COT2000 Technical Information
Trouble Shooting Guide
Symptom: Nothing comes out or flow is very slow when tap faucet is opened.
-
Cause:
-
Empty juice Bag in Box. The pumps will shut off when the juice Bag in Box is empty.
-
Connect a new Bag in Box. Be sure to fully engage the plunger on the Quick Connect-
Disconnect (QCD).
- Low CO² pressure. Open the cabinet door and identify the CO² pressure from the
gauge. The unit is designed to operate at 30 psi, and the pressure gauge was set to 30
psi at the time of installation. Check the pressure at the CO² tank. Replace or recharge
if needed. The CO² supply line leading to the cabinet should be between 60-80 psi.
The Quick Connect-Disconnect (QCD) to the juice Bag in Box is not tight. Reconnect
-
the QCD to the Bag in Box. The plunger must be fully depressed.
Pinched hose. Check for a pinched hose between the cabinet and the tap tower.
-
- Symptom: The flow is sputtering when the tap faucet is opened.
- Cause:
Low spirits level. Air in the lines will cause coughing and sputtering at the tap. Check
-
that there is spirits in the reservoir.
The juice Bag in Box is almost empty. Check there is juice remaining in the box.
-
Connect a new box if needed.
The Quick Connect-Disconnect (QCD) to the juice Bag in Box is not tight. Reconnect
-
the QCD to the Bag in Box. The plunger must be fully depressed.
