Feature
PowerView Model PV25 Display
Yellow Fault/Warning Lamp
Red Fault/Shutdown Lamp
Request Regeneration Button
Inhibit Regeneration Button
Throttle Increment Button
Throttle Decrement Button
Key Switch
Section 30
2013-12-17
To order call 1-800-548-1191 or visit www.partdeal.com - info@partdeal.com
For additional information on the PV25 display,
refer to "00-02-0839 - PV25-Installation and Operations"
manual.
Indicates when a warning is present via CAN
communications.
Indicates when a shutdown is present via CAN
communications.
Allows the operator to send a request to engine to perform
an active regeneration.
Allows the operator to send a message to the engine to
inhibit the engine from performing an active regeneration.
Allows the operator to throttle engine up via CAN
communication utilizing TSC1 capabilities. Takes operator
to 'Desired Engine Speed' screen when pressed.
(Increment "Bump" = 25RPM, default adjustable;
Ramp Up "Hold" = 200RPM, default adjustable)
Allows the operator to throttle engine down via CAN
communication utilizing TSC1 capabilities. Takes operator
to 'Desired Engine Speed' screen when pressed.
(Decrement "Bump" = 25RPM, default adjustable;
Ramp Down "Hold" = 200RPM, default adjustable)
Operator initiated cranking of engine via turning the key to
crank state.
