TROUBLESHOOTING

A Fault status is indicated by a yellow LED and
also by the 4-20 mA output. Refer to Table 9 for
assistance in correcting malfunctions with the
LS2000 Detector.
Fault Condition
Low 24 Volts
Dirty Optics
Calibration Fault
Negative Signal Output
Calibration Line Active
at Start-up
Signal Saturation
EE Error
Other Faults
6.3
Table 9—Troubleshooting Guide
24 Vdc operating voltage is out of range. Verify proper wiring to the detector
and correct voltage output from the power source. Power supply faults are
self-clearing when the condition is corrected. If the fault does not clear,
consult the factory.
Perform cleaning procedure, then recalibrate as required. (Refer to
"Maintenance" for details.)
If the calibration process is allowed to time-out, the fault is set and can only be
reset with a successful calibration.
This fault is indicated when the signal output drops below –0.5 LFL-m.
Normally detection capability is not compromised in this condition.
The device was probably zero calibrated with background gas present.
If the condition persists, purge with clean air and repeat the zero calibration.
Ensure that the heaters are on and the windows are not fogged.
The only way to clear this fault is to correct the wiring and reapply power.
Be sure that the calibration line is not shorted and that the calibration switch is
open. If the fault does not clear, consult the factory.
Add aperture to the transmitter module or adjust lamp voltage if needed.
Return unit to the factory.
Consult the factory.
