- Page 1 CCS-561W Digital Commercial Wireless Camera System INSTALLATION & OPERATING MANUAL...
-
Page 2: Table Of Contents
Table of Contents CONTENTS PAGE Table of Contents Product Overview Features & Specifications Required Tool List Supplied Parts List Wiring Diagram Camera Installation LCD Monitor Installation System Pairing System Setup Trouble Shooting Product Overview The CCS561W represents a combination of the highest quality camera and LCD components, combined with the most advance wireless communication technology available. -
Page 3: Features & Specifications
Features & Specifications · Wireless Range over 200m · Zero static guarantee. · 100% Waterproof Camera (IP68 Tested) · Camera with inbuilt Microphone · Digital High resolution LCD monitor. · Three Year Warranty · Sony SuperHAD CCD image sensor. · IR night vision Capable ·... -
Page 4: Required Tool List
Required Tool List Screwdrivers Marker pencil Electric Drill Plyers Panel Removal Tool Soldering Iron & Solder Voltmeter Safety Glasses Supplied Parts List ✓ Wireless Camera ✓ Wireless LCD Monitor ✓ Camera Power Cable ✓ Monitor Power Cable ✓ Monitor Stand ✓... -
Page 5: Camera Installation
Camera Installation The CAM150W Camera installation is simply a matter of bolting the camera onto the vehicle and supplying reverse power (9v- 28v). The only issue to take into account is mounting location. There are 3 main factors to consider: 1. -
Page 6: System Pairing
System Pairing The purchased set will have been ‘paired’ during the assembly process so the initial operation should be as simply as placing the vehicle into reverse gear. If for any reason the camera/LCD combination needs to be changed then the system will need to paired again. The pairing process is as follows: 1. -
Page 7: System Setup
System Setup Once the rear vision image can be seen, the system will continue to function as a normal wired system. There are a number of adjustments that can be made to the product, Pressing the MENU button scrolls through the settings available including: •... -
Page 8: Trouble Shooting
Trouble Shooting If for any reason the system does not function, the first thing to do is to confirm that both the camera and LCD have power – the LCD screen has a small blue power activation light on the front.
