Instructions
95-8470-05
Eagle Quantum
™
Fire and Gas Detection/Releasing System
Detector Electronics Corporation
6901 West 110th Street • Minneapolis, Minnesota 55438 USA
10/01
95-8470-05
Tel: 952.941.5665 or 800.765.3473 • Fax: 952.829.8750
