Exploded view

Exploded view EH valve with dynamic orifice (no PVFC Spool)

4
EH Electro Proportional Hydraulic Valve In-line Version
17
12
Spare parts list
Spare parts
Valve housing
Main spool
PVE
Plug
Filter
O-ring
O-ring
O-ring
Spring
PR cone
PR spool
Plug
Pilot cone and spring
Adjusting screw
Protection plug
Plug
Screw
Throttle screw
L1026660 • Rev BA • Mar 2014
3
5 6
7
8
6
9
10
11
13
14
15
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
16
5
18
1
16
2
Number per unit Torque setting Nm
1 -
1 -
1 -
1 50 ± 5
2 -
3 -
1 -
1 -
1 -
1 -
1 -
1 15 ± 2
1 -
1 -
1 -
2 15 ± 2
4 8 ± 0.5
1 1 ± 0.1
4
