functionality for the Audio Connection Box is defined in the following table and sections.
USB
Press & release <1s Press & hold >2s
A Source -
B
Random*
Nxt
C -
Prev
D - -
E - -
F - -
G - Random*
Playback time
<= 2s > 2s
H
I
*Not available on some radios
When using AUX IN, the volume -/+ and pause are operating
Operating instruction
iPod
Press & release <1s Press & hold >2s
A Source -
B
Playlist1 Random*
C Playlist2 -
D
Playlist3 -
E Playlist4 -
F
Playlist5 -
G
Play all music files Random*
Playback time
<= 2s > 2s
H
I
