Block Up Converter Systems
6700/6900 series
S A T E L L I T E C O M M U N I C A T I O N S
U S E R G U I D E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6700 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Codan 6700 Series

Summary of Contents for Codan 6700 Series

  • Page 1 Block Up Converter Systems 6700/6900 series S A T E L L I T E C O M M U N I C A T I O N S U S E R G U I D E...
  • Page 2 No part of this guide may be reproduced, transcribed or translated into any language or transmitted in any form whatsoever without the prior written consent of Codan Limited. © Copyright 2006 Codan Limited. Codan part number 15-44027-EN Issue 1, October 2006...

  • Page 3: Table Of Contents

    Table of contents CODAN Introduction Overview Introduction..........4 BUC system configuration .
  • Page 4 Table of contents Mounting the redundancy controller ......42 Installing separate transmit and receive RF waveguide switches ..42 Installing the combined RF waveguide/coaxial switch (C-Band transmit/receive systems only).
  • Page 5 Table of contents Using the BUC fault diagnosis charts ......85 Test procedures ......... . . 97 Finding faults in the redundancy switching equipment .
  • Page 6 Table of contents This page has been left blank intentionally. Block Up Converter Systems 6700/6900 series User Guide...
  • Page 7 List of figures CODAN Figure 1: BUC with L-Band modem and LNB ....5 Figure 2: BUC with L-Band modem, external in-line PSU, and LNB ........6...
  • Page 8 List of figures Figure 26: RF waveguide switch fault diagnosis chart ..104 Figure 27: Remote controller supply fault diagnosis chart ..110 Figure 28: Segments of the BUC model number ....111 Figure 29: Segments of the redundancy system number.
  • Page 9 List of tables CODAN Table 1: Transmit frequency bands for C-Band and Ku-Band BUCs....... . . 7 Table 2: Frequency ranges for C-Band BUCs (Standard) .
  • Page 10 List of tables Table 29: Electrical safety symbols ......125 Table 30: Earth symbols ....... .126 Table 31: Warning labels .
  • Page 11 Introduction CODAN This user guide is for installation technicians and operators of the Block Up Converter 6700/6900 series. This guide contains the following sections: Section 1 Overview—general description of the BUC Section 2 Installation—installation instructions specific to the BUC and redundancy systems...
  • Page 12 Introduction This page has been left blank intentionally. Block Up Converter Systems 6700/6900 series User Guide...
  • Page 13 Overview CODAN This section contains the following topics: Introduction (4) BUC system configuration (5) BUC (7) LNB (15) Redundancy systems (16) The Remote Controller 6570 and Hand-held Controller 6560 (26) Block Up Converter Systems 6700/6900 series User Guide...

  • Page 14: Introduction

    Overview Introduction The Codan Block Up Converter 6700/6900 series is a high- performance BUC for use in a satellite earth station. The Block Up Converter 6700/6900 series comprises: • a BUC • an LNB • a TRF • accessories The BUC is designed to be mounted on a wide range of earth station antennas.

  • Page 15: Buc System Configuration

    Overview BUC system configuration The BUC may be used in the following configurations: Configuration... See... BUC with L-Band modem and LNB Figure 1 on page 5 BUC with L-Band modem, external Figure 2 on page 6 in-line PSU, and LNB Figure 1: BUC with L-Band modem and LNB Block Up Converter Systems 6700/6900 series User Guide...

  • Page 16: Figure 2: Buc With L-Band Modem, External In-Line Psu

    Overview Figure 2: BUC with L-Band modem, external in-line PSU, and LNB Block Up Converter Systems 6700/6900 series User Guide...

  • Page 17: Buc

    Overview Transmit frequency bands Table 1: Transmit frequency bands for C-Band and Ku-Band BUCs Frequency band Transmit frequency band (MHz) C-Band Standard 5 850 to 6425 Extended 5 850 to 6725 Ku-Band Standard 14000 to 14500 Extended 13750 to 14500 Frequency conversion plans All 6700/6900 series BUCs are frequency inverting, that is, the higher the RF frequency required, the lower the modem...

  • Page 18: Table 2: Frequency Ranges For C-Band Bucs (Standard)

    Overview Example 1: The LO frequency of your C-Band BUC is set to 7300 MHz (see Table 3 on page 9). If you need an RF frequency of 5975 MHz, then you must set the modem IF frequency to: = 7300 – 5975 = 1325 MHz Example 2: The LO frequency of your Ku-Band BUC is 15450 MHz (see...

  • Page 19: Figure 3: C-Band Frequency Conversion Plan At An Lo

    Overview Table 3: Frequency ranges for C-Band BUCs (Extended) LO frequency Tuning range of Output See... (MHz) L-Band frequency (MHz) (MHz) 7300 950–1450 5850–6350 Figure 3 on page 9 7375 950–1525 5850–6425 Figure 4 on page 10 7600 950–1750 5850–6650 Figure 5 on page 10 7675 950–1750...

  • Page 20: Figure 4: C-Band Frequency Conversion Plan At An Lo Frequency Of 7375 Mhz

    Overview Figure 4: C-Band frequency conversion plan at an LO frequency of 7375 MHz Figure 5: C-Band frequency conversion plan at an LO frequency of 7600 MHz Block Up Converter Systems 6700/6900 series User Guide...

  • Page 21: Figure 6: C-Band Frequency Conversion Plan At An Lo Frequency Of 7675 Mhz

    Overview Figure 6: C-Band frequency conversion plan at an LO frequency of 7675 MHz Ku-Band Figure 7 Figure 8 show the frequency conversion plans for each LO frequency of the Ku-Band BUCs. Table 4: Frequency ranges for Ku-Band BUCs (Standard) LO frequency Tuning range of Output...

  • Page 22: Figure 7: Ku-Band Frequency Conversion Plan For Bucs That Cover The Standard Frequency Band

    Overview Table 5: Frequency ranges for Ku-Band BUCs (Extended) LO frequency Tuning range of Output See... (MHz) L-Band frequency (MHz) (MHz) 15450 950–1450 14000–14500 Figure 7 on page 12 15450 950–1700 13750–14500 Figure 8 on page 13 Figure 7: Ku-Band frequency conversion plan for BUCs that cover the Standard frequency band Block Up Converter Systems 6700/6900 series User Guide...

  • Page 23: Power Supply Options

    Overview Figure 8: Ku-Band frequency conversion plan for BUCs that cover the Extended frequency band Power supply options The power supply option for your BUC is indicated in the model number on the serial number label. For information on how to interpret the model number see page 111, BUC model and redundancy system numbers.
  • Page 24 Overview BUCs that are AC-powered, also draw current NOTE from the DC power input on the IF input cable for remote alarm indication purposes only. Certain BUCs with external DC power connectors may also have auto-sensing circuits, and can be powered from either the external NOTE connector or via the IF INPUT connector.

  • Page 25: Lnb

    Overview The frequency band that is down converted by the LNB is indicated on the model label of the LNB. C-Band The C-Band LNB is supplied for operation on the frequency band 3400 to 4200 MHz. It has an LO frequency of 5150 MHz.

  • Page 26: Redundancy Systems

    Overview Redundancy systems The Codan Redundancy Controller 6586 is used to control two BUCs and two LNBs (when used) in a redundancy system. When a detectable fault occurs in the on-line BUC, and the off-line BUC is serviceable, the redundancy controller switches over the two BUCs.

  • Page 27: The Redundancy Controller

    Overview Redundancy system control You can control and monitor the redundancy switching equipment: • locally, using a Hand-held Controller 6560 connected to the BUC 1 Serial/BUC 2 Serial connectors on the redundancy controller • remotely, using the optional Remote Controller 6570 connected to the Auxiliary I/O connector on the redundancy controller The redundancy controller...

  • Page 28: Figure 9: Control Panel On The Redundancy Controller

    Overview Figure 9: Control panel on the redundancy controller LED indicators The control panel of the redundancy controller has groups of LEDs that indicate the status of the redundancy system and its fuses. The colours and functions of these LEDs are described Table 12 on page Block Up Converter Systems 6700/6900 series User Guide...

  • Page 29: Figure 10: Connector Panel On The Redundancy Controller

    Overview Switches The control panel of the redundancy controller has one switch. The function of this switch is to select the AC input voltage (115 or 230 V AC). Connectors The connector panel is located at the bottom of the redundancy controller.

  • Page 30: How The Redundancy Controller Works

    Overview How the redundancy controller works When you power up the system, the redundancy controller uses the current status of the BUC Switch and LNB Switch (when used) to select the on-line stream. If the redundancy controller detects that the NOTE switches are inconsistent, or cannot be detected, it selects Stream 1.
  • Page 31 Overview BUC faults The redundancy controller uses a PLD to monitor the alarm signals from both BUCs. The BUCs send alarm signals via cables connected to the 14-way BUC 1 Control and BUC 2 Control connectors on the redundancy controller. Red BUC 1/BUC 2 LEDs on the control panel of the redundancy controller indicate that there is a fault with the corresponding BUC or LNB.
  • Page 32 Overview Auxiliary I/O interface of the redundancy controller The Auxiliary I/O interface of the redundancy controller enables you to perform the following functions remotely: • monitor operation of the redundancy switching system using the isolated relay contacts • switch streams using external signals Most of the remote control functions are achieved by grounding the appropriate control signal to 0 V.

  • Page 33: Rf Waveguide Switches

    Overview RF waveguide switches RF waveguide switches control both the receive and transmit RF paths. The switches direct signals for both on-line and off- line BUCs and LNBs (when used). Transmit/receive C-Band systems may use either two RF waveguide switches or one combined RF waveguide/coaxial switch.
  • Page 34 Overview Systems using a combined RF waveguide/coaxial switch (C-Band only) In the receive path, a receive RF waveguide switch directs the received RF from the receive port of the antenna feed to one of the LNBs. In the transmit path, an RF coaxial switch directs the transmitted RF from the on-line BUC to the transmit port of the antenna feed.
  • Page 35 Overview Systems using a single transmit RF waveguide switch (transmit-only) In the transmit path, a single transmit RF waveguide switch directs the transmitted RF from the on-line BUC to the transmit port of the antenna feed. The RF from the off-line BUC is directed into an appropriately-rated termination.

  • Page 36: The Remote Controller 6570 And Hand-Held Controller 6560

    Overview The Remote Controller 6570 and Hand-held Controller 6560 The Remote Controller 6570 provides remote control and monitoring facilities of the BUCs at a convenient indoor location. The remote controller is connected via its BUC Interface connector to the Auxiliary I/O connector on the redundancy controller using the cable supplied.

  • Page 37: Installation

    Installation CODAN This section contains the following topics: Unpacking the equipment (28) Installing the BUC equipment (28) Cable recommendations (32) Serial interfaces (37) Connecting the serial interface (39) Monitor and control interface of the BUC (40) Installing the redundancy system (42)

  • Page 38: Unpacking The Equipment

    Open each box and check for signs of damage to the equipment. If you notice any damage, contact Codan immediately to obtain an RMA. Failure to contact Codan before returning the unit may result in any warranty being void. Installing the BUC equipment All equipment that is mounted outdoors must be adequately weatherproofed.
  • Page 39 Installation TRF and LNB The TRF and LNB are normally mounted directly on the antenna feed structure. The LNB obtains the required +15 to +24 V DC power and, in certain cases, the 10 MHz reference signal from a compatible L-Band modem.
  • Page 40 Installation BUCs that are externally powered from a DC source require appropriate DC power from an external source. See BUC specifications or compare your BUC model number against Table 27 on page 111 for the exact voltage range of your BUC. Certain BUCs with external DC power connectors may also have auto-sensing circuits, and can be powered from either the external...

  • Page 41: Table 8: Pinouts Of The Ac Input Connector

    Installation Table 8: Pinouts of the AC INPUT connector (Amphenol T 3110 000) Description Neutral Not connected Active Protective earth It is recommended that BUCs are installed as close as possible to the antenna feed to minimise losses. Heavier BUCs may need to be mounted further CAUTION down the boom to minimise the mechanical leverage load on the antenna.

  • Page 42: Cable Recommendations

    Installation Cable recommendations Table 9 lists the recommended specifications for IF coaxial cables used in your system. These specifications place restrictions on the maximum length of the transmit IF cable. The limiting factor is most likely the 20 dB maximum cable loss.

  • Page 43: Cable Lengths

    Installation DC loop resistance specification The maximum DC loop resistance is determined by the DC power drawn by a BUC and its minimum operating input voltage. Some BUCs are not powered via the cable, so the DC loop resistance of the IF cable is not a consideration for such BUC installations.

  • Page 44: If Levels

    Installation IF levels The figures and tables in this section show the single carrier IF levels required to achieve rated P1dB output power from the BUC using various types and lengths of IF cables. Your actual IF levels may be different from those shown if you are operating with multiple carriers and you require output back off to control intermodulation product levels.

  • Page 45: Figure 11: If Levels Required For Short Cables

    Installation Using short IF cables Figure 11 shows the IF levels required when using short IF cables such as the following: • 5 m RG223 • 12 m 9914 • 15 m 9913F • 18 m LMR-400 Figure 11: IF levels required for short cables Block Up Converter Systems 6700/6900 series User Guide...

  • Page 46: Figure 12: If Levels Required For Long Cables

    Installation Using long IF cables Figure 12 shows the IF levels required when using long IF cables such as the following: • 34 m RG223 • 80 m 9914 • 100 m 9913F • 120 m LMR-400 Figure 12: IF levels required for long cables Block Up Converter Systems 6700/6900 series User Guide...

  • Page 47: Serial Interfaces

    The fixed data rate and protocol simplifies the connection during installation and commissioning, and enables a PC running a terminal-emulation program to be used to configure the BUC. For information on protocols, contact your Codan representative. The BUC is able to detect the connection of an RS232 interface.

  • Page 48: Rs422/485 Interface

    FSK monitor and control capability. If an appropriate modem is not available, contact your Codan representative to find out what accessories are available to access the FSK interface.

  • Page 49: Connecting The Serial Interface

    Installation Connecting the serial interface To set the operating parameters of the BUC, the BUC must be connected to a terminal (for example, a Hand-held Controller 6560, a Remote Controller 6570, a PC, or an organiser emulating a terminal). The connection may be permanent as part of the installation or temporary for the purpose of setting the operating parameters of the BUC.

  • Page 50: Monitor And Control Interface Of The Buc

    Installation Monitor and control interface of the BUC The monitor and control interface of the BUC provides a relay contact to indicate the fault status of the BUC. See Figure 13 for the pin assignments of the M/C connector. A MIL-C-26482 12-14P connector (for example, MS3116F12-14P) is required to mate with the M/C connector.

  • Page 51: Figure 13: Monitor And Control Interface Of The Buc

    Installation Figure 13: Monitor and control interface of the BUC Block Up Converter Systems 6700/6900 series User Guide...

  • Page 52: Installing The Redundancy System

    Installation Installing the redundancy system Mounting the redundancy controller The redundancy controller has two mounting flanges. Each flange has 10 mounting holes. If you are going to use the mounting kit supplied, fitting instructions are provided in the kit. Mount the redundancy controller upright on or near the antenna structure.
  • Page 53 Installation Connect port 2 of the transmit RF waveguide switch to the transmit flange of the antenna feed using gasket kits and rigid or flexible waveguide as appropriate. If connecting the Ku-Band transmit RF waveguide switch to a waveguide section NOTE that has clearance holes for 6-32 UNC hardware, a waveguide adaptor kit is...
  • Page 54 Installation Receive RF waveguide switch (transmit/receive systems only) To install the receive RF waveguide switch (LNB switch): Fit the TRF (if used) to the receive port of the antenna feed using the appropriate flange kit for C-Band and Ku-Band, selecting the correct gasket. Hold waveguide port 2 of the receive RF waveguide switch against the receive port of the antenna feed or TRF (if fitted).

  • Page 55: Installing The Combined Rf Waveguide/Coaxial Switch (C-Band Transmit/Receive Systems Only)

    Installation If connecting the Ku-Band receive RF waveguide switch to a receive port of the antenna feed that has clearance holes for 6-32 UNC hardware, a waveguide adaptor kit is available. NOTE Spare flange kits are provided with the redundancy package. The universal Ku-Band flange kit contains a selection of flat gaskets and circular cross-section gaskets (both large and small cross-...
  • Page 56 Installation If you want to allow for dry air pressurisation, fit the supplied air nozzle to the blanking plate. If this is not required, fit the M5 screw with seal into the blanking plate. Connect the off-line BUC termination to port 4 of the coaxial section of the switch as shown in the mounting and interconnection drawings.

  • Page 57: Connecting The Power Cables

    Installation Connecting the power cables The redundancy controller is AC mains powered. To connect the power cable to the redundancy controller: Connect the supplied cable to the AC Power Input connector on the redundancy controller. Block Up Converter Systems 6700/6900 series User Guide...

  • Page 58: Connecting The Control Cables

    Installation Connecting the control cables To connect the control cables: Connect the BUC 1 Control connector and the BUC 2 Control connector on the redundancy controller to the corresponding M/C connector on each BUC using the control cables supplied. For high-power BUC systems, connect the BUC 1 Control connector and the BUC 2 Control connector on the redundancy controller to the corresponding M/C connector on each BUC and the corresponding...

  • Page 59: Connecting The If From The Lnbs To The Redundancy Controller

    Installation Connecting the IF from the LNBs to the redundancy controller To connect the IF cables: Connect the corresponding N-type IF output connector on each LNB to the Rx IF Input 1 connector and the Rx IF Input 2 connector on the redundancy controller using the coaxial cable supplied.

  • Page 60: Serial Interfaces Of The Bucs From The Redundancy Controller

    Installation Serial interfaces of the BUCs from the redundancy controller The M/C connector on each BUC includes the serial interface of the BUC. Although the redundancy controller plugs into this connector, the redundancy controller uses relay contacts to communicate with the BUC. You can access the serial interface of each BUC via the 14-way BUC 1 Serial or BUC 2 Serial connector on the redundancy controller.

  • Page 61: Accessing The Auxiliary I/O Interface On The Redundancy Controller

    Installation Accessing the Auxiliary I/O interface on the redundancy controller Remote control and monitoring of the redundancy switching system is accessible via the 19-way Auxiliary I/O connector on the redundancy controller. To use this 19-way connector, you need a 19-way Mil-C-26482 series plug, part number MS3116J14-19P.

  • Page 62: Figure 14: Auxiliary I/O Interface Of The Redundancy Controller

    Installation Figure 14: Auxiliary I/O interface of the redundancy controller BUC 1 BUC 2 Block Up Converter Systems 6700/6900 series User Guide...

  • Page 63: Setting Up The Redundancy Switching Equipment

    Installation Setting up the redundancy switching equipment To set up the redundancy switching equipment: Set the AC voltage selector on the control panel of the redundancy controller to the appropriate voltage for your operating environment. Switch on the modem(s), then switch off the carrier(s). Apply power to the redundancy controller and the BUCs.
  • Page 64 Installation Parameter Menu Setting Serial parity Auxiliary For information on the required serial Serial stop bits Auxiliary parameters for a Remote RS485 Auxiliary Controller 6570 see termination the Hand-held and Serial protocol Auxiliary Remote Controller 6560/6570 User Serial address Auxiliary Guide Serial echo Auxiliary...
  • Page 65 Installation Connecting the remote controller The optional Remote Controller 6570 is connected to the Auxiliary I/O connector on the redundancy controller using a 19-way cable. Before connecting a Remote Controller 6570, you should ensure that the serial address and packet protocol in each BUC has been set up NOTE correctly using a Hand-held Controller 6560, or other serial device such as a PC.
  • Page 66 Installation This page has been left blank intentionally. Block Up Converter Systems 6700/6900 series User Guide...

  • Page 67: Setting Up And Operating The Buc System

    Setting up and operating the BUC system CODAN This section contains the following topics: Switching on the BUC (58) LED indicators (59) Serial interface monitor and control (62) Serial interface commands (63) Switching the redundancy system on and off (76)

  • Page 68: Switching On The Buc

    Setting up and operating the BUC system Switching on the BUC Ensure that the modem provides the correct DC CAUTION voltages to power the particular BUC and LNB models being used. To switch on the BUC: Switch on the modem, and if you have installed an externally-powered BUC, switch on the power to the BUC.

  • Page 69: Led Indicators

    Setting up and operating the BUC system LED indicators There are three LED indicators on the BUC. These LEDs indicate the state of the BUC (see Table 11). Table 11: LED indicators on the BUC and their states State Indicates... Green Power is supplied to the BUC Yellow...

  • Page 70: Table 12: Led Indicators On The Control Panel Of The Redundancy Controller

    Setting up and operating the BUC system The control panel of the redundancy controller has groups of LEDs that indicate the status of the redundancy system and its fuses. Table 12: LED indicators on the control panel of the redundancy controller Colour Indicates...
  • Page 71 Setting up and operating the BUC system Table 12: LED indicators on the control panel of the redundancy controller (cont.) Colour Indicates... Redundancy green Redundancy system and switches are OK Controller Status Redundancy system is faulty or switches are inconsistent Remote green Remote controller fuse OK...

  • Page 72: Serial Interface Monitor And Control

    The commands listed in Table 13 Table 17 are used with common installations. If you have NOTE other requirements for your installation, contact your Codan representative for the facilities and commands available. Block Up Converter Systems 6700/6900 series User Guide...

  • Page 73: Serial Interface Commands

    Setting up and operating the BUC system Serial interface commands This section describes the serial interface commands you can use to set parameters and display information about the BUC. The descriptions given are based on using ASCII protocol. The commands consist of a 3-letter mnemonic and, in some cases, command data.

  • Page 74: Table 13: Help Commands

    Setting up and operating the BUC system Table 13: Help commands Command Function Enter... Data required Help Lists the Help commands. None Help for Set Lists the Set commands and None commands the possible settings. Some settings are dependent on the NOTE model of the BUC, or another setting.

  • Page 75: Table 14: Set Commands

    Setting up and operating the BUC system Table 14: Set commands Command Function Enter... Data required Set transmit Switches transmit on or off STOn n = 0, switches transmit off by controlling the PA of the n = 1, switches transmit on BUC.
  • Page 76 Setting up and operating the BUC system Table 14: Set commands (cont.) Command Function Enter... Data required Sets either the IF or RF SCFn For C-Band Standard and compensation compensation frequency of Extended frequency band frequency the carrier in MHz. BUCs: The BUC determines from LO = 7300 MHz...
  • Page 77 Setting up and operating the BUC system Table 14: Set commands (cont.) Command Function Enter... Data required Set transmit Sets the transmit attenuator STAn n = 0 to 12 dB attenuator of the BUC in dB. Certain firmware versions To minimise the possible allow 4 dB steps, while effects of interference it is other firmware versions...
  • Page 78 Setting up and operating the BUC system Table 14: Set commands (cont.) Command Function Enter... Data required Set burst Sets the burst mode power SBTn n = value within the mode power threshold in dBm. allowable threshold range threshold for your BUC When you set a n = 0, disables burst new burst mode...
  • Page 79 Setting up and operating the BUC system Table 14: Set commands (cont.) Command Function Enter... Data required Set local Sets the LO frequency in SLOn For C-Band Standard oscillator MHz. frequency range BUCs: n = 7300 or 7375 MHz Before you change the LO setting you For C-Band Extended NOTE...
  • Page 80 Setting up and operating the BUC system Table 14: Set commands (cont.) Command Function Enter... Data required Set on line Sets the on-line or off-line SOLn n = 0, forces the selected state of the BUC in a warm BUC off line standby or hot standby n = 1, forces the selected redundant system, that is,...
  • Page 81 Sets the packet protocol used SPPn n = 0, ASCII protocol protocol on the RS422/485 and FSK n = 1, Codan protocol serial interfaces. n = 2, SAbus protocol The packet protocols for these interfaces cannot be set n = 3, Comstream protocol independently.

  • Page 82: Table 15: Output Commands

    Setting up and operating the BUC system Table 15: Output commands Command Function Enter... Data required Output power Displays the RF power None output output of the BUC in dBm. If the output power is less than the lower limit, 0.0 dBm is displayed.

  • Page 83: Table 16: View Commands

    Setting up and operating the BUC system Table 16: View commands Command Function Enter... Data required View system Displays the status and None status parameter settings of the BUC. View Displays the operational data None operational of the BUC. data View fault Displays the fault status of None...

  • Page 84: Table 17: Reset Commands

    Setting up and operating the BUC system Table 17: Reset commands Command Function Enter... Data required Reset Resets the BUC settings to the settings None at powerup (that is, it has the same effect as switching the power off then on again).
  • Page 85 9600 baud 8 bits no parity 1 stop bit unterminated RS422/485 bus packet protocol NDSatcom protocol packet address 1 for Codan 49 for SAbus 1 for Comstream 1 for NDSatcom echo Block Up Converter Systems 6700/6900 series User Guide...

  • Page 86: Switching The Redundancy System On And Off

    Setting up and operating the BUC system Switching the redundancy system on and When you power up the redundancy controller, the redundancy switching system resumes operation using the current state of the switches. You can switch off the redundancy switching system at any time by simply switching off the redundancy controller at the AC mains supply.
  • Page 87 Setting up and operating the BUC system Operating the redundancy system If you are not using the contact closure inputs on the Auxiliary I/O connector, the redundancy controller runs automatically. You can manually switch streams by setting the Online state of a BUC using a Hand-held Controller 6560 or a PC connected to the BUC 1 Serial or BUC 2 Serial connectors, or a Remote Controller 6570 connected to the Auxiliary I/O connector.

  • Page 88: Controlling The Redundancy System

    Setting up and operating the BUC system Controlling the redundancy system For correct operation of the redundancy system, both BUCs must be switched on. To switch on the BUCs: Switch on the modem, and if you have installed an externally-powered BUC system, switch on the power to the BUC.
  • Page 89 Setting up and operating the BUC system Codan recommends that you set the Redundancy mode of both BUCs to Hot standby. This keeps the off-line stream in hot standby ready for immediate NOTE operation. It also enables detection of faults in the power amplifier of the off-line...
  • Page 90 Setting up and operating the BUC system This page has been left blank intentionally. Block Up Converter Systems 6700/6900 series User Guide...

  • Page 91: Maintenance And Fault Finding

    Maintenance and fault finding CODAN This section contains the following topics: Precautions (82) If technical assistance is required... (84) Finding faults in the BUC system (85) Finding faults in the redundancy switching equipment (100) Finding faults in the remote controller (109)

  • Page 92: Precautions

    WARNING circuiting connector pins. Servicing requirements If you find that any module is faulty, contact your Codan representative or Codan customer service staff. Before returning goods to Codan you must obtain an RMA to authorise the return of your goods.

  • Page 93: Table 18: Fuses In The Redundancy Controller

    Maintenance and fault finding Fuses and overcurrent protection in the Redundancy Controller 6586 Table 18 lists the types of fuses on the control panel of the redundancy controller and the device protected. For information on changing fuses see page 102, Replacing fuses in the redundancy controller.

  • Page 94: If Technical Assistance Is Required

    In the Satellite Communications section, click on Product Support. Outside of normal office hours, Codan has Customer Service Engineers on call to provide emergency technical assistance. They will either answer your call immediately or return your call as soon as possible.

  • Page 95: Finding Faults In The Buc System

    Maintenance and fault finding Finding faults in the BUC system The fault finding information provided in this section is designed to locate faulty modules and cables, and to determine if correct operating procedures have been followed. Faults are indicated by the LEDs on the BUC (see Table 11 on page 59).

  • Page 96: Figure 15: Main Buc Fault Diagnosis Chart

    Maintenance and fault finding Figure 15: Main BUC fault diagnosis chart Main BUC fault diagnosis chart Is the See BUC fault PWR LED on the diagnosis chart 1. BUC green? * The FLT LED on earlier- Is the version BUCs may flash red FLT LED on the See BUC fault to indicate the presence of...

  • Page 97: Figure 16: Buc Fault Diagnosis Chart 1

    (Test B)*. cable? Check cable, AC mains and circuit breakers. IF cable BUC faulty. Refer to Codan. Check for DC power at IF power supply both ends of the Tx IF being used? cable (Test A)*. Check for DC power at...

  • Page 98: Figure 17: Buc Fault Diagnosis Chart 2

    Maintenance and fault finding Figure 17: BUC fault diagnosis chart 2 BUC fault diagnosis chart 2 Check faults using VFS command. Check the IF level (Test D)* and the Reset latched Tx Power output power alarm faults using RLF Alarm threshold and adjust command.

  • Page 99: Figure 18: Buc Fault Diagnosis Chart 3

    Maintenance and fault finding Figure 18: BUC fault diagnosis chart 3 BUC fault diagnosis chart 3 See BUC fan fault there a diagnosis chart 1. fan fault? See BUC fault BUC Temp diagnosis chart 4. See BUC fan fault diagnosis chart 1. Block Up Converter Systems 6700/6900 series User Guide...

  • Page 100: Figure 19: Buc Fault Diagnosis Chart 4

    RLF command. Switch on BUC PA using STO1 command. FLT LED BUC faulty. red and PA Refer to Codan. showing a fault? BUC OK. Monitor for recurrence of fault. Block Up Converter Systems 6700/6900 series User Guide...

  • Page 101: Figure 20: Buc Fault Diagnosis Chart 5

    RLF command. Monitor for recurrence of fault. Does BUC have an internal BUC faulty. 10 MHz Refer to Codan. reference? Check for 10 MHz at both ends of the Tx IF cable (Test C)*. Modem, external 10 MHz reference source, or cable faulty.

  • Page 102: Figure 21: Buc Fault Diagnosis Chart 6

    IF cable, or cable faulty. Replace as required. Is the Set the correct transmit transmit attenuator attenuator setting setting using STA correct? command. BUC faulty. * Refer to test Refer to Codan. procedures Block Up Converter Systems 6700/6900 series User Guide...

  • Page 103: Figure 22: Buc Fault Diagnosis Chart 7

    BUC OK. yellow? Reset the setting to default values using RDV command. Is the BUC faulty. Tx LED Refer to Codan. yellow? Set all BUC settings changed by RDV command. BUC OK. Block Up Converter Systems 6700/6900 series User Guide...

  • Page 104: Figure 23: Buc Fan Fault Diagnosis Chart 1

    RLF commands. Check fan fault using VFS command. Is fan fault Fan operation still present? normal. Are fan(s) See BUC fan fault running? diagnosis chart 2. BUC faulty. Refer to Codan. Block Up Converter Systems 6700/6900 series User Guide...

  • Page 105: Figure 24: Buc Fan Fault Diagnosis Chart 2

    Repair/replace fans as necessary. Check for DC power at the fan (Test E)*. Fan faulty. Repair/replace fans as necessary. BUC faulty. * Refer to test Refer to Codan. procedures Block Up Converter Systems 6700/6900 series User Guide...

  • Page 106: Figure 25: Lnb Fault Diagnosis Chart

    Replace as required. Does LNB LNB faulty. have an Replace LNB or internal 10 MHz refer to Codan. reference? Check 10 MHz at both ends of the Rx IF cable (Test C)*. Modem, external 10 MHz reference source, or cable faulty.

  • Page 107: Test Procedures

    Maintenance and fault finding Test procedures Use the following tests in conjunction with the fault finding diagnosis charts. Table 19: Test A Procedure Comment Measure the DC voltage at both ends of For +24 V BUCs, the DC voltage should the transmit IF cable.

  • Page 108: Table 21: Test C

    • 9 to 10.2 V DC, or • 12 V ±1 V DC Refer to your Codan representative for exact specifications for your BUC. Block Up Converter Systems 6700/6900 series User Guide...

  • Page 109: Table 24: Test F

    Maintenance and fault finding Table 24: Test F Procedure Comment Measure the DC voltage at both ends of The DC voltage should be +15 to the receive IF cable. +24 V DC. Block Up Converter Systems 6700/6900 series User Guide...

  • Page 110: Finding Faults In The Redundancy Switching Equipment

    Maintenance and fault finding Finding faults in the redundancy switching equipment A fault in the redundancy switching equipment is likely when a fault in the on-line BUC or high-power BUC system does not cause streams to switch, or you cannot manually switch streams.
  • Page 111 Maintenance and fault finding Faults in the RF waveguide switches Faults in the RF waveguide switches are caused inside the switches or in the switch cables. Such faults are likely if: the BUC Switch or LNB Switch LEDs on the control •...

  • Page 112: Replacing Fuses In The Redundancy Controller

    If the fuse does not blow after reconnecting all cables, the original fuse may have blown because of a temporary power supply surge. If a problem persists, contact your Codan representative for assistance. Block Up Converter Systems 6700/6900 series User Guide...

  • Page 113: Resolving Inconsistent Stream Selections

    Maintenance and fault finding Resolving inconsistent stream selections To resolve inconsistent stream selections: Use serial commands on a PC running terminal- emulating software, a Hand-held Controller 6560, or a Remote Controller 6570 to switch streams remotely (see page 76, Switching between streams).

  • Page 114: Figure 26: Rf Waveguide Switch Fault Diagnosis Chart

    Maintenance and fault finding Figure 26: RF waveguide switch fault diagnosis chart RF waveguide switch fault diagnosis chart Disconnect cable from switch. Select position 1 by manually rotating actuator in switch. Are the resistances and tell-back Switch faulty. contacts consistent with Replace switch.

  • Page 115: Table 25: Resistance Of Coils When The Rf Waveguide

    Maintenance and fault finding Checking the resistance of an RF waveguide switch To check the resistance of an RF waveguide switch: Disconnect the control cable from the RF waveguide switch. Use a multimeter to check the resistance of the coils and tell-back contacts at the connector on the switch.
  • Page 116 If the RF waveguide switch fails to operate correctly, bypass the switch by connecting the LNB or BUC directly to the receive port or transmit port of the antenna feed respectively. Return the RF waveguide switch to Codan for repair. Block Up Converter Systems 6700/6900 series User Guide...

  • Page 117: Finding Faults In The Redundancy Controller

    Do not short circuit the outputs. If 36 to 60 V DC is not present, check the fuses. If the fuses have not blown, the power supply inside the redundancy controller is faulty. Contact your Codan representative for assistance. Disconnecting a faulty BUC...

  • Page 118: Reverting To A Single-Buc Earth Station

    Maintenance and fault finding Reverting to a single-BUC earth station If it is necessary to remove the redundancy controller from the system because it is faulty, you can restore communications by reverting to a basic, single-BUC earth station. You can either leave the RF waveguide switches in place or remove them.

  • Page 119: Finding Faults In The Remote Controller

    Maintenance and fault finding Finding faults in the remote controller The remote controller or its associated cable is faulty if the LEDs on the remote controller are not illuminated, or actions taken on the remote controller are not reflected in the redundancy system.

  • Page 120: Figure 27: Remote Controller Supply Fault Diagnosis Chart

    Remote controller Auxiliary I/O faulty. cable assembly? Is there +12 V between Auxiliary I/O pin U and pin D at cable assembly Auxiliary I/O faulty. connector on 6586? 6586 faulty. Refer to Codan. Block Up Converter Systems 6700/6900 series User Guide...

  • Page 121: Appendix A-Buc Model And Redundancy System Numbers

    Appendix A—BUC model and redundancy system numbers CODAN BUC model numbers The model number of your BUC indicates various options available in your BUC. Figure 28: Segments of the BUC model number Table 27: Definition of the BUC model number...

  • Page 122: Numbers

    BUC model and redundancy system numbers Table 27: Definition of the BUC model number (cont.) Option Description Code Frequency band Standard: 5.850 to 6.425 GHz for C-Band 14.0 to 14.5 GHz for Ku-Band Extended: 5.850 to 6.725 GHz for C-Band 13.75 to 14.50 GHz for Ku-Band Power supply 24 V DC...

  • Page 123: Figure 29: Segments Of The Redundancy System Number

    BUC model and redundancy system numbers Redundancy system numbers The number of your redundancy system indicates various options available in your system. Figure 29: Segments of the redundancy system number Table 28: Definition of the redundancy system number Option Description Code Frequency band C-Band...

  • Page 124: Numbers

    BUC model and redundancy system numbers Table 28: Definition of the redundancy system number (cont.) Option Description Code BUC model and LBUC C-Band: 5 W, 10 W, 20 W power group Ku-Band: 4 W, 8 W, 16 W MBUC C-Band: 25 W, 40 W Ku-Band: 16 W C-Band:...

  • Page 125: Appendix B-Example Outputs For The View Commands

    Transmit On (RS485) Off (0) Burst Pwr Thresh 19.0 Transmit On (FSK) Serial I/face 9600,8,N,1,T Transmit Default Off (0) Packet Protocol Codan (1) Compensation Freq Packet Address IF Comp Freq Red'cy -Mode Non (0) LO Freq 7375 -On/Off Line On (1)

  • Page 126: Commands

    Example outputs for the View commands View fault status -------------Fault Status------------- Current Latched Tx Power Alarm BUC Temp Internal Red'cy Controller -------------------------------------- If there is no fan in the BUC, the current and NOTE latched status for the fan shows a dash. View identity and configuration data --------------------------Identity Data---------------------------- Model No...

  • Page 127: Commands

    Example outputs for the View commands View protocol data -----------------------Protocol Data-------------------- Protocol 0 ASCII Protocol 1 Codan Address Range 1..126 Protocol 2 SAbus Address Range 49..111 Protocol 3 Comstream Address Range 1..31 Protocol 4 NDSatcom Address Range 1..15 ------------------------------------------------------- View build standard data...

  • Page 128: Commands

    Example outputs for the View commands This page has been left blank intentionally. Block Up Converter Systems 6700/6900 series User Guide...
