BLiNQ Networks Inc.
FW-300i Intelligent LTE Base Station
Installation Guide
Release 1.1
APRIL 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FW-300i and is the answer not in the manual?

Questions and answers

Related Manuals for BLiNQ Networks Inc. FW-300i

Summary of Contents for BLiNQ Networks Inc. FW-300i

  • Page 1 BLiNQ Networks Inc. FW-300i Intelligent LTE Base Station Installation Guide Release 1.1 APRIL 2019...
  • Page 2 BLiNQ Networks Inc. FW-300i System Installation Guide Release 1.1 Revision History Date Release Issue Reason for Issue January 8, 2019 First Release April 30, 2019 Amendment to Page 45 & 46 Contact Information: BLiNQ Networks (CCARI) 140 Renfrew Drive, Suite 205...

  • Page 3: Preface

    All specifications are subject to change without notice. IMPORTANT NOTE This installation guide contains information for the FW-300i Intelligent LTE Base Station. Installation should only be done by licensed and bonded installer/technician.

  • Page 4: Table Of Contents

    Recommended Torque Values ......................22 8.2. Installing Power Supply Kit (Optional) ..................... 22 8.3. FW-300i Unit Installation ......................... 24 8.3.1. Installing Pole Mount ....................... 24 8.3.2. Attaching FW-300i Mounting Assembly onto Pole Mount ............26 Confidential - Restricted Use and Duplication Page 4...
  • Page 5 BLiNQ Networks Inc. FW-300i System Installation Guide Release 1.1 8.3.3. Mounting onto a Wall ......................31 8.4. Cables ............................... 31 8.4.1. Grounding and Lightning Protection ..................32 8.4.2. Installing the Grounding Cable ....................33 8.4.3. Installing DC Surge Protection ....................34 8.4.4.

  • Page 6: Figures

    Figure 1.1 Two FW-300i Mounted on a Pole ....................8 Figure 1.2 FW-300i (Back and Front Respectively) ..................10 Figure 1.3 Connectors on the Bottom of the FW-300i ................... 10 Figure 4.1 FW-300i Casing Labels ........................14 Figure 5.1 FW-300i with Mounting Bracket ....................16 Figure 5.2 Mounting Assembly ........................
  • Page 7 Figure 8.23 Holes for Socket Head Screws and Washers ................30 Figure 8.24 Socket Head Screws and Washers Attached ................31 Figure 8.25 Connectors at the Bottom of the FW-300i Unit................31 Figure 8.26 FW-300i with Grounding Lug ...................... 33 Figure 8.27 DC Surge Protector Pole Mounting Kit ..................

  • Page 8: System Description

    42, 43, 46 and 48 (Citizens Broadband Radio Service (CBRS)). With a distinctive feature set and integration level, the FW-300i brings an ideal solution to an “install anywhere” micro-base transceiver station (micro-BTS) that fully serves private networks, fixed wireless access and mobility use cases.

  • Page 9: System Parameters

    UNIVERSAL POLE MOUNT Pole Diameter Supported Up to 6 in. Mechanical Downtilt 0 degree, 5 degrees, 10 degrees Number of Units Up to two FW-300i units can be attached to the mount Confidential - Restricted Use and Duplication Page 9...

  • Page 10: System Enclosure And Connectivity

    1.2. System Enclosure and Connectivity The enclosure for the FW-300i is a rugged IP67 casing, supplied with a mounting bracket that has vertical tilt capabilities to mount the unit on towers, poles and building side walls. The IP67 casing protects the unit against dust and is capable of withstanding water immersion up to one meter for thirty minutes.

  • Page 11: Flowchart: Installation Process Overview

    BLiNQ Networks Inc. FW-300i System Installation Guide Release 1.1 2. Flowchart: Installation Process Overview To get started quickly, follow the process below. For more details, click on the chapter/section title. Important Unpack the Site Trouble- Installation Safety & Start Installation...

  • Page 12: Checklist

    During installation, review and perform all the steps on this checklist (in the given order). This checklist is meant for the person who performs the FW-300i installation. Tip: To make sure you complete all the tasks, detach or print this checklist and use it as a job aid.

  • Page 13: Important Safety And Service Notices

    4.2. Important Service and Warranty Information Keep all product information for future reference. Refer all repairs to qualified service personnel. Do not remove the covers or modify any part of the FW-300i system, as this action will void the warranty.

  • Page 14: Overvoltage (Lightning/Surge) Protection

    Release 1.1  Record the MAC address for future reference when provisioning the system Figure 4.1 FW-300i Casing Labels 4.3. Overvoltage (Lightning/Surge) Protection A qualified professional installer must install the wireless equipment. The installer must follow local and national codes for electrical grounding and safety.
  • Page 15 FW-300i System Installation Guide Release 1.1 The FW-300i system is designed with consideration for resistance to the effects of lightning on the access point electronics. When installing a lightning/surge arrestor for your system installation, observe the following general industry practices: ...

  • Page 16: What Is In The Box

    BLiNQ Networks Inc. FW-300i System Installation Guide Release 1.1 5. What Is In The Box ITEM PART NO. FW-300i with Mounting Bracket BMA00075 with BQF00164 Mounting Assembly BMA00081 Washers 1/4in. BQH00159 Socket Head Cap Screws 1/4in.-20, 5/8in.L* BQH00160 Washers 3/8in.

  • Page 17: Items For Power Kit Installation

    BLiNQ Networks Inc. FW-300i System Installation Guide Release 1.1 5.1. Items for Power Kit Installation ITEM PART NO. Universal AC/DC Power Kit UNV-ACDC-PWR AC Plug (North America) BQM00104 AC Plug (Europe) BQM00131 10m AC Cable (18 AWG) BCA00012 Figure 5.5 Universal AC/DC Power Kit Figure 5.6...

  • Page 18: Optional Add-Ons

    BLiNQ Networks Inc. FW-300i System Installation Guide Release 1.1 Figure 5.10 Spacers Figure 5.9 Bracket Plates Figure 5.12 Short U-Bolts Figure 5.11 Long U-Bolts 5.3. Optional Add-Ons ITEM PART NO. DC Extension Kit BMA00105 Littelfuse Surge Protection Device (N.America) LSP05G120S...

  • Page 19: Site Preparation

    A. Determine how and where the power source is coming from. B. Decide/determine if the FW-300i unit is going to be powered by AC or DC power source. If you are powering by an AC source, BLiNQ Networks Inc. provides a 10m extension cable along with the FW-300i unit.

  • Page 20: Pole Installation Preparation

    BLiNQ Networks Inc. FW-300i System Installation Guide Release 1.1 6.3. Pole Installation Preparation The diameter of the pole needs to be measured to determine which U-bolt will be suitable for mount installation.  IF THE DIAMETER OF THE POLE IS LESS THAN 2.5in.

  • Page 21: Installation Requirements

    BLiNQ Networks Inc. FW-300i System Installation Guide Release 1.1 7. Installation Requirements 7.1. Installation Tools Required The following table lists all the screws, bolts and nuts that you might encounter during installation. Please prepare the necessary tool(s) for each item.

  • Page 22: Installation

    To attach the power supply kit onto FW-300i follow these steps: 1. Place the power supply bracket on the back of the FW-300i unit, in the lower center position. Align the two holes so that they are centered with the holes on the back of the module enclosure.

  • Page 23: Figure 8.2 Threading Screws Into Mounting Holes

    Release 1.1 3. Thread, by hand, each of the screw into the mounting holes. Ensure that the holes on the mounting bracket and the holes on the back of the FW-300i unit are aligned. Figure 8.2 Threading Screws into Mounting Holes 4.

  • Page 24: Fw-300I Unit Installation

    FW-300i System Installation Guide Release 1.1 8.3. FW-300i Unit Installation It is recommended that you:  Pre-configure units in the warehouse then deploy. Please refer to the FW-300i User Guide for configuration instructions.  Record Serial number, MAC, location for each radio 8.3.1.

  • Page 25: Figure 8.6 Align The Plates With The Pole In The Middle

    BLiNQ Networks Inc. FW-300i System Installation Guide Release 1.1 4. Assemble the plates onto the pole as shown in the following figures. Align the plates with the pole in between them, making sure that the U-bolts fit right through the second plate.

  • Page 26: Attaching Fw-300I Mounting Assembly Onto Pole Mount

    Spacers (#BQF00165) Figure 8.10 Bracket Plates Installed with Spacers 8.3.2. Attaching FW-300i Mounting Assembly onto Pole Mount  FOR POLES SMALLER THAN 2.5in.: Slide the mounting assembly (#BMA00081) onto the U-bolts as shown below. The U-bolts should go through the holes that are circled out in red.

  • Page 27: Figure 8.13 Holes For Straight Bolts On Bracket Plates

    BLiNQ Networks Inc. FW-300i System Installation Guide Release 1.1  FOR LARGER POLES (diameter 2.5in to 6in) Slide the mounting assembly (#BMA00081) onto the straight bolts as shown with the red arrows below. The bolts should go through the holes that are circled out in red.

  • Page 28: Figure 8.16 Washers & Torque Nuts Tightened Onto Lower U-Bolt

    BLiNQ Networks Inc. FW-300i System Installation Guide Release 1.1 Figure 8.16 Washers & Torque nuts Tightened onto Lower U-Bolt Figure 8.17 Mounting Assembly on Straight Bolts (without and with cover)  HORIZONTAL RAILING ORIENTATION This universal mounting kit can also be installed on horizontal railings. The installation steps are the same as the vertical pole installation.

  • Page 29: Figure 8.19 Holes For Straight Bolts On Bracket Plates

    Release 1.1  DOUBLE FW-300I UNITS ORIENTATION This mounting kit is also designed to allow up to two FW-300i units to be mounted at the same time. To install double FW-300i units on a vertical pole, follow all the steps listed in 8.3.1 Installing...

  • Page 30: Figure 8.22 Align The Bracket To Hook Onto The Rod Of The Mount

    Figure 8.22 Align the Bracket to hook onto the Rod of the Mount  Use six pairs of socket head screws and washers provided to attach the FW-300i to the mounting assembly. (see Figure 8.23 and Figure 8.24) Figure 8.23...

  • Page 31: Mounting Onto A Wall

    Socket Head Screws and Washers Attached 8.3.3. Mounting onto a Wall The swinging bracket has four wall-mounting holes that you can use to mount the FW-300i unit directly onto a wall. For wall installation, please contact BLiNQ Networks Customer Support for more information.

  • Page 32: Grounding And Lightning Protection

    8.4.1. Grounding and Lightning Protection Ensure that you externally ground the FW-300i system. Two grounding screws with a two-hole lug are provided on the side of the unit enclosure for this purpose. Connect the ground lug to the main ground to safeguard against possible lightning strikes.

  • Page 33: Installing The Grounding Cable

    2. Use a socket wrench, and the unit’s two hex bolts and locking washers, to connect the two-hole grounding lug to the FW-300i. Figure 8.26 FW-300i with Grounding Lug shows the location of the lug on the unit (do not over tighten).

  • Page 34: Installing Dc Surge Protection

    BLiNQ Networks Inc. FW-300i System Installation Guide Release 1.1 8.4.3. Installing DC Surge Protection BLiNQ Networks recommends the installation of the DC Surge Protector that is listed here. Depending on your installation, you may also need the DC Surge Protector pole mounting kit to aid in the installation of the recommended DC surge protection.

  • Page 35: Figure 8.29 Inside The Dc Lightning/Surge Protector

    To install the DC lightning/surge protector, follow these general steps: 1. Mount the protection device as close to the FW-300i as possible. Mount the unit with the strain reliefs facing the ground, as shown in Figure 8.31, “Wiring of Lightning/Surge Arrestor”.

  • Page 36: Figure 8.30 Lightning/Surge Arrestor Connection Close Up View

    BLiNQ Networks Inc. FW-300i System Installation Guide Release 1.1 3. Thread the incoming DC power cable through the left hand strain relief on the bottom of the unit. Strip back the cable jacket and wire insulation, as needed, using wire strippers. Position the positive and negative wires in the SURGE + and SURGE –...

  • Page 37: Installing The Ac Surge Protection

    BLiNQ Networks Inc. FW-300i System Installation Guide Release 1.1 7. Use a grounding standoff to connect grounding wires of the appropriate gauge (minimum of 6 AWG), between the module, the arrestor unit and a solid Earth ground (See Figure 8.32 Grounding the Lightning/Surge Arrestor”...

  • Page 38: Figure 8.34 Ac Surge Protection Device Installation (North America)

    BLiNQ Networks Inc. FW-300i System Installation Guide Release 1.1 If you are using the BLiNQ AC surge protector, you also need a NEMA 4X-type weatherproof enclosure to complete the installation.  Lightning/surge protectors MUST be grounded to work properly and may only be connected and installed by a qualified electrician.

  • Page 39: Figure 8.35 Wiring For A Series Connection

    If needed, consult Figure 8.35, “Wiring for a series connection” above for more information. 6. When connections are secure, close up the NEMA 4X-type weatherproof enclosure. 7. After you restore AC power, verify that the AC surge protector is working by observing that the FW-300i unit LED is ON.

  • Page 40: Power Cables

    The FW-300i is protected against an inadvertent reverse polarity connection. Ensure that the DC power supply is not under-rated and that it is capable of meeting the power requirement of Table 1 FW-300i System Parameters under various temperature and solar loading conditions.

  • Page 41: Dc Extension Cable Preparation (Optional)

    8.5.4. DC Extension Cable Preparation (Optional) You can order the DC Extension Kit (#BMA00105) from BLiNQ Networks if you need to pull your own cable to power the FW-300i. It comes with a Female DC Connector and a Male DC Connector (see figure below).

  • Page 42: Cable Management

    Finally, you can slide Part A into Part B and tighten them together. USING UNIVERSAL AC/DC KIT  If you are using AC to power up the FW-300i Unit, you will need to use the Universal AC/DC Kit provided in the box. ...

  • Page 43: Verifying Basic Installation

    Release 1.1 8.7. Verifying Basic Installation On connection of DC power to the FW-300i, verify its operational state by checking the LED located on the base of the unit. As the FW-300i starts up, the LED runs through the states shown in the figure below.

  • Page 44: Troubleshooting

    Ethernet port on unit faulty replacement Confirm that there is no physical impedance GPS sync failure above the FW-300i that would prevent GPS lock No RF transmission Confirm routing from FW-300i to the EPC and No network connectivity with any firewall rules that could prevent...

  • Page 45: Appendix Ablinq Wireless Devices And Rf Safety/Les Appareils Sans Fil Blinq Et La Sécurité Rf

    When the FW-300i system is operational, maintain a distance of at least 1.1 metre (43.3 inches) from the FW-300i antennas.  Do not install the FW-300i system in a location where it is possible for people to stand or walk inadvertently in front of an antenna. Antenna Statement: The antenna used for this transmitter must be installed to provide a separation distance of at least 1.1...
  • Page 46 Lorsque le système FW-300i est opérationnel, maintenir une distance d'au moins 1.1 mètre (43.3 pouces) à partir des antennes du FW-300i.  Ne pas installer le système FW-300i dans un endroit où il est possible pour les gens de se tenir debout ou de marcher en face d'une antenne. Déclaration d’antenne: L'antenne utilisée pour cet émetteur doit être installé...

  • Page 47: Equipment Compliance

    BLiNQ Networks Inc. FW-300i System Installation Guide Release 1.1 Equipment Compliance A.1.1 Federal Communications Commission (FCC) Notices This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 48: Appendix B List Of Acronyms

    BLiNQ Networks Inc. FW-300i System Installation Guide Release 1.1 Appendix B List of Acronyms ACRONYM MEANING Alternating Current American Wire Gauge Ampere Base Transceiver Station CAT5e Category 5 Enhanced Cable CAT6 Category 6 UTP (Unshielded Twisted Pair) Cable CBRS Citizens Broadband Radio Service...
