Fini ROTAR PLUS 20 Manual

TABLE OF CONTENTS

Safety indications .............................................................................. 2
Installation ......................................................................................... 4
Specifications .................................................................................... 5
Settings and controls ........................................................................ 6
Control functions ............................................................................... 8
Operation .......................................................................................... 9
Start-up … ......................................................................................... 9
Maintenance ................................................................................... 10
Trouble-shooting ............................................................................. 13
Wiring diagram ................................................................................ 14
OUTFIT
Check outfit carefully. Later claims for missing parts will not be accepted.
The following accessories are supplied with the compressor:
no. 1 line cock
no. 1 Teflon tape
no. 1 delivery tube
no. 4 anti-vibration elements
no. 1 door key
no. 1 user’s guide
CONDITION OF THE MACHINE WHEN SUPPLIED
Every compressor is shop tested and delivered ready to be installed and to be set at work.
The oil used is SHELL CORENA D.
WARRANTY
The Manufacturer guarantees their products for manufacturing or material defects for 12 months from their delivery
date.
NOTE: Warranty terms are extended as follows only to piston pumping units:
- 18 months for models belonging to “PROFESSIONAL” line,
- 24 months for models belonging to “HEAVY DUTY” line,
- Machines belonging to “ROTAR” line are guaranteed for 3,000 operating hours (as shown by the hour counter)
but limited to 12 months maximum from their delivery date. The above warranty period is extended to 24 months with
no hour limit to the screw pumping unit and the electronic controller.
d) Electric part and parts subject to wear are not covered by this warranty.
e) Any repairs and/or servicing under warranty can be carried out only by Authorized Service Centers and the
Manufacturers.
f) Products can be delivered to the Manufacturer for servicing purposes only after prior authorization by the very
Manufacturer. The Manufacturer shall decide at their discretion whether authorization can be granted or require an
Authorized Service Center to take on servicing.
In any case, products shall be delivered free of any charge and will be returned to the Customer on ex-factory basis.
g) This warranty covers free-of-charge repairs or replacement of those machine parts, which have been acknowledged
as faulty by our authorized technicians.
h) This Warranty becomes null and void in case of accidental damages due to negligence, incorrect or improper
use and installation or in case of use and installation, which do not comply with the instructions given in the Instruction
Manual as well as in case of changes or repairs carried out by non-authorized personnel. All defective parts, which are
replaced under warranty, are collected by the Authorized Service Center.
i) This warranty does not cover any repairs or compensation for transport damages (to or from the Authorized
Service Center).
k) Any compensations for damages caused to objects or injuries caused to people due to improper use of the
purchased compressor are excluded from this warranty.
l) Machines under warranty can be serviced against purchase documents bearing the purchasing date only if the
Purchaser has met all contract and payment requirements.
m) This Warranty is the only one which is acknowledged by the Manufacturer. The issue of any other verbal or
written warranty is not allowed. Also, no changes to the terms of this Warranty are allowed,
Any dispute shall be settled by the Court of Bologna.
GENERAL INFORMATION
Rotar Plus 20-25 Easytronic - Cod.197AA2702 - Edition 00 01/2004
