Blichmann Fermenator Operation, Assembly, Maintenance

Hide thumbs

Advertisement

Quick Links

Download this manual
Fermenator
Operation, Assembly, Maintenance
Congratulations on your purchase, and thank you for selecting the Fermenator™
stainless conical fermentor from Blichmann Engineering™. We are confident that
it will provide you years of service and many gallons of outstanding beer. This
manual will familiarize you with the assembly of the product.
PLEASE READ AND THOROUGHLY UNDERSTAND THIS MANUAL PRIOR TO USE
WARNING:
Sections labeled "Warning" can lead to serious injury or death if not followed. Please thoroughly read these sections
and understand them completely before use. If you do not understand them or have any questions, contact your
retailer or Blichmann Engineering (www.BlichmannEngineering.com) before use.
CAUTION:
Sections labeled "Caution" can lead to equipment damage or unsatisfactory performance of the equipment. Please
read these sections thoroughly. If you have any questions, contact your retailer or Blichmann Engineering
(www.BlichmannEngineering.com) before use.
IMPORTANT:
Sections labeled "Important" should specifically be followed to ensure satisfactory results with the product.
ABOUT THIS MANUAL
This manual is for the F3-7, 14.5, and 27 gallon tri-clamp models and optional leg extensions, casters and blow-off assembly. If you purchased
the optional 42 gallon modular extension for the 27 gallon model, or the complete 42 gallon model, you will have received a supplemental manual
with the extension. This manual is broken down into the following sections:
Assembly: Proper assembly procedures to ensure reliable, safe, leak-free operation of your Fermenator™. Be sure to read the sanitizing
section before the first use your Fermenator™ since most parts are sanitized before assembly. We recommend an initial assembly
to familiarize you with the process prior to your first use.
Sanitation: Steps to properly sanitize your fermentor before each use.
Operation: Techniques to get the most out of your fermentor.
Storage & Maintenance: Get years of service by properly maintaining and storing your fermentor.
Fermenator™
© Blichmann Engineering, LLC 2019
™
IMPORTANT INFORMATION
FOR IMPORTANT SAFETY INFORMATION!
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Fermenator and is the answer not in the manual?

Questions and answers

Related Manuals for Blichmann Fermenator

Summary of Contents for Blichmann Fermenator

  • Page 1 This manual is broken down into the following sections: Assembly: Proper assembly procedures to ensure reliable, safe, leak-free operation of your Fermenator™. Be sure to read the sanitizing section before the first use your Fermenator™ since most parts are sanitized before assembly. We recommend an initial assembly to familiarize you with the process prior to your first use.
  • Page 2 QuickConnect 1/2” Straight Please check your box to make sure you have received all parts. NOTE: Some parts will be partially assembled to protect them during shipment. Fermenator ™ © Blichmann Engineering, LLC 2019 For replacement parts, visit: blichmannengineering.com/genuine-replacement-parts...
  • Page 3 ASSEMBLY NOTE: We recommend a trial assembly of your new Fermenator™ before using it to ferment so you are familiar with the procedures and are sure you have all the parts. When you are ready to use the fermentor for an actual brewing session, read the sanitizing procedures before assembling your Fermenator™...
  • Page 4 WARNING: Failure to correctly install and tighten the lid clamp can cause the lid to blow off during pressurization resulting in serious injury or death! Please contact your Authorized Fermenator™ Distributor or Blichmann Engineering™ (www.BlichmannEngineering.com) if you have any questions about proper assembly. Do not operate the unit until you are certain that you understand the proper installation procedure.
  • Page 5 NOTE: It is not necessary to install the 90 degree street elbow on the bottom dump assembly when using the leg extension kit (Figure 11). This will allow the trub and yeast to flow more freely from the dump valve. FIGURE 13 FIGURE 11 FIGURE 12 FIGURE 14 Fermenator ™ © Blichmann Engineering, LLC 2019 For replacement parts, visit: blichmannengineering.com/genuine-replacement-parts...
  • Page 6 Insert the large carriage bolts through the bracket and into the hole in the caster. Place a lock washer and nut on the bolt and finger tighten as shown in Figure 16. Invert your Fermenator™ and place on a soft surface to prevent scratching the lip.
  • Page 7 Place the U-shaped seal over the edge of the lid as shown in Figure 21. One side of the seal has a small bead running the length of the seal. The bead side of the seal must face the lip of the tank to seal properly. Bead FIGURE 21 Fermenator ™ © Blichmann Engineering, LLC 2019 For replacement parts, visit: blichmannengineering.com/genuine-replacement-parts...
  • Page 8 If you are unable to resolve a leak problem please re-read the fitting assembly instruction thoroughly taking special note of the location of the o-rings. If you are still experiencing a leak, contact Blichmann Engineering™ as this is not normal.

  • Page 9: Operation

    OPERATION The Fermenator™ has been designed to fit in a large refrigerator, and about any chest or upright freezer. If you plan to use it in a freezer or refrigerator, the CO2 gas from fermentation should be vented through the door or wall of the refrigerator. For primary fermentation, it is highly recommended that you use a blow-off tube (not included).
  • Page 10 Then slowly rotate the racking arm assembly downward as in Figure 26-27, stopping when you see a yeast pick-up, then turn it back a bit to keep from picking up additional yeast. Fermenator ™ © Blichmann Engineering, LLC 2019 For replacement parts, visit: blichmannengineering.com/genuine-replacement-parts...
  • Page 11 Wine Makers: The Fermenator™ is an outstanding vessel in which to ferment wine. The sealing system is far superior to wine tanks and is completely impervious to oxygen. Most stainless wine fermenting tanks have a loose fitting lid for primary fermentation (to vent gas) and a floating lid for secondary fermentation (to prevent oxygen infiltration).

  • Page 12: Maintenance

    The Fermenator™ always maintains a 100% positive seal for pressure and vacuum so a floating lid is not necessary. The blanket of CO₂ on the surface of the wine from fermentation will protect the wine from oxidation. After complete fermentation has been verified remove the airlock and stopper and replace with a stopper with no hole (not included).
  • Page 13 3. This warranty does not cover, and in no event shall Blichmann Engineering be liable for, travel, lodging, or any other expense incurred due to manufacturing defects in material and workmanship, or any other reason.
