- Page 1 Air Conditioners Technical Data H i g h C O P, r o u n d f l o w c a s s e t t e E E D E N 1 2 - 1 0 0 FCQHG-F...
-
Page 2: Table Of Contents
• Indoor Unit • High COP, round flow cassette • FCQHG-F TABLE OF CONTENTS FCQHG-F Features ............. 2 Specifications . -
Page 3: Features
• Indoor Unit • High COP, round flow cassette • FCQHG-F Features U n i o o r H G - I n d F C Q • User friendly remote control with contemporary design • Easy setup: clear graphical user interface for advanced menu settings •... -
Page 4: Specifications
• Indoor Unit • High COP, round flow cassette • FCQHG-F Specifications 2-1 Technical Specifications FCQHG71FEVB FCQHG100FEVB FCQHG125FEVB FCQHG140FEVB Casing Material Galvanised steel plate Dimensions Unit Height/Width/ 288/840/840 Depth Packed unit Height/Width/ 300/880/880 Depth Weight Unit Packed unit Decoration panel... -
Page 5: Electrical Specifications
Standard Accessories : Washer for hanger bracket; Standard Accessories : Clamp for drain hose; Standard Accessories : Drain hose; Standard Accessories : Installation manual; Standard Accessories : Operation manual; 2-2 Electrical Specifications FCQHG71FEVB FCQHG100FEVB FCQHG125FEVB FCQHG140FEVB Power supply Name Phase... -
Page 6: Safety Device Settings
• Indoor Unit • High COP, round flow cassette • FCQHG-F Safety device settings 3 - 1 Safety Device Settings ® • Split - Sky Air • Indoor Unit... -
Page 7: Options
• Indoor Unit • High COP, round flow cassette • FCQHG-F Options 4 - 1 Options ® • Split - Sky Air • Indoor Unit... -
Page 8: Dimensional Drawings
• Indoor Unit • High COP, round flow cassette • FCQHG-F Dimensional drawings 5 - 1 Dimensional Drawings ® • Split - Sky Air • Indoor Unit... -
Page 9: Dimensional Drawings With Accessories
• Indoor Unit • High COP, round flow cassette • FCQHG-F Dimensional drawings 5 - 2 Dimensional Drawings with Accessories ® • Split - Sky Air • Indoor Unit... -
Page 10: Centre Of Gravity
• Indoor Unit • High COP, round flow cassette • FCQHG-F Centre of gravity 6 - 1 Centre of Gravity ∼ ® • Split - Sky Air • Indoor Unit... -
Page 11: Piping Diagrams
• Indoor Unit • High COP, round flow cassette • FCQHG-F Piping diagrams 7 - 1 Piping Diagrams ® • Split - Sky Air • Indoor Unit... -
Page 12: Wiring Diagrams
• Indoor Unit • High COP, round flow cassette • FCQHG-F Wiring diagrams 8 - 1 Wiring Diagrams - Single Phase • ® • Split - Sky Air • Indoor Unit... -
Page 13: External Connection Diagrams
• Indoor Unit • High COP, round flow cassette • FCQHG-F External connection diagrams 9 - 1 External Connection Diagrams ∼ ∼ ∼ ∼ ® • Split - Sky Air • Indoor Unit... -
Page 14: Sound Data
• Indoor Unit • High COP, round flow cassette • FCQHG-F Sound data 10 - 1 Sound Pressure Spectrum ® • Split - Sky Air • Indoor Unit... - Page 15 • Indoor Unit • High COP, round flow cassette • FCQHG-F Sound data 10 - 1 Sound Pressure Spectrum ® • Split - Sky Air • Indoor Unit...
-
Page 16: Air Flow Patterns
• Indoor Unit • High COP, round flow cassette • FCQHG-F Air flow patterns 11 - 1 Air Flow Pattern - Cooling ® • Split - Sky Air • Indoor Unit... - Page 17 • Indoor Unit • High COP, round flow cassette • FCQHG-F Air flow patterns 11 - 1 Air Flow Pattern - Cooling ® • Split - Sky Air • Indoor Unit...
- Page 18 • Indoor Unit • High COP, round flow cassette • FCQHG-F Air flow patterns 11 - 1 Air Flow Pattern - Cooling ® • Split - Sky Air • Indoor Unit...
- Page 19 • Indoor Unit • High COP, round flow cassette • FCQHG-F Air flow patterns 11 - 1 Air Flow Pattern - Cooling ® • Split - Sky Air • Indoor Unit...
-
Page 20: Air Flow Pattern - Heating
• Indoor Unit • High COP, round flow cassette • FCQHG-F Air flow patterns 11 - 2 Air Flow Pattern - Heating ® • Split - Sky Air • Indoor Unit... - Page 21 • Indoor Unit • High COP, round flow cassette • FCQHG-F Air flow patterns 11 - 2 Air Flow Pattern - Heating ® • Split - Sky Air • Indoor Unit...
- Page 22 • Indoor Unit • High COP, round flow cassette • FCQHG-F Air flow patterns 11 - 2 Air Flow Pattern - Heating ® • Split - Sky Air • Indoor Unit...
- Page 23 • Indoor Unit • High COP, round flow cassette • FCQHG-F Air flow patterns 11 - 2 Air Flow Pattern - Heating ® • Split - Sky Air • Indoor Unit...
- Page 24 EEDEN1 2 - 1 0 0 leaflet. All content is copyrighted by Daikin Europe N.V. Naamloze Vennootschap - Zandvoordestraat 300, B-8400 Oostende - Belgium - www.daikin.eu - BE 0412 120 336 - RPR Oostende...
