5 Mechanical Specifications & Drawings
Table 5.1: Mechanical Specifications
Specifications
Length
Width
Thickness
Area (total aperture)
Weight
Fire Rating
Operating Temperature
Figure 5.1 Mechanical Drawing for FS Series 3 PV Modules
FS Series 3 PV Module User Guide—North America | Page 9 of 13
FS Series 3 PV Module
1200 mm
600 mm
6.8 mm
0.72 m
2
12 kg
Class B (Class A Spread of Flame)
-40°C to +85°C
47.25 in
23.63 in
0.27 in
7.75 ft
2
26.5 lbs
PD-5-200-03 NA | REV 2.1 | 02771_UG_NA_24OCT12
