Lucent PacketStar 23N41 User Manual

Psax enhanced router module for the packetstar psax multiservice media gateways
Hide thumbs

Advertisement

Quick Links

Download this manual
®
PacketStar
PSAX Enhanced Router Module
User Guide
Model 23N41
®
for the PacketStar
PSAX Multiservice Media Gateways
Issue 1, March 2004
System Software Release 9.1.0
®
®
Navis
AQueView
EMS Release 9.1.0
Doc. No.: 255-700-614

Advertisement

loading
Need help?

Need help?

Do you have a question about the PacketStar 23N41 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lucent PacketStar 23N41

Summary of Contents for Lucent PacketStar 23N41

  • Page 1 ® PacketStar PSAX Enhanced Router Module User Guide Model 23N41 ® for the PacketStar PSAX Multiservice Media Gateways Issue 1, March 2004 System Software Release 9.1.0 ® ® Navis AQueView EMS Release 9.1.0 Doc. No.: 255-700-614...
  • Page 2 Copyright © 2004 by Lucent Technologies. All rights reserved. For trademark, regulatory compliance, and related legal information, see the "Legal Notices, Safety, and Regulatory Information" section.
  • Page 3 This material is protected by the copyright laws of the United States and other countries. It may not be reproduced, distributed, or altered in any fash- ion by any entity (either internal or external to Lucent Technologies), except in accordance with applicable agreements, contracts or licensing, without the express written consent of the originating organization and the business management owner of the material.
  • Page 4 CAUTION: Modifying or tampering with PSAX chassis components may void your warranty. Any modification to this equipment not expressly authorized by Lucent Technologies may void your granted authority to operate such equipment. CAUTION: Shipping the chassis with removable I/O, server, or CPU modules installed may cause damage to the chassis and the modules.
  • Page 5 EU-regulativer CE-mærkning Lucent Technologies erklærer hermed at PacketStar PSAX 1000 (-48 V dc og 220 v vekselstrøm), PSAX 1250 (-48 V dc og 220 v vekselstrøm), PSAX 2300, og PSAX 4500 Multiservice Media Gateways, inkl. det udstyr der findes behandlet i denne dokumentation, er i overensstemmelse med følgende EU-...
  • Page 6 Euroopan unionin sääntelystandardi CE-merkintä Lucent Technologies vakuuttaa täten, että PacketStar PSAX 1000 (-48 V dc ja 220 V vaihtovirtaa), PSAX 1250 (-48 V dc ja 220 V vaihtovirtaa), PSAX 2300, ja PSAX 4500 Media Gatewayt ja tässä julkaisussa dokumentoidut laitteet, täyttävät seuraavien neuvoston direktiivien keskeiset vaatimukset ja asiaank-...
  • Page 7 Norme réglementaire de l’Union européenne Label CE Lucent Technologies déclare en ceci que les passerelles de média multiser- vices PacketStar PSAX 1000 (-48 V c.c. et 220 V ca), PSAX 1250 (-48 V c.c. et 220 V ca), PSAX 2300, et PSAX 4500 sont conformes aux exigences essen- tielles et autres dispositions pertinentes des directives suivantes du Conseil: •...
  • Page 8 Norm van de Europese Unie CE-markering Lucent Technologies verklaart hierbij dat de PacketStar PSAX 1000 (-48 V dc en 220V wisselstroom), PSAX 1250 (-48 V dc en 220V wisselstroom), PSAX 2300, en PSAX 4500 Multiservice Media Gateways voldoen aan de essentiële vereisten en andere relevante bepalingen van de volgende Rich-...
  • Page 9 • Elektromagnetisk kompatibilitet (EMC) 89/336/EEC • Radioutrustning och telekommunikationskopplingsutrustning 1999/5/EC Lucent PacketStar PSAX Multiservice Media Gateways, som är placerad i EEA (European Economic Area), är avsedd för att anslutas till E1, E3, STM-1 och STM-4c nätverk. Europarådets Konformitetsdeklarationer kan ses på bild- skärm eller skrivas ut på...
  • Page 10 Legal Notices, Safety, and Regulatory Information Regulatory Statements ® PSAX Enhanced Router Module User Guide, Issue 1 Release 9.1.0 PacketStar 255-700-614...

  • Page 11: Table Of Contents

    Related Reading ............1-1 Lucent Technologies Information Products ....... . .1-1 Product Information Library .

  • Page 12: Table Of Contents

    Contents Text Types Used in This Document ........1-4 Icons and Symbols .

  • Page 13: Table Of Contents

    Contents Static IP Routing Overview .........2-12 IP Route Table .

  • Page 14: Table Of Contents

    Contents Viewing ARP Entries ..........3-51 Setting the Values for ARP .

  • Page 15: Table Of Contents

    Contents Provisioning In-band Management Connections .......4-32 Provisioning In-band Management Connections with the Enhanced Router ..4-33 In-band Management Configuration .

  • Page 16: Table Of Contents

    Contents Deleting Class Rule Configurations ........5-38 Viewing and Updating RIP Interfaces .

  • Page 17: Table Of Contents

    Contents Provisioning Bridge Connections Using an I/O Module with the Enhanced Router Module ............6-20 Ethernet Module Configuration .

  • Page 18: Table Of Contents

    List of Figures Field Description Table Example ..........1-6 Main Menu Help Window .

  • Page 19: Table Of Contents

    List of Figures 3-26 Enhanced Router Class Rule Configuration Window .......3-60 3-27 Save Configuration [Modified] (Before Saving) .

  • Page 20: Table Of Contents

    List of Figures 5-22 Enhanced Router RIP Interface Configuration Window (UPDATE) ....5-40 5-23 Enhanced Router RIP2 Interface Statistics Window ....... 5-43 5-24 Delete Entry Confirmation Window .

  • Page 21: Table Of Contents

    List of Tables Text Conventions ............1-5 Command Description Table Example .

  • Page 22: Table Of Contents

    List of Tables ERM-to-ATM VCC SPVC Traffic Parameters Window Field Descriptions ....4-51 4-10 Enhanced Router PPP Config Template Table Window Field Descriptions ....4-54 4-11 Enhanced Router PPP Config Template Configuration Window Field Descriptions .

  • Page 23: Getting Started

    Lucent Technologies Information Products Product Information Library To install, operate, and configure your PSAX system and I/O and server mod- ules, read the PSAX publications provided on your Lucent Technologies PacketStar PSAX Multiservice Media Gateways Products, Product Information Library CD-ROM. ®...

  • Page 24: Printed Documents

    Bell Laboratories. Our legacy and our spirit of innovation allow Lucent to provide our custom- ers with the tools needed to communicate effectively, any time and any- where, and to integrate the latest technologies into real-life solutions that help make business work.

  • Page 25: Psax 1250 Multiservice Media Gateway

    Chapter 1 Getting Started About the PacketStar PSAX Product Family When it is functioning in a redundant operating mode and after it has experi- enced a single-point failure, the PSAX 1000 system provides up to 630 Mbps of ATM cell bus capacity. The total ATM cell bus capacity of the system may also be scaled to provide nonblocking, nonredundant chassis bandwidths beyond 630 Mbps.

  • Page 26: Psax 4500 Multiservice Media Gateway

    Chapter 1 Getting Started Text Conventions PSAX 4500 Multiservice Media Gateway The PacketStar PSAX 4500 Multiservice Media Gateway provides carrier-class reliability, with an unmatched range of service capabilities, end-to-end traffic prioritization, “any-service, any-channel” flexibility, and breakthrough voice technology. Ideal for the central office or a large enterprise multiservice media gateway, the PSAX 4500 system provides highly reliable network access for time-division multiplex voice, frame relay, 10/100BASE-T Ether- net, and ATM data applications.

  • Page 27: Icons And Symbols

    Chapter 1 Getting Started Text Conventions Table 1-1. Text Conventions Appearance How it is used SANS SERIF BOLD, ALL CAPS Labels on module panels, chassis faceplates, or other hardware Message text displayed on the user interface window Fixed-width normal • Button name (GUI interface) or command name Serif bold (console interface) on the user interface window •...

  • Page 28: Use Of Field Description Tables

    Chapter 1 Getting Started Text Conventions Table 1-2. Command Description Table Example Command Function Bring All Interfaces Brings the out-of-service configured interfaces to in-service status. Into Service Note: In GR-303 configuration, it is critical to bring into service only those channels actively configured with DS1 ports. Use of Field Description Tables For all illustrations for configuration windows in this guide for both the PSAX system console interface and the AQueView EMS, the field description...

  • Page 29: System Responses To Selecting Options, Fields, Or Commands

    Chapter 1 Getting Started Text Conventions ~ Use the alternate keys, K=UP, H=LEFT, L=RIGHT to highlight (reverse video image) the option name, field name, or command you want to select and press Enter. (You can optionally redefine these alternate keys from the User Options window, which is accessible from the Console Interface Main Menu window.) ~ To quickly select a command, you can also simultaneously press Ctrl and...

  • Page 30: Help Information

    Chapter 1 Getting Started Help Information Help Information The Help windows are accessible from any window in the PSAX system con- sole interface. To access the Help windows, press the ? (Question Mark) key on any window. In addition to the Help windows, the Console Interface win- dows display contextual help in the information line at the bottom of each window.

  • Page 31: Technical Support

    4 To exit Help and return to the current console window, press the Enter key. Technical Support If you experience a problem with the Enhanced Router module module, refer to the Lucent Technologies Product Warranty Registration Information, which accompanied your shipment, for instructions on obtaining support in your area. Before You Begin...
  • Page 32 Chapter 1 Getting Started Comments on This Guide ® PSAX Enhanced Router Module User Guide, Issue 1 Release 9.1.0 PacketStar 1-10 255-700-614...

  • Page 33: Functional Description

    Module Description Functional Description The Enhanced Router module is the premier IP routing platform for the PacketStar PSAX Multiservice Media Gateway systems. In addition to support- ing existing PSAX multiservice interworking capabilities, the module pro- vides routing, aggregation, and adaptation capabilities, and supports SPVC connection options.

  • Page 34: Routing And Arp Features

    Chapter 2 Module Description Feature Summary ~ In Single-Instance mode, the module operates as a monolithic router. This is the default mode of operation. ~ In Multi-Instance mode, a limited set of features will be supported on up to eight individual routing instances (VPNs). Note: The Multi-Instance mode is not supported on the Enhanced Router module in Release 9.1.0.

  • Page 35: Vpn Features

    Chapter 2 Module Description Feature Summary • The module supports inverse ARP over ATM and frame relay (receives and responds to requests only). • The module supports up to 2,048 IP interfaces, which can be statically shared (scaled) across VPNs. VPN Features •...

  • Page 36: Software Features

    Chapter 2 Module Description Software Features • SPVC connections: 100 Software Features Traffic Flow The Enhanced Router module is an edge device that borders an IP network and an ATM core network. Ingress IP traffic (Figure 2-2) from a given inter- face is forwarded at the edge device.

  • Page 37: Ip Application In The Multiservice Media Gateway

    Chapter 2 Module Description Software Features Note: The Multi-Instance mode is not supported on the Enhanced Router module in Release 9.1.0. Do not perform configurations with the Enhanced Router module in Multi-Instance mode. IP Application in the Multiservice Media Gateway An IP interface consists of an IP address and an IP network mask.

  • Page 38: Enhanced Router Database Conversion

    Chapter 2 Module Description Software Features Enhanced Router module mode to match existing slot configuration. As such, when an Enhanced Router module is inserted, if necessary, it may immediately reboot as it switches operating modes. Note: The Multi-Instance mode is not supported on the Enhanced Router module in Release 9.1.0.

  • Page 39: Capacity Of Classification Tables

    Chapter 2 Module Description Software Features Classification is done on the ingress, and is specified at the connection level. Each connection in an IP interface is configured with the range of CoS values that it supports. For example, VCC 1= CoS 1–3, VCC 2= CoS 4–5, VCC 3= CoS 6.

  • Page 40: Ingress Diffserv Mapping Table

    Chapter 2 Module Description Software Features Ingress DiffServ The six bits in DiffServ are mapped into CoS values of 1–6. Mapping Table Virtual Routing Another key differentiator using the Enhanced Router module in Multi-VPN mode is the virtual router aspect of the module (see Figure 2-3). The virtual routing capability arises from its ability to form groupings of IP interfaces that can combine to act as separate IP networks relative to some other grouping of IP interfaces on the same device.

  • Page 41: Unnumbered Interfaces

    Chapter 2 Module Description Software Features Existing Console FR Connections Partitioned In-Band into Interfaces Management 192.001.001.001 255.255.255.000 Virtual 192.001.002.001 Router 255.255.255.000 192.001.003.001 255.255.255.000 145.121.215.001 Virtual 255.255.000.000 Router 145.122.215.001 Existing In-Band Management 255.255.000.000 145.123.215.001 192.001.004.001 255.255.000.000 255.255.255.000 192.001.005.001 An IP interface can be 255.255.255.000 assigned a VC that ATM Connections Partitioned...

  • Page 42: Unnumbered Interfaces Example

    Chapter 2 Module Description Software Features bered interfaces. The feature works when static routes are used without a routing protocol (such as RIP) are used. Unnumbered interfaces are not sup- ported on Ethernet interfaces. Router C 20.1.1.2 20.1.1.1 10.1.1.1 10.1.1.2 VPN 1 VPN 2 Router B...

  • Page 43: Rip Version 2 Features

    Chapter 2 Module Description Software Features RIP Version 2 Features RIP version 2 adds additional functionality to RIP version 1, such as external route tags, subnet masks, next hop router addresses, authentication, and multicasting. Note: RIP is intended to operate as an interior gateway protocol within a relatively small network with a longest path of 15 hops.

  • Page 44: Static Routing

    Chapter 2 Module Description Software Features ARP functionality is supported for all interface types that are configured to carry bridged Ethernet traffic. You may specify a MAC address or allow a MAC address to be randomly selected from an available pool pre-pro- grammed into the Enhanced Router module.

  • Page 45: Ip Filtering

    Chapter 2 Module Description Software Features A router connected to a network must be able to identify which interface is to be used to reach every other connected end system. Routers near the cen- ter of a network generally have very large routing tables, those near the edges have smaller tables.

  • Page 46: Enhanced Router Module Applications

    Chapter 2 Module Description Enhanced Router Module Applications In the example shown in Figure 2-6, if a packet matches Rule 1, then it is dropped. The Enhanced Router module module will not check any other rules in this case, because Rule 1 matched the packet. If a packet does not match Rule 1, then the module checks Rule 5.

  • Page 47: Qos Transport Application

    Chapter 2 Module Description Enhanced Router Module Applications 1xEVDO Base Station 1xEVDO PSAX 4500/2300 with Base Station Enhanced Router Module 1xEVDO IP over Ethernet Base Station Figure 2-7. 1xEVDO Backhaul Application QoS Transport Application In Figure 2-8, IP packets are transported by ATM VCC connections. VBR-RT Enhanced Router Module...

  • Page 48: Hardware Features

    Chapter 2 Module Description Hardware Features PSAX 1000 with IP PBX Enhanced Router Module PSAX 4500 with IP PBX Network Enhanced Router Module IP PBX PSAX 1000 with Enhanced Router Module Figure 2-9. IP PBX Backhaul with QoS Transport Application Hardware Features The Enhanced Router module has the following hardware features: •...

  • Page 49: Performance And Power Specifications

    Chapter 2 Module Description Hardware Features Table 2-2. Physical Hardware Specifications (Continued) Specification Description 60 meters (197 feet) below sea level to 4,000 meters Operating altitude range for all chassis (13,123 feet) above sea level -40° to 70° C (-40° to 158° F) Storage temperature range for all chassis 0% to 90% noncondensing...

  • Page 50: Led Indicators For The Enhanced Router Module

    Chapter 2 Module Description Hardware Features Table 2-4. LED Indicators for the Enhanced Router Module Module Status Lights Not lit Lights Briefly FAIL (red) Initial Module is func- Module is not functioning power-on tioning properly properly ACTIVE Initial No configured Module is functioning (green) power-on...

  • Page 51: Overview Of This Chapter

    Configuring VPNs Using the Console Interface Overview of This Chapter This chapter describes how to do the following: ~ Configure various components of the Enhanced Router module: • VPNs • IP interfaces • IP filter rules • static IP routes •...

  • Page 52: Hierarchy Of The Enhanced Router Configuration

    Chapter 3 Configuring VPNs Using the Console Interface Configuring the Module Hierarchy of the Enhanced Router Configuration You must configure the Enhanced Router module in a hierarchy of three major tasks (see Figure 3-1): 1. Configure a VPN (see ”Configuring VPNs” on page 3-5). 2.

  • Page 53: Console Interface Main Menu (Equipment Configuration Selected)

    Chapter 3 Configuring VPNs Using the Console Interface Configuring the Module Begin 1 On the Console Interface Main Menu window (see Figure 3-2), select the Equipment Configuration option. Figure 3-2. Console Interface Main Menu (Equipment Configuration Selected) The Equipment Configuration window is displayed (see Figure 3-3). Figure 3-3.

  • Page 54: Enhanced Router Vpn Table Window

    Chapter 3 Configuring VPNs Using the Console Interface Configuring the Module 2 On the Equipment Configuration window, select an Enhanced Router module. The Enhanced Router VPN Table window is displayed (see Figure 3-4). Figure 3-4. Enhanced Router VPN Table Window The commands in this window have the following functions: Command Function...

  • Page 55: Configuring Vpns

    Chapter 3 Configuring VPNs Using the Console Interface Configuring VPNs Table 3-1. ERM VPN Table Window Field Descriptions Field Name Field Values Description VPN No Default: N/A Displays the VPN number on the Enhanced Router module. [EOT] denotes the end of the Range: 1–8 table.

  • Page 56: Enhanced Router Vpn Configuration Window

    Chapter 3 Configuring VPNs Using the Console Interface Configuring VPNs The Enhanced Router VPN Configuration window is displayed (see Figure 3-5). Figure 3-5. Enhanced Router VPN Configuration Window The value OutOfService is displayed in the [Oper Status] and [Admin Status] fields. The commands in this window have the following functions: Command Function...
  • Page 57 Chapter 3 Configuring VPNs Using the Console Interface Configuring VPNs Command Function View IP Filter Table Displays the Enhanced Router Filter Rule Table Table win- dow. Note: You cannot use this command until Enabled is selected in the IP Filter Support field. [View OSPF Config Screen] Displays the Enhanced Router OSPF General Configuration window.

  • Page 58: Enhanced Router Vpn Configuration Window Field Descriptions

    Chapter 3 Configuring VPNs Using the Console Interface Configuring VPNs 5 Repeat the steps in the “Accessing the VPN Configuration Table” proce- dure to configure additional VPNs. Table 3-2. Enhanced Router VPN Configuration Window Field Descriptions Field Name Field Values Description VPN No Default: 0...
  • Page 59 Chapter 3 Configuring VPNs Using the Console Interface Configuring VPNs Table 3-2. Enhanced Router VPN Configuration Window Field Descriptions (Continued) Field Name Field Values Description FILTER Default: (Blank) Indicates whether IP filtering feature is supported on this VPN. You cannot view or configure the IP Range: N/A Filter Rule configuration parameters unless this Format: Blank (unse-...
  • Page 60 Chapter 3 Configuring VPNs Using the Console Interface Configuring VPNs Table 3-2. Enhanced Router VPN Configuration Window Field Descriptions (Continued) Field Name Field Values Description RIP Redistribute Default: Enabled Indicates whether the local interface routes on Local this module are to be distributed or not during a Range: N/A RIP update in the RIP advertisement on this VPN.

  • Page 61: Bringing Vpns Into And Out Of Service

    Chapter 3 Configuring VPNs Using the Console Interface Configuring VPNs Table 3-2. Enhanced Router VPN Configuration Window Field Descriptions (Continued) Field Name Field Values Description [Oper Status] Default: OutOfSer- Displays whether the VPN is fully operational or vice not. Range: N/A Format: Predefined Inservice Indicates that all IP interfaces and connections on...

  • Page 62: Viewing Icmp Statistics

    Chapter 3 Configuring VPNs Using the Console Interface Configuring VPNs Deleting a VPN that is configured in Single-Instance mode will cause the module to reboot. Perform the following procedure to delete a VPN. CAUTION: Before you perform the following procedure, be aware that if you delete a VPN, all of the interfaces and connections created under the VPN are also removed with the VPN.

  • Page 63: Enhanced Router Vpn Icmp Statistics Window

    Chapter 3 Configuring VPNs Using the Console Interface Configuring VPNs The Enhanced Router VPN ICMP Statistics window is displayed (see Figure 3-6). Figure 3-6. Enhanced Router VPN ICMP Statistics Window The commands in this window have the following functions: Command Function Continuous Update Updates the values constantly.
  • Page 64 Chapter 3 Configuring VPNs Using the Console Interface Configuring VPNs Table 3-3. Enhanced Router VPN ICMP Statistics Window Field Descriptions (Continued) Field Name Field Values Description Errored Messages Default: 0 Displays the number of errors in received ICMP messages on this VPN. Range: N/A Format: Numeric Unreach Messages...

  • Page 65: Viewing Ip Statistics

    Chapter 3 Configuring VPNs Using the Console Interface Configuring VPNs Table 3-3. Enhanced Router VPN ICMP Statistics Window Field Descriptions (Continued) Field Name Field Values Description Errored Messages Default: 0 Displays the number of errors in received ICMP messages on this VPN. Range: N/A Format: Numeric Unreach Messages...

  • Page 66: Enhanced Router Vpn Ip Statistics Window

    Chapter 3 Configuring VPNs Using the Console Interface Configuring VPNs The Enhanced Router VPN IP Statistics window is displayed (see Figure 3-7). Figure 3-7. Enhanced Router VPN IP Statistics Window The commands in this window have the following functions: Command Function Continuous Update Updates the values constantly.

  • Page 67: Erm Vpn Ip Statistics Window Field Descriptions

    Chapter 3 Configuring VPNs Using the Console Interface Configuring VPNs Table 3-4. ERM VPN IP Statistics Window Field Descriptions Field Name Field Values Description In Total Datagrams Default: 0 Displays the total number of input datagrams received from interfaces on this VPN, including Range: N/A those received in error.
  • Page 68 Chapter 3 Configuring VPNs Using the Console Interface Configuring VPNs Table 3-4. ERM VPN IP Statistics Window Field Descriptions (Continued) Field Name Field Values Description Out Total Data- Default: 0 Displays the total number of IP datagrams which grams local IP user-protocols (including ICMP) supplied Range: N/A to IP in requests for transmission.

  • Page 69: Configuring Ip Interfaces

    Chapter 3 Configuring VPNs Using the Console Interface Configuring IP Interfaces Configuring IP Interfaces An IP interface identifies one of the VPN’s locally attached networks, and associates an IP interface address with the network. By creating an IP inter- face, a route is automatically created in the IP route table of the VPN. When configuring an IP interface, it is possible to assign connections corresponding to a specific traffic treatment.

  • Page 70: Enhanced Router Ip Interface Configuration Window

    Chapter 3 Configuring VPNs Using the Console Interface Configuring IP Interfaces Command Function Displays the first page of the table. Bottom Displays the last page of the table. PgUp Displays the previous page of the table. PgDown Displays the next page of the table. Add an IP Interface Displays the Enhanced Router IP Interface Configuration window.

  • Page 71: Enhanced Router Ip Interface Configuration Window Field Descriptions

    Chapter 3 Configuring VPNs Using the Console Interface Configuring IP Interfaces Command Function Take IP Interface Out of Ser- Takes the in-service IP network interface vice to out-of-service status. The value OutOf- Service is displayed in the [Admin Status] field. View Connection Table Displays the Enhanced Router Connection Screen...
  • Page 72 Chapter 3 Configuring VPNs Using the Console Interface Configuring IP Interfaces Table 3-5. Enhanced Router IP Interface Configuration Window Field Descriptions (Continued) Field Name Field Values Description IP Interface Addr Default: 000.000.000. Indicates the IP address of the enterprise network to which this IP interface is attached.
  • Page 73 Chapter 3 Configuring VPNs Using the Console Interface Configuring IP Interfaces Table 3-5. Enhanced Router IP Interface Configuration Window Field Descriptions (Continued) Field Name Field Values Description UnNumbered Intf Default: Disabled Indicates whether the unnumbered IP interface Supp type is supported on this IP interface. Range: N/A Format: Predefined Disabled...
  • Page 74 Chapter 3 Configuring VPNs Using the Console Interface Configuring IP Interfaces Table 3-5. Enhanced Router IP Interface Configuration Window Field Descriptions (Continued) Field Name Field Values Description [Class Tb Id] Default: 0 Displays the applied class of service table index number when the [Fixed Classification] field is Range: 1–6 set to No.

  • Page 75: Class Of Service Configuration Examples

    Chapter 3 Configuring VPNs Using the Console Interface Configuring IP Interfaces Table 3-5. Enhanced Router IP Interface Configuration Window Field Descriptions (Continued) Field Name Field Values Description [Intf Type] Default: Other Displays the type of IP interface on this VPN, dis- tinguished according to the physical/link proto- Range: N/A col(s) immediately below the network layer in...

  • Page 76: Configuring Unnumbered Interfaces

    Chapter 3 Configuring VPNs Using the Console Interface Configuring IP Interfaces Fixed Classification—Yes Fixed Color—3 [Default Color]—1 [Classification Tb Id]—01 [Modify QoS on Egress]—No Example 3. if Classification Supp..Enabled Fixed Classification—No [Fixed Color]—1 Default Color—1 Classification Tb Id—05 [Modify QoS on Egress]—No Configuring Unnumbered Interfaces To configure an IP interface as an unnumbered interface, perform the steps in the section, “Setting the Values for IP Interfaces,”...

  • Page 77: Enhanced Router Interface Statistics Window

    Chapter 3 Configuring VPNs Using the Console Interface Configuring IP Interfaces The Enhanced Router Interface Statistics window is displayed (see Figure 3-10). Figure 3-10. Enhanced Router Interface Statistics Window The commands in this window have the following functions: Command Function Continuous Update Updates the values constantly.

  • Page 78: Deleting An Ip Interface

    Chapter 3 Configuring VPNs Using the Console Interface Configuring IP Interfaces Table 3-6. Enhanced Router Interface Statistics Window Field Descriptions (Continued) Field Name Field Value Description In Errored Pkts Default: 0 Indicates the number of inbound packets that contained errors preventing them from being Range: N/A deliverable to a higher-layer protocol.

  • Page 79: Viewing And Configuring Dhcp Servers

    Chapter 3 Configuring VPNs Using the Console Interface Viewing and Configuring DHCP Servers Viewing and Configuring DHCP Servers To configure and/or view a DHCP server, perform the following procedure. Note: You must enable DHCP on the Enhanced Router VPN Configura- tion window before you can proceed.

  • Page 80: Enhanced Router Dhcp Server Configuration Window

    Chapter 3 Configuring VPNs Using the Console Interface Viewing and Configuring DHCP Servers Table 3-7. Enhanced Router DHCP Server Table Window Field Descriptions Field Name Field Values Description [Req Pkts In] Default: 0 Displays the total number of request packets received by the primary and backup DHCP serv- Range: N/A ers.

  • Page 81: Enhanced Router Dhcp Server Configuration Window Field Descriptions

    Chapter 3 Configuring VPNs Using the Console Interface Viewing and Configuring DHCP Servers 3 Select the values for the fields on this window from the values given in Table 3-8. 4 To apply the values for the fields, select the Add DHCP Servers com- mand.

  • Page 82: Viewing And Updating Rip Interfaces

    Chapter 3 Configuring VPNs Using the Console Interface Viewing and Updating RIP Interfaces Table 3-8. Enhanced Router DHCP Server Configuration Window Field Descriptions Field Name Field Values Description [Request Pkts Out Default: 0 Displays the total number of request packets to Svr B] received by the backup DHCP server.

  • Page 83: Enhanced Router Rip Interface Table Window Field Descriptions

    Chapter 3 Configuring VPNs Using the Console Interface Viewing and Updating RIP Interfaces You cannot add RIP interfaces. The RIP interfaces displayed in the Enhanced Router RIP Interface Table window are automatically populated after the IP interface is created, if RIP is enabled on the VPN. The command in this window has the following function: Command Function...

  • Page 84: Updating A Rip Interface

    Chapter 3 Configuring VPNs Using the Console Interface Viewing and Updating RIP Interfaces Table 3-9. Enhanced Router RIP Interface Table Window Field Descriptions (Continued) Field Name Field Values Description Rcvd RIP Ver Default: Rip2 Indicates whether RIP packets are accepted by the Enhanced Router module on this RIP interface, and Range: N/A if so, the type of RIP packets.

  • Page 85: Enhanced Router Rip Interface Configuration Window

    Chapter 3 Configuring VPNs Using the Console Interface Viewing and Updating RIP Interfaces The Enhanced Router RIP Interface Configuration window is displayed (see Figure 3-14). Figure 3-14. Enhanced Router RIP Interface Configuration Window The commands in this window have the following functions: Command Function Apply RIP Configuration...

  • Page 86: Enhanced Router Rip Interface Configuration Window Field Descriptions

    Chapter 3 Configuring VPNs Using the Console Interface Viewing and Updating RIP Interfaces Table 3-10. Enhanced Router RIP Interface Configuration Window Field Descriptions Field Name Field Values Description [Intf IP Address] Default: N/A Indicates the IP address of the RIP interface on the indicated subnet from the IP Network Intf Range: Addr field on the Enhanced Router Configuration...
  • Page 87 Chapter 3 Configuring VPNs Using the Console Interface Viewing and Updating RIP Interfaces Table 3-10. Enhanced Router RIP Interface Configuration Window Field Descriptions (Continued) Field Name Field Values Description Send RIP Version Default: RipVersion Indicates whether the Enhanced Router module will send RIP packets on this RIP interface, and if so, the type of RIP packets.

  • Page 88: Deleting An Rip Interface

    Chapter 3 Configuring VPNs Using the Console Interface Viewing and Updating RIP Interfaces Table 3-10. Enhanced Router RIP Interface Configuration Window Field Descriptions (Continued) Field Name Field Values Description Rip Status Default: Valid Indicates whether this RIP interface exists on this IP network interface.

  • Page 89: Enhanced Router Rip Interface Statistics Window

    Chapter 3 Configuring VPNs Using the Console Interface Viewing and Updating RIP Interfaces The Enhanced Router RIP Interface Statistics window is displayed (see Figure 3-15). Figure 3-15. Enhanced Router RIP Interface Statistics Window The commands in this window have the following functions: Command Function Continuous Update...

  • Page 90: Viewing Ip Addresses

    Chapter 3 Configuring VPNs Using the Console Interface Viewing IP Addresses Table 3-11. Enhanced Router Module RIP Interface Statistics Window Field Descriptions (Continued) Field Name Field Values Description RIP2 Intf Sent Default: N/A Displays the number of triggered RIP updates Updates actually sent on this interface.

  • Page 91: Configuring Ip Filter Rules

    Chapter 3 Configuring VPNs Using the Console Interface Configuring IP Filter Rules Command Function Displays the first page of the table. Bottom Displays the last page of the table. PgUp Displays the previous page of the table. PgDown Displays the next page of the table. Go Back to VPN Config Redisplays the Enhanced Router VPN Screen...

  • Page 92: Enhanced Router Filter Rule Configuration Window

    Chapter 3 Configuring VPNs Using the Console Interface Configuring IP Filter Rules Command Function Delete ‘ALL’ Filter Rules Removes all filter rule entries from the Enhanced Router Filter Rule Table win- dow. Add IP Filter Rules Displays the Enhanced Router Filter Rule Configuration window.

  • Page 93: Enhanced Router Filter Rule Configuration Window Field Descriptions

    Chapter 3 Configuring VPNs Using the Console Interface Configuring IP Filter Rules Command Function Delete this Filter Rule Removes this filter rule entry from the Enhanced Router Filter Rule Table win- dow. Go Back to Filter Table Redisplays the Enhanced Router Filter Screen Rule Table window.
  • Page 94 Chapter 3 Configuring VPNs Using the Console Interface Configuring IP Filter Rules Table 3-12. Enhanced Router Filter Rule Configuration Window Field Descriptions (Continued) Field Name Field Values Description Destination IP Mask Default: 0 Indicates the IP mask for the matching of the des- tination IP address.
  • Page 95 Chapter 3 Configuring VPNs Using the Console Interface Configuring IP Filter Rules Table 3-12. Enhanced Router Filter Rule Configuration Window Field Descriptions (Continued) Field Name Field Values Description [Dest Port Type] Default: None Indicates the type of port numbers used for this filter rule.

  • Page 96: Configuring Static Ip Routes

    Chapter 3 Configuring VPNs Using the Console Interface Configuring Static IP Routes Table 3-12. Enhanced Router Filter Rule Configuration Window Field Descriptions (Continued) Field Name Field Values Description Filter Pass Flag Default: Drop Indicates the action to be taken on this module for each filter rule (drop or pass).

  • Page 97: Ip Route Table Window

    Chapter 3 Configuring VPNs Using the Console Interface Configuring Static IP Routes The Enhanced Router IP Route Table window is displayed (see Figure 3-19). Figure 3-19. IP Route Table Window The commands in this window has the following functions: Command Function Displays the first page of the table.

  • Page 98: Enhanced Router Ip Route Configuration Window

    Chapter 3 Configuring VPNs Using the Console Interface Configuring Static IP Routes The Enhanced Router IP Route Configuration window is displayed (see Figure 3-20). Figure 3-20. Enhanced Router IP Route Configuration Window The commands in this window have the following functions: Command Function Add IP Route Configuration Adds this destination IP address (route) to...

  • Page 99: Enhanced Router Ip Route Configuration Window Field Descriptions

    Chapter 3 Configuring VPNs Using the Console Interface Configuring Static IP Routes Table 3-13. Enhanced Router IP Route Configuration Window Field Descriptions Field Name Field Values Description Note: You cannot change any fields on this window for an existing IP static route configura- tion if Local or RIP was previously selected and applied in the Route Protocol field.
  • Page 100 Chapter 3 Configuring VPNs Using the Console Interface Configuring Static IP Routes Table 3-13. Enhanced Router IP Route Configuration Window Field Descriptions (Continued) Field Name Field Values Description [Route Protocol] Default: Displays the routing mechanism by which this route was learned. Range: N/A Note: You cannot change this IP route configura- Format: Predefined...

  • Page 101: Deleting Static Ip Routes

    Chapter 3 Configuring VPNs Using the Console Interface Configuring ARP Deleting Static IP Routes Once a static IP route is created, it will remain present until it is deleted. Static IP routes that were created using dynamic routing protocols, such as RIP, will be removed per the appropriate RFC specification.

  • Page 102: Enhanced Router Arp Table Window

    Chapter 3 Configuring VPNs Using the Console Interface Configuring ARP Figure 3-21. Enhanced Router ARP Table Window The commands in this window have the following functions: Command Function Displays the first page of the table. Bottom Displays the last page of the table. PgUp Displays the previous page of the table.

  • Page 103: Setting The Values For Arp

    Chapter 3 Configuring VPNs Using the Console Interface Configuring ARP Setting the Values for ARP To configure ARP on the Enhanced Router module, perform the following procedure. Begin 1 On the Enhanced Router VPN Configuration window, select the View Arp Table command. The Enhanced Router ARP Table window is displayed (see Figure 3-21).

  • Page 104: Deleting An Existing Arp Entry

    Chapter 3 Configuring VPNs Using the Console Interface Configuring ARP Note: These multiple routes are local to the VPN and are not advertised externally. Table 3-14. Enhanced Router ARP Configuration Window Field Descriptions Field Name Field Value Description [Slot: ] Default: N/A Displays the slot number where the Enhanced Router module is installed in the PSAX chassis.

  • Page 105: Configuring Class Of Service Parameters

    Chapter 3 Configuring VPNs Using the Console Interface Configuring Class of Service Parameters 4 Type Y. The existing ARP entry is deleted. Configuring Class of Service Parameters For subchannel and DSCP classification schemes, you must create a classifica- tion table before creating the interface. Classification rule table creation is independent of assigning the table ID to the interface, but the rule table must be created before a table can be associated with an interface.

  • Page 106: Enhanced Router Class Table Window Field Descriptions

    Chapter 3 Configuring VPNs Using the Console Interface Configuring Class of Service Parameters Command Function Add this Class Scheme Applies this class scheme configuration. Delete this Class Scheme Removes this class scheme configuration. Sort the Class Table Rearranges the Table ID column to display table IDs in ascending numerical order.

  • Page 107: Configuring Class Rules

    Chapter 3 Configuring VPNs Using the Console Interface Configuring Class of Service Parameters Table 3-16. Class Scheme Actions To perform the following select the command labelled... action... add a new class scheme Add this Class Scheme delete the selected class scheme Delete this Class Scheme sort the class table Sort the Class Table...

  • Page 108: Enhanced Router Class Rule Configuration Window (Subchannel)

    Chapter 3 Configuring VPNs Using the Console Interface Configuring Class of Service Parameters Figure 3-24. Enhanced Router Class Rule Configuration Window (Subchannel) Figure 3-25. Enhanced Router Class Rule Configuration Window (DSCP) ® PSAX Enhanced Router Module User Guide, Issue 1 Release 9.1.0 PacketStar 3-58...

  • Page 109: Enhanced Router Class Rule Table Window Field Descriptions

    Chapter 3 Configuring VPNs Using the Console Interface Configuring Class of Service Parameters The commands in Enhanced Router Class Rule Table windows have the fol- lowing functions: Command Function Add a Class Rule Displays the Enhanced Router Class Rule Configuration window. Go Back to Previous Screen Redisplays the Enhanced Router Class Table window.

  • Page 110: Enhanced Router Class Rule Configuration Window

    Chapter 3 Configuring VPNs Using the Console Interface Configuring Class of Service Parameters Table 3-17. Enhanced Router Class Rule Table Window Field Descriptions (Continued) Field Name Field Values Description SubChan Max Default: N/A Indicates the maximum range for the subchannel classification scheme.

  • Page 111: Enhanced Router Class Rule Configuration Window Field Descriptions

    Chapter 3 Configuring VPNs Using the Console Interface Configuring Class of Service Parameters The commands in this window have the following functions: Command Function Apply this configuration Saves this class rule configuration. Delete this configuration Removes this class rule configuration. Go Back to Class Rule Table Redisplays the Enhanced Router Class Screen...

  • Page 112: Configuring Radius Server Parameters

    Chapter 3 Configuring VPNs Using the Console Interface Configuring RADIUS Server Parameters Table 3-18. Enhanced Router Class Rule Configuration Window Field Descriptions (Continued) Field Name Field Values Description [Class Table Default: DSCP Displays the class scheme selected on the Scheme] Enhanced Router Class Table window.

  • Page 113: Configuring Ospf Parameters

    Chapter 3 Configuring VPNs Using the Console Interface Configuring OSPF Parameters Configuring OSPF Parameters OSPF configurations are not supported on the Enhanced Router module in Release 9.1.0. Do not enter any information in, or use any commands on, any OSPF window. Saving the Configuration After configuring VPNs, IP interfaces, and connections, you must save the values to the PSAX system database.

  • Page 114: Save Configuration [Modified] (Before Saving)

    Chapter 3 Configuring VPNs Using the Console Interface Saving the Configuration Figure 3-27. Save Configuration [Modified] (Before Saving) 2 Select the Save Configuration command or press Ctrl+A. Wait a few seconds while the system writes the values to the PSAX sys- tem database.
  • Page 115 Chapter 3 Configuring VPNs Using the Console Interface Saving the Configuration After saving the configuration values, the indicator [Modified] is no longer displayed next to the Save Configuration command. ® PSAX Enhanced Router Module User Guide, Issue 1 Release 9.1.0 PacketStar 255-700-614 3-65...
  • Page 116 Chapter 3 Configuring VPNs Using the Console Interface Saving the Configuration ® PSAX Enhanced Router Module User Guide, Issue 1 Release 9.1.0 PacketStar 3-66 255-700-614...
  • Page 117 Provisioning Connections Using the Console Interface Overview of This Chapter This chapter describes how to set up connections between the Enhanced Router module and I/O modules that support ATM, frame relay, HDLC, in- band management, or bridge groups. It also includes instructions to configure local NSAP addresses and PPP templates, and viewing and deleting connec- tions.

  • Page 118: Provisioning Connections Using The Console Interface

    Chapter 4 Provisioning Connections Using the Console Interface Adding/Viewing Connections on an IP Interface Adding/Viewing Connections on an IP Interface Accessing the Enhanced Router Connection Table Adding a connection requires the specification and location of the corre- sponding IP interface. You must specify the slot, port, and type of connection. To view the connections, go to the Enhanced Router Interface Configuration window, and select the View Connection Table Screen command.

  • Page 119: Adding/Viewing Connections On An Ip Interface

    Chapter 4 Provisioning Connections Using the Console Interface Adding/Viewing Connections on an IP Interface Command Function Add an IbMgt Connection Displays the Enhanced Router IbMgt Con- nection Configuration window. Add a SPVC Connection Displays the ERM-to-ATM VCC SPVC Connection window. Go Back to IP Intf Cfg Redisplays the Enhanced Router IP Inter- Screen...

  • Page 120: Before You Begin

    Chapter 4 Provisioning Connections Using the Console Interface Adding Connections to an IP Interface If all CoS field values are not covered by all connections within an IP inter- face, then that IP interface will not be brought into service. You must either assign more connections or assign more CoS values to an existing connec- tion to bring the IP interface into service.

  • Page 121: Provisioning Atm Connections

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning ATM Connections Begin 1 For the I/O module port that is configured for ATM, be sure that on the ATM UNI/PNNI Interface Configuration window, the port of the I/O module is configured according to the ATM UNI field description table. 2 Select the Apply Interface Configuration command.
  • Page 122 Chapter 4 Provisioning Connections Using the Console Interface Provisioning ATM Connections The Enhanced Router ATM Connection Configuration window is dis- played (see Figure 4-3). Figure 4-3. Enhanced Router ATM Connection Configuration Window The commands in this window have the following functions: Command Function Add this Connection...

  • Page 123: Enhanced Router Atm Connection Configuration Window

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning ATM Connections Table 4-1. Enhanced Router ATM Connection Configuration Window Field Descriptions Field Name Field Values Description [Slot: ] Default: N/A Displays the slot number where the Enhanced Router module is installed in the PSAX chassis. Range: Chassis dependent Format: Numeric...

  • Page 124: Enhanced Router Atm Connection Configuration Window Field Descriptions

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning ATM Connections Table 4-1. Enhanced Router ATM Connection Configuration Window Field Descriptions (Continued) Field Name Field Values Description [LLC Encapsula- Default: LlcSnap Displays the encapsulation technique used in tion ] convert an IP packet to an ATM cell. Range: N/A Format: Predefined Indicates that VC multiplexing is used to convert...
  • Page 125 Chapter 4 Provisioning Connections Using the Console Interface Provisioning ATM Connections Table 4-1. Enhanced Router ATM Connection Configuration Window Field Descriptions (Continued) Field Name Field Values Description Service Type Default: UBR Indicates the quality of service (QoS) type used on this connection. Range: N/A Note: There cannot be more than one connection Format: Predefined...
  • Page 126 Chapter 4 Provisioning Connections Using the Console Interface Provisioning ATM Connections Table 4-1. Enhanced Router ATM Connection Configuration Window Field Descriptions (Continued) Field Name Field Values Description [Oper Status] Default: OutOfSer- Displays the operational status of the connection vice you are configuring. Range: N/A Format: Predefined OutOfService...
  • Page 127 Chapter 4 Provisioning Connections Using the Console Interface Provisioning ATM Connections Table 4-1. Enhanced Router ATM Connection Configuration Window Field Descriptions (Continued) Field Name Field Values Description PCR/SCR Default: 1 Indicates the peak cell rate and sustained cell rate (respectively) used on this connection. This field Range: N/A displays the frame relay values in ATM terms.
  • Page 128 Chapter 4 Provisioning Connections Using the Console Interface Provisioning ATM Connections Table 4-1. Enhanced Router ATM Connection Configuration Window Field Descriptions (Continued) Field Name Field Values Description Traffic Shaping Default: Disabled Indicates whether traffic shaping is enabled on this connection. It is implemented on modules Range: N/A that are offered with traffic-shaping variations: Format: Predefined...
  • Page 129 Chapter 4 Provisioning Connections Using the Console Interface Provisioning ATM Connections Table 4-1. Enhanced Router ATM Connection Configuration Window Field Descriptions (Continued) Field Name Field Values Description Conformance Type Default: Best-effort Indicates the type of traffic control option used for ATM cells. The traffic descriptor combination Range: N/A specifies which traffic parameters are used for Format: Predefined...
  • Page 130 Chapter 4 Provisioning Connections Using the Console Interface Provisioning Frame Relay Connections Table 4-1. Enhanced Router ATM Connection Configuration Window Field Descriptions (Continued) Field Name Field Values Description Bulk Stats Flag Default: Disabled Indicates whether the bulk statistics feature is supported on this connection.

  • Page 131: Enhanced Router Configuration

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning Frame Relay Connections Begin 1 For the I/O module port that is configured for frame relay, be sure that on the Frame Relay Interface Configuration window, the Interworking Type field has the value Frf8. The other fields may be configured accord- ing to the Frame Relay field description table (see the appropriate Packet- ®...
  • Page 132 Chapter 4 Provisioning Connections Using the Console Interface Provisioning Frame Relay Connections The Enhanced Router Frame Relay Connection Configuration window is displayed (see Figure 4-4). Figure 4-4. Enhanced Router Frame Relay Connection Configuration Window The commands in this window have the following functions: Command Function Add this Connection...

  • Page 133: Enhanced Router Frame Relay Connection Configuration Window

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning Frame Relay Connections Table 4-2. Enhanced Router Frame Relay Connection Configuration Window Field Descriptions Field Name Field Values Description [Slot: ] Default: N/A Displays the slot number where the Enhanced Router module is installed in the PSAX chassis. Range: Chassis dependent Format: Numeric...

  • Page 134: Enhanced Router Frame Relay Connection Configuration Window Field Descriptions

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning Frame Relay Connections Table 4-2. Enhanced Router Frame Relay Connection Configuration Window Field Descriptions Field Name Field Values Description [Flow] Default: Duplex Displays the direction of flow of data traffic in for this connection.
  • Page 135 Chapter 4 Provisioning Connections Using the Console Interface Provisioning Frame Relay Connections Table 4-2. Enhanced Router Frame Relay Connection Configuration Window Field Descriptions Field Name Field Values Description Service Type Default: UBR Indicates the quality of service (QoS) type used on this connection.
  • Page 136 Chapter 4 Provisioning Connections Using the Console Interface Provisioning Frame Relay Connections Table 4-2. Enhanced Router Frame Relay Connection Configuration Window Field Descriptions Field Name Field Values Description Port Default: 1 Indicates the port number of the module config- ured with a frame relay interface, or the VPN Range: N/A identifier for a configured Enhanced Router mod- Format: Numeric...
  • Page 137 Chapter 4 Provisioning Connections Using the Console Interface Provisioning Bridge Connections Table 4-2. Enhanced Router Frame Relay Connection Configuration Window Field Descriptions Field Name Field Values Description [Peak Cell Rate] Default: 1 Displays the peak cell rate used on this connec- tion.
  • Page 138 Chapter 4 Provisioning Connections Using the Console Interface Provisioning Bridge Connections 1 Configure the physical port (that you want to connect to the Enhanced Router module) and assign a bridge group number. 2 Create a virtual channel and assign the same bridge group number. 3 Bring the bridge group into service.
  • Page 139 Chapter 4 Provisioning Connections Using the Console Interface Provisioning Bridge Connections 2 Select the View Connection Table Screen command. The Enhanced Router Connection Table window is displayed (see Figure 4-1). 3 On the Enhanced Router Connection Table window, select the Add a Bridge Connection command.

  • Page 140: Enhanced Router Bridge Connection Configuration Window

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning Bridge Connections Table 4-3. Enhanced Router Bridge Connection Configuration Window Field Descriptions Field Name Field Values Description [Slot: ] Default: N/A Displays the slot number where the Enhanced Router module is installed in the PSAX chassis. Range: Chassis dependent Format: Numeric...

  • Page 141: Enhanced Router Bridge Connection Configuration Window Field Descriptions

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning Bridge Connections Table 4-3. Enhanced Router Bridge Connection Configuration Window Field Descriptions (Continued) Field Name Field Values Description [Connection Descr] Default: N/A Displays a text string containing information about the connection. Range: 0–255 Format: Alphanu- meric...
  • Page 142 Chapter 4 Provisioning Connections Using the Console Interface Provisioning HDLC Connections Table 4-3. Enhanced Router Bridge Connection Configuration Window Field Descriptions (Continued) Field Name Field Values Description [Oper Status] Default: OutOfSer- Indicates the operational status of the connection vice you are configuring. Range: N/A Format: Predefined OutOfService...
  • Page 143 Chapter 4 Provisioning Connections Using the Console Interface Provisioning HDLC Connections When a packet comes to an I/O module with an IP over PPP HDLC-like inter- face, it will be in the format of IP/PPP with HDLC framing. After removing the 3 bytes of the HDLC framing octets, the module segments the remaining packet into ATM cells with AAL5 VC multiplexing and then sends the cells to the Enhanced Router module through the backplane.

  • Page 144: Module

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning HDLC Connections 2 Select the View Connection Table Screen command. The Enhanced Router Connection Table window is displayed (see Figure 4-1). 3 On the Enhanced Router Connection Table window, select the Add an HDLC Connection command.

  • Page 145: Enhanced Router Hdlc Connection Configuration Window

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning HDLC Connections 5 To apply these values, select the Add this Connection command. The HDLC connection is displayed in the Enhanced Router Connection Table window. Table 4-4. Enhanced Router HDLC Connection Configuration Window Field Descriptions Field Name Field Values Description...

  • Page 146: Enhanced Router Hdlc Connection Configuration Window Field Descriptions

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning HDLC Connections Table 4-4. Enhanced Router HDLC Connection Configuration Window Field Descriptions (Continued) Field Name Field Values Description [Flow] Default: Duplex Displays the direction of flow of data traffic in for this connection.
  • Page 147 Chapter 4 Provisioning Connections Using the Console Interface Provisioning HDLC Connections Table 4-4. Enhanced Router HDLC Connection Configuration Window Field Descriptions (Continued) Field Name Field Values Description Service Type Default: UBR Indicates that PPP traffic is running on this con- nection (PPP over ATM connection).
  • Page 148 Chapter 4 Provisioning Connections Using the Console Interface Provisioning In-band Management Connections Table 4-4. Enhanced Router HDLC Connection Configuration Window Field Descriptions (Continued) Field Name Field Values Description Port Default: 1 Indicates the port number configured with the HDLC Passthrough interface. Range: N/A Format: Numeric Channel...
  • Page 149 Chapter 4 Provisioning Connections Using the Console Interface Provisioning In-band Management Connections The Enhanced Router module module is a router; therefore traffic from any interface on a given VPN can be routed to or from the in-band management connection. Provisioning In-band Management Connections with the Enhanced Router In-band Management To provision an in-band management connection between an I/O module Configuration...

  • Page 150: Enhanced Router Ibmgt Connection Configuration Window

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning In-band Management Connections The Enhanced Router IbMgt Connection Configuration window is dis- played (see Figure 4-7). Figure 4-7. Enhanced Router IbMgt Connection Configuration Window The commands in this window have the following functions: Command Function Add this Connection...
  • Page 151 Chapter 4 Provisioning Connections Using the Console Interface Provisioning In-band Management Connections Table 4-5. Enhanced Router In-band Management Connection Configuration Window Field Descriptions Field Name Field Values Description [Slot: ] Default: N/A Displays the slot number where the Enhanced Router module is installed in the PSAX chassis. Range: Chassis dependent Format: Numeric...

  • Page 152: Descriptions

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning In-band Management Connections Table 4-5. Enhanced Router In-band Management Connection Configuration Window Field Descriptions (Continued) Field Name Field Values Description [Connection Descr] Default: N/A Displays a text string containing information about the connection. Range: 0–255 Format: Alphanu- meric...
  • Page 153 Chapter 4 Provisioning Connections Using the Console Interface Provisioning In-band Management Connections Table 4-5. Enhanced Router In-band Management Connection Configuration Window Field Descriptions (Continued) Field Name Field Values Description [Oper Status] Default: OutOfSer- Displays the operational status of the connection vice you are configuring.
  • Page 154 Chapter 4 Provisioning Connections Using the Console Interface Provisioning ERM-to-ATM VCC SPVC Connections Provisioning ERM-to-ATM VCC SPVC Connections Configuring Local NSAP Addresses In the SPVC Address table, you configure the local NSAP addressed assigned to the VPN. Adding NSAP Addresses to the SPVC Address Table Begin 1 On the SPVC Connection Configuration Menu window, select the Con- figure Local Address command.

  • Page 155: Provisioning Erm-To-Atm Vcc Spvc Connections

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning ERM-to-ATM VCC SPVC Connections Command Function Find: " " To find a particular SPVC address, enter the NSAP address after the Find field. If the address exists, it is displayed on the first line of the table.
  • Page 156 Chapter 4 Provisioning Connections Using the Console Interface Provisioning ERM-to-ATM VCC SPVC Connections Begin 1 On the Connection Configuration Menu window, select the SPVC Con- figuration Screen option. The SPVC Connection Configuration Menu window is displayed (see Figure 4-9). Figure 4-9. SPVC Connection Configuration Menu Window 2 On the SPVC Connection Configuration Menu window, select the ERM- to-ATM VCC option.

  • Page 157: Spvc Connection Configuration Menu Window

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning ERM-to-ATM VCC SPVC Connections Figure 4-10. ERM-to-ATM VCC SPVC Table Window Note: At the time of initial installation, the ERM-to-ATM VCC SPVC Table window is empty. After you have set up connections, this window is displayed all the connections of this type in the system.

  • Page 158: Erm-To-Atm Vcc Spvc Table Window

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning ERM-to-ATM VCC SPVC Connections Table 4-7. ERM-to-ATM VCC SPVC Table Window Field Descriptions Field Name Field Values Description (ERM Interface) ERM Interface Default: N/A This column displays the information for all PVC sides of the connections.
  • Page 159 Chapter 4 Provisioning Connections Using the Console Interface Provisioning ERM-to-ATM VCC SPVC Connections Figure 4-11. ERM-to-ATM VCC SPVC Connection Window Commands The commands on this window have the following functions: Command Function Configure Traffic Paras Displays the ERM-to-ATM VCC SPVC Traffic Parameters win- dow.

  • Page 160: Erm-To-Atm Vcc Spvc Connection Window

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning ERM-to-ATM VCC SPVC Connections Table 4-8. ERM-to-ATM VCC SPVC Connection Window Field Descriptions Field Name Field Values Description ERM Interface A Panel Slot Default: N/A Displays the slot number where the Enhanced Router module is installed in the PSAX chassis.

  • Page 161: Erm-To-Atm Vcc Spvc Connection Window Field Descriptions

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning ERM-to-ATM VCC SPVC Connections Table 4-8. ERM-to-ATM VCC SPVC Connection Window Field Descriptions (Continued) Field Name Field Values Description [LLC Encapsula- Default: LlcSnap Displays the encapsulation technique used in con- tion] vert an IP packet to an ATM cell.
  • Page 162 Chapter 4 Provisioning Connections Using the Console Interface Provisioning ERM-to-ATM VCC SPVC Connections Table 4-8. ERM-to-ATM VCC SPVC Connection Window Field Descriptions (Continued) Field Name Field Values Description PPPoE Support Default: Disabled This field is not currently supported. Range: N/A Format: Predefined ATM Interface Panel [Slot]...
  • Page 163 Chapter 4 Provisioning Connections Using the Console Interface Provisioning ERM-to-ATM VCC SPVC Connections Table 4-8. ERM-to-ATM VCC SPVC Connection Window Field Descriptions (Continued) Field Name Field Values Description Conn Type Default: ActiveSvc Specifies whether the near-end side of the connec- tion on the PSAX system attempts to set up calls or Range: N/A accepts calls from another device.
  • Page 164 Chapter 4 Provisioning Connections Using the Console Interface Provisioning ERM-to-ATM VCC SPVC Connections Table 4-8. ERM-to-ATM VCC SPVC Connection Window Field Descriptions (Continued) Field Name Field Values Description Rmt Vpi/Vci Default: N/A Specifies the VPI and VCI of the remote endpoint of this connection.
  • Page 165 Chapter 4 Provisioning Connections Using the Console Interface Provisioning ERM-to-ATM VCC SPVC Connections Table 4-8. ERM-to-ATM VCC SPVC Connection Window Field Descriptions (Continued) Field Name Field Values Description [Oper Status] Default: Other Displays the operational status of the connection. Range: N/A Format: Predefined Other Indicates that none of the types specified below...
  • Page 166 Chapter 4 Provisioning Connections Using the Console Interface Provisioning ERM-to-ATM VCC SPVC Connections The ERM-to-ATM VCC SPVC Table window is displayed with the values you just applied. 7 To add more connections of this type, repeat steps 2 through 5 for more connections as needed.

  • Page 167: Erm-To-Atm Vcc Spvc Traffic Parameters Window

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning ERM-to-ATM VCC SPVC Connections Table 4-9. ERM-to-ATM VCC SPVC Traffic Parameters Window Field Descriptions Field Name Field Values Description Service Type Default: Ubr Specifies the PSAX system-supported quality of ser- vice (QoS) class. The type selected causes the con- Range: N/A formance type for the connection to be derived Format: Predefined...

  • Page 168: Erm-To-Atm Vcc Spvc Traffic Parameters Window Field Descriptions

    Chapter 4 Provisioning Connections Using the Console Interface Provisioning ERM-to-ATM VCC SPVC Connections Table 4-9. ERM-to-ATM VCC SPVC Traffic Parameters Window Field Descriptions (Continued) Field Name Field Values Description Sustained Cell Rate Default: 1 Indicates the sustainable cell rate (SCR) with CLP=0 (high priority) cells or the PCR with CLP=0 cells.
  • Page 169 Chapter 4 Provisioning Connections Using the Console Interface Configuring PPP Templates Table 4-9. ERM-to-ATM VCC SPVC Traffic Parameters Window Field Descriptions (Continued) Field Name Field Values Description Cell Discard Default: Epd Specifies the type of cell discarding used when the traffic flow on the egress side of this connection is Range: N/A congested (congestion discard).

  • Page 170: Configuring Ppp Templates

    Chapter 4 Provisioning Connections Using the Console Interface Configuring PPP Templates Command Function Displays the first page of the table. Bottom Displays the last page of the table. PgUp Displays the previous page of the table. PgDown Displays the next page of the table. Add a PPP Config Template Displays the Enhanced Router PPP Config Template Configuration window.
  • Page 171 Chapter 4 Provisioning Connections Using the Console Interface Configuring PPP Templates Begin 1 On the Enhanced Router PPP Config Template Table window, select the Add a PPP Config Template command. The Enhanced Router PPP Config Template Configuration window is dis- played (see Figure 4-14).

  • Page 172: Enhanced Router Ppp Config Template Configuration Window

    Chapter 4 Provisioning Connections Using the Console Interface Configuring PPP Templates Table 4-11. Enhanced Router PPP Config Template Configuration Window Field Descriptions Field Name Field Values Description [Slot: ] Default: N/A Displays the slot number where the Enhanced Router module is installed in the PSAX chassis. Range: Chassis dependent Format: Numeric...

  • Page 173: Deleting Ppp Template Configurations

    Chapter 4 Provisioning Connections Using the Console Interface Configuring Point-to-Point Protocol Table 4-11. Enhanced Router PPP Config Template Configuration Window Field Descriptions Field Name Field Values Description Chap Max Retries Default: 2 Configures the maximum number of unacknowl- edged challenge handshake authentication proto- Range: 1–20 col (CHAP) challenge or response messages to Range: Numeric...

  • Page 174: Configuring Point-To-Point Protocol

    Chapter 4 Provisioning Connections Using the Console Interface Configuring Point-to-Point Protocol The values on the Enhanced Router PPP Status window are not available until after the PPP option negotiation has completed. When the PPP option negotiation has completed the link becomes operationally in service. Note: PPP can only be configured on VPN 1.

  • Page 175: Enhanced Router Ppp Configuration Window

    Chapter 4 Provisioning Connections Using the Console Interface Configuring Point-to-Point Protocol Command Function View PPP Status Screen Displays the Enhanced Router PPP Status window. Go Back to Previous Screen Redisplays the Enhanced Router HDLC Connection Configuration window. 2 Select the values for the fields on this window from the values given in Table 4-12.

  • Page 176: Enhanced Router Ppp Configuration Window Field Descriptions

    Chapter 4 Provisioning Connections Using the Console Interface Configuring Point-to-Point Protocol Table 4-12. Enhanced Router PPP Configuration Window Field Descriptions (Continued) Field Name Field Values Description Authentication Parameters Panel Primary Protocol Default: None Indicates the security protocol type that is applied to this interface.

  • Page 177: Viewing Ppp Status

    Chapter 4 Provisioning Connections Using the Console Interface Configuring Point-to-Point Protocol Table 4-12. Enhanced Router PPP Configuration Window Field Descriptions (Continued) Field Name Field Values Description Secondary Protocol Default: None Indicates the security protocol type that is applied to this interface if the primary security protocol is Range: N/A not supported by the peer.
  • Page 178 Chapter 4 Provisioning Connections Using the Console Interface Configuring Point-to-Point Protocol The Enhanced Router PPP Status window is displayed (see Figure 4-16). Figure 4-16. Enhanced Router PPP Status Window The commands on this window have the following functions: Command Function Reset PPP Status Display Sets the values on this window to zero.

  • Page 179: Enhanced Router Ppp Status Window

    Chapter 4 Provisioning Connections Using the Console Interface Configuring Point-to-Point Protocol Table 4-13. Enhanced Router PPP Status Window Field Descriptions (Continued) Field Name Field Values Description [Remote MRU] Default: N/A Displays the current value of the MRU for the remote PPP entity. This value is the MRU that the Range: 576–9180 local entity is using when sending packets to the Format: Numeric...
  • Page 180 Chapter 4 Provisioning Connections Using the Console Interface Configuring Point-to-Point Protocol Table 4-13. Enhanced Router PPP Status Window Field Descriptions (Continued) Field Name Field Values Description Stopping The Stopping state is the Open counterpart to the Closing state. A Terminate-Request has been sent and the Restart timer is running, but a Termi- nate-Ack has not yet been received.
  • Page 181 Chapter 4 Provisioning Connections Using the Console Interface Viewing Connection Statistics Table 4-13. Enhanced Router PPP Status Window Field Descriptions (Continued) Field Name Field Values Description [Peer IP NetMask] Default: N/A Displays the IP network mask of the PPP client. Range: N/A Format: Valid dotted quad...

  • Page 182: Viewing Connection Statistics

    Chapter 4 Provisioning Connections Using the Console Interface Viewing Connection Statistics The Enhanced Router Connection Statistics window is displayed (see Figure 4-17). Figure 4-17. Enhanced Router Connection Statistics Window The commands in this window have the following functions: Command Function Continuous Update Updates the values constantly.

  • Page 183: Vpn Ip N/W Interface Connection Statistics Window Field Descriptions

    Chapter 4 Provisioning Connections Using the Console Interface Deleting Connections Table 4-14. VPN IP N/w Interface Connection Statistics Window Field Descriptions (Continued) Field Name Field Values Description In Errored Pkts Default: 0 Indicates the number of inbound packets that contained errors preventing them from being Range: N/A deliverable to a higher-layer protocol.

  • Page 184: Deleting Connections

    Chapter 4 Provisioning Connections Using the Console Interface Deleting Connections ® PSAX Enhanced Router Module User Guide, Issue 1 Release 9.1.0 PacketStar 4-68 255-700-614...
  • Page 185 Configuring VPNs Using the AQueView EMS Overview of This Chapter This chapter describes how to do the following: ~ Configure various components of the Enhanced Router module: • VPNs • IP interfaces • IP filter rules • static IP routes •...
  • Page 186 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring VPNs Hierarchy of the Enhanced Router Configuration You must configure the Enhanced Router module in a hierarchy of three major tasks: 1. Configure the VPN. 2. Configure IP interfaces within the given VPN. Note: The interface numbers you choose in step 2 may be repeated when configuring the other VPNs, but the interface number must be...

  • Page 187: Front Panel View Of The Enhanced Router Module

    Chapter 5 Configuring VPNs Using the AQueView EMS Configuring VPNs • In the Device Tree, expand the module name identifier, and double- click 01 identifier. • In the Device Tree, expand the module name identifier, select 01, right- click 01 and a menu appears. Select Configure. Figure 5-2.

  • Page 188: Add Vpn Enhanced Router Module Configuration Table Window Field Descriptions

    Chapter 5 Configuring VPNs Using the AQueView EMS Configuring VPNs The buttons on this page have the following functions: Button Function Refresh Diagnostics Updates the display-only fields on the Diagnostics panel by retrieving the values from the PSAX MIB. Close Closes this window.

  • Page 189: Enhanced Router Module Configuration Window (Displaying Menu)

    Chapter 5 Configuring VPNs Using the AQueView EMS Configuring VPNs Table 5-1. ADD VPN Enhanced Router Module Configuration Table Window Field Descriptions Field Name Field Values Description ERM CPU Utiliza- Default: 0.00 Displays the CPU’s memory utilization as a per- tion centage of total memory available per VPN.

  • Page 190: Add Enhanced Router Module Vpn Configuration Entry Window

    Chapter 5 Configuring VPNs Using the AQueView EMS Configuring VPNs Figure 5-5. ADD Enhanced Router Module VPN Configuration Entry Window The buttons in this window have the following functions: Button Function Create Creates a VPN. This button is only dis- played on the ADD Enhanced Router VPN Configuration Entry window.

  • Page 191: Add Enhanced Router Module Vpn Configuration Entry Window Field Descriptions

    Chapter 5 Configuring VPNs Using the AQueView EMS Configuring VPNs Button Function Take Out of Service Takes the VPN out of service. Close Closes this window. 3 Enter the values in the fields on this window according to the informa- tion provided in Table 5-2.
  • Page 192 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring VPNs Table 5-2. ADD Enhanced Router Module VPN Configuration Entry Window Field Descriptions Field Name Field Values Description Max No of Inter- Default: 8192 Displays the maximum number of interfaces to faces be contained in this VPN.
  • Page 193 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring VPNs Table 5-2. ADD Enhanced Router Module VPN Configuration Entry Window Field Descriptions Field Name Field Values Description Default: (Blank) Indicates whether the class of service feature is supported on this VPN. Range: N/A Note: This field is display-only in Multi-Instance Format: Blank (unse-...
  • Page 194 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring VPNs Table 5-2. ADD Enhanced Router Module VPN Configuration Entry Window Field Descriptions Field Name Field Values Description RIP Redistribute Default: Enabled This field is not currently supported. OSPF Range: N/A Format: Predefined Enabled Indicates that OSPF is used to redistribute RIP...
  • Page 195 Chapter 5 Configuring VPNs Using the AQueView EMS Viewing ICMP Statistics Begin 1 Do one of the following (a or b): a On the Enhanced Router Module Configuration Table window, select the Take Out of Service > Delete. b On the VIEW or UPDATE Enhanced Router Module VPN Configura- tion Entry window, click Delete.

  • Page 196: Vpn Icmp Statistics Page

    Chapter 5 Configuring VPNs Using the AQueView EMS Viewing ICMP Statistics Figure 5-7. VPN ICMP Statistics Page The buttons on this page have the following functions: Button Function Update Refreshes the statistics manually. Clear Resets the resetable statistics to zero. Poll Poll + continuously update the statistics and changes the button label to Poll-.

  • Page 197: Enhanced Router Vpn Icmp Statistics Window Field Descriptions

    Chapter 5 Configuring VPNs Using the AQueView EMS Viewing ICMP Statistics Table 5-3. Enhanced Router VPN ICMP Statistics Window Field Descriptions Field Name Field Values Description [Slot: ] Default: N/A Displays the slot number where the Enhanced Router module is installed in the PSAX chassis. Range: Chassis dependent Format: Numeric...
  • Page 198 Chapter 5 Configuring VPNs Using the AQueView EMS Viewing ICMP Statistics Table 5-3. Enhanced Router VPN ICMP Statistics Window Field Descriptions (Continued) Field Name Field Values Description Mask Requests Default: 0 Displays the number of received mask requests on this VPN. Range: N/A Format: Numeric Mask Replies...
  • Page 199 Chapter 5 Configuring VPNs Using the AQueView EMS Viewing ICMP Statistics Table 5-3. Enhanced Router VPN ICMP Statistics Window Field Descriptions (Continued) Field Name Field Values Description Time Stamp Replies Default: 0 Displays the number of transmitted time stamp requests on this VPN. Range: N/A Format: Numeric Mask Requests...
  • Page 200 Chapter 5 Configuring VPNs Using the AQueView EMS Viewing ICMP Statistics Table 5-4. ERM VPN IP Statistics Window Field Descriptions (Continued) Field Name Field Values Description In Discarded Data- Default: 0 Displays the number of input IP datagrams for grams which no problems were encountered to prevent Range: N/A their continued processing, but which were dis-...

  • Page 201: Configuring An Ip Interface

    Chapter 5 Configuring VPNs Using the AQueView EMS Configuring an IP Interface Table 5-4. ERM VPN IP Statistics Window Field Descriptions (Continued) Field Name Field Values Description Reasm Fails Default: 0 Displays the number of failures detected by the IP reassembly algorithm (for whatever reason: time- Range: N/A outs, errors, and so on).

  • Page 202: Enhanced Router Module Interface Configuration Table Window

    Chapter 5 Configuring VPNs Using the AQueView EMS Configuring an IP Interface The Enhanced Router Interface Configuration Table page appears (see Figure 5-8). Figure 5-8. Enhanced Router Module Interface Configuration Table Window 2 Right-click within the page and a menu appears. Select Create. The ADD Enhanced Router Interface Table Entry window appears (see Figure 5-9).
  • Page 203 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring an IP Interface Button Function Bring Into Service Brings the out-of-service IP network interface to in-service status. Displayed on the ADD Enhanced Router Interface Table Entry window when creat- ing an IP network interface. Adds the entry to the Enhanced Router Interface Table.

  • Page 204: Enhanced Router If Parameter Page

    Chapter 5 Configuring VPNs Using the AQueView EMS Configuring an IP Interface The entry appears in the window with the values you just created (see Figure 5-10). . Figure 5-10. Enhanced Router IF Parameter Page Table 5-5. Enhanced Router Interface Configuration Page Field Name Field Values Description...
  • Page 205 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring an IP Interface Table 5-5. Enhanced Router Interface Configuration Page (Continued) Field Name Field Values Description Intf IP Mask Default: 000.000.000. Indicates the IP subnet mask of the enterprise network to which this IP interface is attached. This value is strictly checked for network consis- Range: N/A tency with other IP interfaces defined on the...
  • Page 206 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring an IP Interface Table 5-5. Enhanced Router Interface Configuration Page (Continued) Field Name Field Values Description UnNumbered Intf Default: Disabled Indicates whether the unnumbered IP interface Supp type is supported on this IP interface. Range: N/A Format: Predefined Disabled...
  • Page 207 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring an IP Interface Table 5-5. Enhanced Router Interface Configuration Page (Continued) Field Name Field Values Description Class Default Color Default: 0 Indicates the default color on this IP interface when the FixedClassSupport field is set to No. Range: 1–6 Unused values in the Enhanced Router Class Format: Numeric...
  • Page 208 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring an IP Interface Table 5-5. Enhanced Router Interface Configuration Page (Continued) Field Name Field Values Description [Intf Type] Default: Other Displays the type of IP interface on this VPN, dis- tinguished according to the physical/link proto- Range: N/A col(s) immediately below the network layer in Format: Predefined...
  • Page 209 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring an IP Interface The IF Parameter page appears (see Figure 5-11). Figure 5-11. Enhanced Router IF Parameter Page 6 Enter values in the fields on this window according to the information provided in Table 5-6.
  • Page 210 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring an IP Interface Table 5-6. Field Descriptions for the IF Parameter Configuration Page (Continued) Field Name Field Values Description If Type Default: Other Displays the type of IP interface on this VPN, dis- tinguished according to the physical/link proto- Range: N/A col(s) immediately below the network layer in...
  • Page 211 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring an IP Interface Example 1. if QoS Class Supp—Disabled Fixed Class Support—No Fixed Class Color—1 Class Default Color—1 QOS Class Tb ID—0 QOS Egress Flag—No Example 2. if QoS Class Supp—Enabled Fixed Class Support—Yes Fixed Class Color—3 Class Default Color—1...

  • Page 212: Ip Parameters Page

    Chapter 5 Configuring VPNs Using the AQueView EMS Configuring an IP Interface Figure 5-12. IP Parameters Page The buttons on this page have the following functions: Button Function Top Row Update Refreshes the statistics manually on the IP Parameters page. Clear Resets the resetable statistics to zero.
  • Page 213 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring an IP Interface The display-only fields in the VPN Statistics window are described in Table 5-7. Table 5-7. Enhanced Router Interface Statistics Window Field Descriptions Field Name Field Value Description In Octets Default: 0 Indicates the total number of input datagrams (octets) received on this IP interface, including...
  • Page 214 Chapter 5 Configuring VPNs Using the AQueView EMS Viewing and Configuring DHCP Servers Deleting an Interface Begin 1 On the VIEW Enhanced Router Interface Table Entry or UPDATE Enhanced Router Interface Table Entry window, right-click the mouse on the IP interface to be deleted, and select Take Out of Service. 2 Right-click the mouse and on the IP network interface to be deleted, and select Delete.

  • Page 215: Add Enhanced Router Module Dhcp Server Configuration Entry Window

    Chapter 5 Configuring VPNs Using the AQueView EMS Viewing and Configuring DHCP Servers Table 5-8. Enhanced Router DHCP Server Table Window Field Descriptions Field Name Field Values Description Req Pkts In Default: 0 Displays the total number of request packets received by the primary and backup DHCP serv- Range: N/A ers.
  • Page 216 Chapter 5 Configuring VPNs Using the AQueView EMS Viewing and Configuring DHCP Servers 4 To apply the values for the fields, click Add. 5 Once the DHCP server configuration is added or deleted, you can view the updated Enhanced Router Module DHCP Server Address Table win- dow by clicking the Close.

  • Page 217: Pinging A Device

    Chapter 5 Configuring VPNs Using the AQueView EMS Pinging a Device Table 5-9. Enhanced Router DHCP Server Configuration Window Field Descriptions (Continued) Field Name Field Values Description Request Pkts Out to Default: 0 Displays the total number of request packets Server B received by the backup DHCP server.
  • Page 218 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring Class of Service Parameters 3 Click Ping. Configuring Class of Service Parameters Accessing the Class Table Begin 1 On the Enhanced Router VPN Configuration window, click the Class Table tab. The Enhanced Router Class Configuration Table page appears (see Figure 5-17).
  • Page 219 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring Class of Service Parameters Button Function Displayed on the ADD Enhanced Router Class Configuration Table Entry window when creating an IP route. Adds the entry to the Enhanced Router Class Rule Con- figuration Table.

  • Page 220: Deleting Class Configurations

    Chapter 5 Configuring VPNs Using the AQueView EMS Configuring Class of Service Parameters Deleting Class Configurations Once a class is created, it will remain present on the Enhanced Router Class Configuration Table page until it is deleted. To delete a class, perform the steps in the following procedure.

  • Page 221: Enhanced Router Class Rule Configuration Entry Window

    Chapter 5 Configuring VPNs Using the AQueView EMS Configuring Class of Service Parameters The Enhanced Router Class Rule Configuration Entry window appears (see Figure 5-18). Figure 5-20. Enhanced Router Class Rule Configuration Entry Window The buttons on this window have the following functions: Button Function Displayed on the ADD Enhanced Router...

  • Page 222: Deleting Class Rule Configurations

    Chapter 5 Configuring VPNs Using the AQueView EMS Configuring Class of Service Parameters Table 5-11. Enhanced Router Class Rule Configuration Window Field Descriptions Field Name Field Values Description ERM Slot Default: N/A Displays the slot number where the Enhanced Router module is installed in the PSAX chassis. Range: Chassis dependent Format: Numeric...
  • Page 223 Chapter 5 Configuring VPNs Using the AQueView EMS Viewing and Updating RIP Interfaces A confirmation window appears, asking you to confirm that you want to delete this class configuration entry. 4 Click Yes. Viewing and Updating RIP Interfaces Viewing/Updating a RIP Interface You cannot add RIP interfaces.

  • Page 224: Enhanced Router Rip Interface Configuration Window (Update)

    Chapter 5 Configuring VPNs Using the AQueView EMS Viewing and Updating RIP Interfaces The RIP2 Interface Configuration window appears (see Figure 5-22). Figure 5-22. Enhanced Router RIP Interface Configuration Window (UPDATE) The buttons on this window have the following functions: Button Function Update...

  • Page 225: Add Erm Rip Interface Table Entry Window Field Descriptions

    Chapter 5 Configuring VPNs Using the AQueView EMS Viewing and Updating RIP Interfaces Table 5-12. ADD ERM RIP Interface Table Entry Window Field Descriptions Field Name Field Values Description Erm Slot Default: N/A Displays the slot number where the Enhanced (display only) Router module is installed in the PSAX chassis.
  • Page 226 Chapter 5 Configuring VPNs Using the AQueView EMS Viewing and Updating RIP Interfaces Table 5-12. ADD ERM RIP Interface Table Entry Window Field Descriptions (Continued) Field Name Field Values Description Send RIP Version Default: RipVersion Indicates whether the Enhanced Router module will send RIP packets on this RIP interface, and if so, the type of RIP packets.

  • Page 227: Viewing Rip Interface Statistics

    Chapter 5 Configuring VPNs Using the AQueView EMS Viewing and Updating RIP Interfaces Table 5-12. ADD ERM RIP Interface Table Entry Window Field Descriptions (Continued) Field Name Field Values Description Conf Status Default: Valid Indicates whether this RIP interface exists on this IP network interface.

  • Page 228: Deleting A Rip Interface

    Chapter 5 Configuring VPNs Using the AQueView EMS Viewing and Updating RIP Interfaces The fields in this window are described in Table 5-13. Table 5-13. Enhanced Router Module RIP2 Interface Statistics Window Field Descriptions Field Name Field Values Description ERM Slot Default: N/A Displays the slot number where the Enhanced Router module is installed in the PSAX chassis.

  • Page 229: Viewing The Ip Address Table

    Chapter 5 Configuring VPNs Using the AQueView EMS Viewing the IP Address Table A confirmation message appears (see Figure 5-24): Figure 5-24. Delete Entry Confirmation Window Click Yes. The RIP interface is deleted. Viewing the IP Address Table To view IP address table, go to the Enhanced Router IP Address Table win- dow, clickthe IP Address Table tab.

  • Page 230: Enhanced Router Filter Rule Table Page

    Chapter 5 Configuring VPNs Using the AQueView EMS Configuring Filter Rules The Enhanced Router Module Filter Rule Configuration Table page appears (see Figure 5-26). Figure 5-26. Enhanced Router Filter Rule Table Page 2 Right-click anywhere within the page and a menu appears. Select Create. The Enhanced Router Module Filter Rule Table Entry window appears (see Figure 5-27).
  • Page 231 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring Filter Rules Button Function Delete Displayed on the VIEW Enhanced Router Module IP Filter Table Entry and UPDATE Enhanced Router Module IP Filter Table Entry windows. Removes the entry from the Enhanced Router Module Filter Rule Configuration Table.
  • Page 232 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring Filter Rules Table 5-14. Enhanced Router Filter Rule Configuration Window Field Descriptions (Continued) Field Name Field Values Description Destination mask Default: 0 Indicates the IP mask for the matching of the des- tination IP address.
  • Page 233 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring Filter Rules Table 5-14. Enhanced Router Filter Rule Configuration Window Field Descriptions (Continued) Field Name Field Values Description Destination Port Default: None Indicates the type of port numbers used for this Type filter rule.
  • Page 234 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring Static IP Routes Table 5-14. Enhanced Router Filter Rule Configuration Window Field Descriptions (Continued) Field Name Field Values Description Pass Flag Default: Drop Indicates the action to be taken on this module for each filter rule (drop or pass).

  • Page 235: Enhanced Router Module Route Table Window

    Chapter 5 Configuring VPNs Using the AQueView EMS Configuring Static IP Routes The Enhanced Router Module Route Table window appears (see Figure 5-28). Figure 5-28. Enhanced Router Module Route Table Window The buttons on this page have the following functions: Button Function Find...
  • Page 236 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring Static IP Routes 2 Right-click within the window and select Create. The Enhanced Router Module IP Route Configuration window appears (see Figure 5-29). Figure 5-29. Enhanced Router IP Route Configuration Window The buttons on this window have the following functions: Button Function...

  • Page 237: Add Erm Ip Route Table Entry Window Field Descriptions

    Chapter 5 Configuring VPNs Using the AQueView EMS Configuring Static IP Routes Table 5-15. ADD ERM IP Route Table Entry Window Field Descriptions Field Name Field Values Description Note: You cannot change any fields on this window for an existing IP static route configura- tion if Local or RIP was previously selected and applied in the Route Protocol field.
  • Page 238 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring Static IP Routes Table 5-15. ADD ERM IP Route Table Entry Window Field Descriptions (Continued) Field Name Field Values Description Route Protocol Default: Displays the routing mechanism by which this route was learned. Range: N/A Note: You cannot change this IP route configura- Format: Predefined...
  • Page 239 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring ARP Deleting Static IP Routes Once a static IP route is created, it will remain present until it is deleted. Static IP routes that were created using dynamic routing protocols, such as RIP, will be removed per the appropriate RFC specification.
  • Page 240 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring ARP The Enhanced Router ARP Table window appears (see Figure 5-30). Figure 5-31. Enhanced Router ARP Table Window The buttons on this window have the following functions: Button Function Displayed on the ADD Enhanced Router Module IP Route Table Entry window when creating an IP interface.
  • Page 241 Chapter 5 Configuring VPNs Using the AQueView EMS Configuring RADIUS Server Parameters Table 5-16. Enhanced Router ARP Configuration Window Field Descriptions Field Name Field Value Description [Slot: ] Default: N/A Displays the slot number where the Enhanced Router module is installed in the PSAX chassis. Range: Varies depending on chassis type...

  • Page 242: Obtaining Module Status Information

    Chapter 5 Configuring VPNs Using the AQueView EMS Obtaining Module Status Information Obtaining Module Status Information This section describes how to obtain hardware operating status data about a module. You can quickly obtain status information about ports, interfaces, and connection on the PSAX devices using the PSAX system EMS. All of this information can be obtained from the Front Panel tab or the Device Tree.

  • Page 243: Obtaining Port Configuration Data

    Chapter 5 Configuring VPNs Using the AQueView EMS Obtaining Module Status Information Table 5-17. LED Status Indicator Descriptions LED Name on Indicator Description Faceplate FAIL Module Status Indi- A red light at the top of a module indicates the cators complete failure of a module.

  • Page 244: Port Status Data

    Chapter 5 Configuring VPNs Using the AQueView EMS Obtaining Module Status Information FAIL ACTIVE UNSTR DS3/E3 A port changes color to indicate its status. Figure 5-33. Port Status Data ® PSAX Enhanced Router Module User Guide, Issue 1 Release 9.1.0 PacketStar 5-60 255-700-614...

  • Page 245: Ghosted Modules

    Chapter 5 Configuring VPNs Using the AQueView EMS Obtaining Module Status Information Module Indicator Name of PSAX Device Name of PSAX Device and Module Name Operational Status Port Indicators Figure 5-34. Device Tree Status Indicators Table 5-18. Port Status Data Color Description Dark Blue...

  • Page 246: Saving The Configuration

    Chapter 5 Configuring VPNs Using the AQueView EMS Saving the Configuration To correct this condition, you must do one of the following as described in Table 5-19. Table 5-19. Removing Ghosted Modules from the Front Panel If a module... and you want to... then do this ...
  • Page 247 Provisioning Connections Using the AQueView EMS Overview of This Chapter This chapter describes how to set up connections between the Enhanced Router module and I/O modules that support ATM, frame relay, HDLC, in- band management, or bridge groups. It also includes instructions to configure local NSAP addresses and PPP templates, and viewing and deleting connec- tions.

  • Page 248: Accessing The Enhanced Router Connection Table

    Chapter 6 Provisioning Connections Using the AQueView EMS Adding/Viewing Connections on an IP Interface The CoS fields on the various connection windows are egress-related param- eters. For example, suppose that a packet arrives at the ingress interface 1. The routing and classification procedure determines that the packet is des- tined for IP interface 4 and has an egress CoS value of 5 (see Figure 6-1).

  • Page 249: Connection Table Page

    Chapter 6 Provisioning Connections Using the AQueView EMS Adding/Viewing Connections on an IP Interface The Enhanced Router Connection Table page is displayed (see Figure 6-2). Figure 6-2. Connection Table Page The buttons on the pages in this chapter have the following functions: Button Function Displayed on the ADD Enhanced Router...

  • Page 250: Adding Connections To An Ip Interface

    Chapter 6 Provisioning Connections Using the AQueView EMS Adding Connections to an IP Interface Button Function PPP Status Displayed on the Enhanced Router PPP Link Configuration window. Displays the Enhanced Router PPP Status Information window. Refresh Displayed on the Enhanced Router PPP Status Information window.
  • Page 251 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ATM Connections Begin 1 For the I/O module port that is configured for ATM, be sure that on the ATM UNI/PNNI Interface Configuration window, the port of the I/O module is configured according to the ATM UNI field description table. 2 Click Apply.

  • Page 252: Enhanced Router Connection Table Entry Window (Atm)

    Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ATM Connections The Enhanced Router ATM Connection Configuration window is dis- played (see Figure 6-3). Figure 6-3. Enhanced Router Connection Table Entry Window (ATM) 2 Enter the values for the fields on this window according to the informa- tion provided in Table 6-1.
  • Page 253 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ATM Connections Table 6-1. ADD Enhanced Router Connection Configuration Entry Window Field Descriptions (ATM) Field Name Field Values Description Connection ID Default: N/A Indicates the connection identifier within the current VPN. Range: 1–6 Format: Numeric IP N/w Interface...
  • Page 254 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ATM Connections Table 6-1. ADD Enhanced Router Connection Configuration Entry Window Field Descriptions (ATM) Field Name Field Values Description Conn. Description Default: N/A Displays a text string containing information about the connection. Range: 0–255 Format: Alphanu- meric...
  • Page 255 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ATM Connections Table 6-1. ADD Enhanced Router Connection Configuration Entry Window Field Descriptions (ATM) Field Name Field Values Description Service Type Default: UBR Indicates the quality of service (QoS) type used on this connection.
  • Page 256 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ATM Connections Table 6-1. ADD Enhanced Router Connection Configuration Entry Window Field Descriptions (ATM) Field Name Field Values Description Channel Default: N/A Indicates the channel number of the module con- figured with an ATM interface. Range: Varies depending on module type...
  • Page 257 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ATM Connections Table 6-1. ADD Enhanced Router Connection Configuration Entry Window Field Descriptions (ATM) Field Name Field Values Description OAM Status Default: Unsupp Indicates whether OAM is in use on this connec- tion, and how traffic is processed on this connec- Range: N/A tion.
  • Page 258 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ATM Connections Table 6-1. ADD Enhanced Router Connection Configuration Entry Window Field Descriptions (ATM) Field Name Field Values Description Confirm Type Default: Best-effort Indicates the type of traffic control option used for ATM cells.

  • Page 259: Provisioning Frame Relay Connections

    Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning Frame Relay Connections Table 6-1. ADD Enhanced Router Connection Configuration Entry Window Field Descriptions (ATM) Field Name Field Values Description Bulk Stats Flag Default: Disabled Indicates whether the bulk statistics feature is supported on this connection.
  • Page 260 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning Frame Relay Connections Begin 1 For the I/O module port that is configured for frame relay, be sure that on the Frame Relay Interface Configuration window, the port of the I/O module port must have the value Frf8 in the Interworking Type field.

  • Page 261: Enhanced Router Connection Table Entry Window (Frame Relay)

    Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning Frame Relay Connections The Enhanced Router Frame Relay Connection Configuration window is displayed (see Figure 6-4). Figure 6-4. Enhanced Router Connection Table Entry Window (Frame Relay) 2 Enter the values for the fields on this window according to the informa- tion provided in Table 6-2.
  • Page 262 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning Frame Relay Connections Table 6-2. Enhanced Router Frame Relay Connection Configuration Entry Window Field Descriptions (Continued) Field Name Field Values Description Connection ID Default: N/A Indicates the connection identifier within the current VPN.
  • Page 263 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning Frame Relay Connections Table 6-2. Enhanced Router Frame Relay Connection Configuration Entry Window Field Descriptions (Continued) Field Name Field Values Description Service Type Default: UBR Indicates the quality of service (QoS) type used on this connection.
  • Page 264 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning Frame Relay Connections Table 6-2. Enhanced Router Frame Relay Connection Configuration Entry Window Field Descriptions (Continued) Field Name Field Values Description Conn. Description Default: N/A Displays a text string containing information about the connection.
  • Page 265 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning Frame Relay Connections Table 6-2. Enhanced Router Frame Relay Connection Configuration Entry Window Field Descriptions (Continued) Field Name Field Values Description OperStatus Default: OutofSer- Displays the operational status of the connection vice you are configuring.

  • Page 266: Provisioning Bridge Connections

    Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning Bridge Connections Table 6-2. Enhanced Router Frame Relay Connection Configuration Entry Window Field Descriptions (Continued) Field Name Field Values Description Time Interval Default: N/A Displays the time interval over which CIR, Bc, and Be are measured in the A-to-B direction.
  • Page 267 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning Bridge Connections Begin On the Ethernet bridge side of the connection, you must perform the follow- ing tasks in order: 1 Configure the physical port (that you want to connect to the Enhanced ®...

  • Page 268: Provisioning Bridge Connections On The Enhanced Router Module

    Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning Bridge Connections Provisioning Bridge Connections on the Enhanced Router Module Before configuring a bridge connection, be sure to leave the Intf Neighbor IpAddr field on the Enhanced Router Interface Configuration window blank. Perform the following procedure to create a bridge connection.

  • Page 269: Enhanced Router Bridge Connection Configuration Entry Window Field Descriptions

    Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning Bridge Connections Table 6-3. Enhanced Router Bridge Connection Configuration Entry Window Field Descriptions Field Name Field Values Description Slot Default: N/A Displays the slot number where the Enhanced Router module is installed in the PSAX chassis. Range: Chassis dependent Format: Numeric...
  • Page 270 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning Bridge Connections Table 6-3. Enhanced Router Bridge Connection Configuration Entry Window Field Descriptions Field Name Field Values Description Service Type Default: UBR Indicates the quality of service (QoS) type used on this connection. Range: N/A Note: There cannot be more than one connection Format: Predefined...
  • Page 271 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning Bridge Connections Table 6-3. Enhanced Router Bridge Connection Configuration Entry Window Field Descriptions Field Name Field Values Description Conn. Description Default: N/A Displays a text string containing information about the connection. Range: 0–255 Format: Alphanu- meric...

  • Page 272: Provisioning Hdlc Connections

    Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning HDLC Connections Table 6-3. Enhanced Router Bridge Connection Configuration Entry Window Field Descriptions Field Name Field Values Description AdminStatus Default: OutOfSer- Indicates whether the connection is attempting to vice make calls or receive calls. Range: N/A Format: Predefined OutOfService...
  • Page 273 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning HDLC Connections Begin 1 On the I/O module, select HdlcPassThrough in the Interface Type field. 2 Click Apply. 3 Configure the interface. 4 Bring the interface into service. Enhanced Router Configuration Begin 1 Create a VPN.

  • Page 274: Enhanced Router Connection Table Entry Window (Hdlc)

    Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning HDLC Connections The Enhanced Router HDLC Connection Configuration window is dis- played (see Figure 6-6). Figure 6-6. Enhanced Router Connection Table Entry Window (HDLC) 2 Enter the values for the fields on this window according to the informa- tion provided in Table 6-4.
  • Page 275 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning HDLC Connections Table 6-4. Enhanced Router HDLC Connection Configuration Entry Window Field Descriptions Field Name Field Values Description IP N/w Interface Default: N/A Displays the IP network interface address that Addr you specified on the Enhanced Router IP Inter- Range: N/A face Configuration window.
  • Page 276 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning HDLC Connections Table 6-4. Enhanced Router HDLC Connection Configuration Entry Window Field Descriptions Field Name Field Values Description LLC Encapsulation Default: LlcSnap Indicates the encapsulation technique used in convert an IP packet to an ATM cell. Range: N/A Format: Predefined Indicates that VC multiplexing is used to convert...
  • Page 277 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning HDLC Connections Table 6-4. Enhanced Router HDLC Connection Configuration Entry Window Field Descriptions Field Name Field Values Description Slot Default: N/A Indicates the slot number of the I/O module con- figured with a HDLC Passthrough interface. Range: Varies depending on chassis type...

  • Page 278: Provisioning In-Band Management Connections

    Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning In-band Management Connections Provisioning In-band Management Connections The in-band connection allows a connection between the Enhanced Router module and the CPU module’s IP address. If you are creating an in-band connection, adding a connection requires the specification and location of the corresponding IP interface.

  • Page 279: Provisioning In-Band Management Connections On The Enhanced Router Module

    Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning In-band Management Connections Provisioning In-band Management Connections on the Enhanced Router Module Perform the following procedure to create an in-band connection. Adding In-band Management connections Begin 1 On the VPN Connection Table window, right-click on a blank area and select Add IBM Connection.
  • Page 280 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning In-band Management Connections Table 6-5. Enhanced Router In-band Management Connection Configuration Entry Window Field Descriptions Field Name Field Values Description Slot Default: N/A Displays the slot number where the Enhanced Router module is installed in the PSAX chassis. Range: Chassis dependent Format: Numeric...
  • Page 281 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning In-band Management Connections Table 6-5. Enhanced Router In-band Management Connection Configuration Entry Window Field Descriptions (Continued) Field Name Field Values Description Service Type Default: UBR Indicates the quality of service (QoS) type used on this connection.
  • Page 282 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning In-band Management Connections Table 6-5. Enhanced Router In-band Management Connection Configuration Entry Window Field Descriptions (Continued) Field Name Field Values Description Conn. Description Default: N/A Displays a text string containing information about the connection.
  • Page 283 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning In-band Management Connections Table 6-5. Enhanced Router In-band Management Connection Configuration Entry Window Field Descriptions (Continued) Field Name Field Values Description AdminStatus Default: OutOfSer- Indicates whether the connection is attempting to vice make calls or receive calls.
  • Page 284 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ERM-to-ATM VCC SPVC Connections Provisioning ERM-to-ATM VCC SPVC Connections Configuring Local NSAP Addresses Before you can set up a local NSAP address, you must first configure the ports and channels of the modules you want to use as described in the appro- ®...

  • Page 285: Spvc Nsap Address Page

    Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ERM-to-ATM VCC SPVC Connections Figure 6-9. SPVC NSAP Address Page You can enter and update SPVC NSAP address information by using the but- tons on this page: Button Function Find Searches the table and displays a matching text string entered in the Show table entry containing: field.
  • Page 286 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ERM-to-ATM VCC SPVC Connections Button Function Calculate Navis NSAP Automatically calculates the local NSAP Address address, and populates the NSAP address in the Local NSAP Address (Hex) field using the Navis algorithm for the slot, port, and channel selected in the fields on the bottom right panel.

  • Page 287: Adding Erm-To-Atm Vcc Spvc Connections

    Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ERM-to-ATM VCC SPVC Connections Table 6-6. SPVC Address Table Window Field DescriptionsSPVC NSAP Address Table Window Field Descriptions Field Name Field Values Description Port Default: N/A Displays the port on the I/O module that has a configured ATM IISP (User or Network) or ATM Range: Module UNI 3.0 or 3.1 interface.

  • Page 288: Create Connection Window

    Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ERM-to-ATM VCC SPVC Connections The Create Connection window appears (see Figure 6-10). Figure 6-10. Create Connection Window 3 On the Side A panel, select the appropriate slot containing an Enhanced Router module. 4 On the Side B panel, select SPVC.

  • Page 289: Create Erm-To-Atm_Spvc Connection Window (Top)

    Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ERM-to-ATM VCC SPVC Connections Figure 6-11. Create ERM-to-ATM_SPVC Connection Window (Top) Figure 6-12. Create ERM-to-ATM_SPVC Connection Window (Bottom) ® PSAX Enhanced Router Module User Guide, Issue 1 Release 9.1.0 PacketStar 255-700-614 6-43...
  • Page 290 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ERM-to-ATM VCC SPVC Connections The buttons on this window have the following functions: Button Function Retrieve from If you have previously established an NSAP address database, NSAP Database click this button to retrieve an entry from this list to populate the Remote NSAP Address (Hex) field.
  • Page 291 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ERM-to-ATM VCC SPVC Connections Table 6-7. ERM-to-ATM VCC SPVC Connection Window Field Descriptions (Continued) Field Name Field Values Description ERM Connection Configuration Panel MAC Address Default: 00:00:00:00:00 Displays the MAC address for this connection. Note: This field is configurable when the Ethernet Range: N/A field value is selected in the Traffic Type field, and...
  • Page 292 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ERM-to-ATM VCC SPVC Connections Table 6-7. ERM-to-ATM VCC SPVC Connection Window Field Descriptions (Continued) Field Name Field Values Description Traffic Type Default: Atm Indicates the type of traffic running on this connec- tion.
  • Page 293 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ERM-to-ATM VCC SPVC Connections Table 6-7. ERM-to-ATM VCC SPVC Connection Window Field Descriptions (Continued) Field Name Field Values Description Peak Cell Rate (cps) Default: 1 Indicates peak cell rate. The maximum allowed cell transmission rate (in cells per second), which Range: 1–(2 -1) (the-...
  • Page 294 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ERM-to-ATM VCC SPVC Connections Table 6-7. ERM-to-ATM VCC SPVC Connection Window Field Descriptions (Continued) Field Name Field Values Description Max Burst Size Default: 1 Indicates the maximum burst size. The maximum (cells) number of cells that can be received at the peak cell Range: 0–65535...
  • Page 295 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ERM-to-ATM VCC SPVC Connections Table 6-7. ERM-to-ATM VCC SPVC Connection Window Field Descriptions (Continued) Field Name Field Values Description Traffic Parameters B to A Panel Peak Cell Rate (cps) Default: 1 Indicates peak cell rate.
  • Page 296 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ERM-to-ATM VCC SPVC Connections Table 6-7. ERM-to-ATM VCC SPVC Connection Window Field Descriptions (Continued) Field Name Field Values Description Max Burst Size Default: 1 Indicates the maximum burst size. The maximum (cells) number of cells that can be received at the peak cell Range: 0–65535...
  • Page 297 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ERM-to-ATM VCC SPVC Connections Table 6-7. ERM-to-ATM VCC SPVC Connection Window Field Descriptions (Continued) Field Name Field Values Description Remote Inter Connection Configuration Panel Remote Inter Con- Default: ErmToAtm Indicates the interface that acts as the remote SPVC nection endpoint on this connection.
  • Page 298 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ERM-to-ATM VCC SPVC Connections Table 6-7. ERM-to-ATM VCC SPVC Connection Window Field Descriptions (Continued) Field Name Field Values Description Remote IP Intf Default: 1 Specifies the IP interface and subchannel (connec- tion) of the remote endpoint of this connection.
  • Page 299 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ERM-to-ATM VCC SPVC Connections Table 6-7. ERM-to-ATM VCC SPVC Connection Window Field Descriptions (Continued) Field Name Field Values Description Admin Status Default: OutOfSer- Indicates whether the connection is attempting to vice make calls or receive calls.
  • Page 300 Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ERM-to-ATM VCC SPVC Connections Table 6-7. ERM-to-ATM VCC SPVC Connection Window Field Descriptions (Continued) Field Name Field Values Description Retry Failure Count Default: N/A Displays how many times the call retry failed since the last successful call setup.

  • Page 301: Display Connection:erm-To-Atm_Spvc (Top Of Primary Page)

    Chapter 6 Provisioning Connections Using the AQueView EMS Provisioning ERM-to-ATM VCC SPVC Connections Figure 6-13. Display Connection:ERM-to-ATM_SPVC (Top of Primary Page) Figure 6-14. Display Connection: ERM-to-ATM SPVC (Bottom of Primary Page) ® PSAX Enhanced Router Module User Guide, Issue 1 Release 9.1.0 PacketStar 255-700-614...
  • Page 302 Chapter 6 Provisioning Connections Using the AQueView EMS Configuring PPP Templates The buttons at the bottom of the window have the following functions: Button Function Retrieve from If you have previously established an NSAP address database, NSAP database click this button to retrieve an entry from this list to populate the Remote NSAP Address (Hex) field.

  • Page 303: Enhanced Router Ppp Config Template Table Page

    Chapter 6 Provisioning Connections Using the AQueView EMS Configuring PPP Templates The Enhanced Router PPP Config Template Table page appears (see Figure 6-15). Figure 6-15. Enhanced Router PPP Config Template Table Page 2 Right-click within the window and select Create. The Enhanced Router PPP Config Template Table Entry window appears (see Figure 6-16).

  • Page 304: Enhanced Router Ppp Config Template Configuration Window Field Descriptions

    Chapter 6 Provisioning Connections Using the AQueView EMS Configuring PPP Templates Button Function Delete Displayed on the VIEW Enhanced Router PPP Config Template Table Entry and UPDATE Enhanced Router PPP Config Template Table Entry windows. Removes the entry from the Enhanced Router PPP Config Template Table.
  • Page 305 Chapter 6 Provisioning Connections Using the AQueView EMS Configuring PPP Templates Table 6-8. Enhanced Router PPP Config Template Configuration Window Field Descriptions (Continued) Field Name Field Values Description Restart Timer Default: 3 Indicates the time in seconds between transmis- sions of Configure-Request and Terminate- Range: 1–120 Request packets.
  • Page 306 Chapter 6 Provisioning Connections Using the AQueView EMS Configuring Point-to-Point Protocol Configuring Point-to-Point Protocol To establish communications over a point-to-point link, each end of the PPP link must first send LCP packets to configure the data link during Link Estab- lishment phase.

  • Page 307: Enhanced Router Ppp Link Configuration Window Field Descriptions

    Chapter 6 Provisioning Connections Using the AQueView EMS Configuring Point-to-Point Protocol If you want to view PPP statistics, skip step 4 and go to “Viewing PPP Sta- tus” on page 6-63. Otherwise, go to step 4. 4 Click Close. Table 6-9. Enhanced Router PPP Link Configuration Window Field Descriptions Field Name Field Values Description...
  • Page 308 Chapter 6 Provisioning Connections Using the AQueView EMS Configuring Point-to-Point Protocol Table 6-9. Enhanced Router PPP Link Configuration Window Field Descriptions (Continued) Field Name Field Values Description Passive Mode Default: Active Indicates whether Link Control Protocol (LCP) initiates negotiation on this PPP link. Range: N/A Format: Predefined Active...
  • Page 309 Chapter 6 Provisioning Connections Using the AQueView EMS Configuring Point-to-Point Protocol Table 6-9. Enhanced Router PPP Link Configuration Window Field Descriptions (Continued) Field Name Field Values Description Secondary Protocol Default: None Indicates the security protocol type that is applied to this interface if the primary security protocol is Range: N/A not supported by the peer.
  • Page 310 Chapter 6 Provisioning Connections Using the AQueView EMS Configuring Point-to-Point Protocol The Enhanced Router PPP Link Status Information window appears (see Figure 6-18). Figure 6-18. Enhanced Router PPP Status Window The display-only fields on this window are described in Table 6-10. Table 6-10.
  • Page 311 Chapter 6 Provisioning Connections Using the AQueView EMS Configuring Point-to-Point Protocol Table 6-10. Enhanced Router PPP Status Window Field Descriptions (Continued) Field Name Field Values Description Authentication Pro- Default: None Displays the security protocol type that is applied tocol for authentication on this interface. Range: N/A Format: Predefined Chap...
  • Page 312 Chapter 6 Provisioning Connections Using the AQueView EMS Configuring Point-to-Point Protocol Table 6-10. Enhanced Router PPP Status Window Field Descriptions (Continued) Field Name Field Values Description Closed In the Closed state, the link is available (Up), but no Open has occurred. The Restart timer is not running in the Closed state.Upon reception of Configure-Request packets, a Terminate-Ack is sent.
  • Page 313 Chapter 6 Provisioning Connections Using the AQueView EMS Viewing Connection Statistics Table 6-10. Enhanced Router PPP Status Window Field Descriptions (Continued) Field Name Field Values Description Opened In the Opened state, a Configure-Ack has been both sent and received. The Restart timer is not running.

  • Page 314: Ip N/W Interface Connection Statistics Page

    Chapter 6 Provisioning Connections Using the AQueView EMS Viewing Connection Statistics Command Function Continuous Update Updates the values constantly. Press any key to stop the update. Go Back to Previous Screen Redisplays the Enhanced Router Connec- tion Configuration window for the con- nection you configured.
  • Page 315 Chapter 6 Provisioning Connections Using the AQueView EMS Deleting Connections Deleting Connections Perform the following procedure to delete a connection. Deleting a Connection Begin 1 On the Enhanced Router Interface Configuration window, select the Take Connection Out of Service command. A message appears at the bottom of the window: 2 Select the Delete Connection command.
  • Page 316 Chapter 6 Provisioning Connections Using the AQueView EMS Deleting Connections ® PSAX Enhanced Router Module User Guide, Issue 1 Release 9.1.0 PacketStar 6-70 255-700-614...
  • Page 318 Copyright © 2004 Lucent Technologies All rights reserved. Part Number: 575M0A9101D1...
