Gold Note XT-7 Owner's Manual

Full range 3 way speaker
Hide thumbs Also See for XT-7:
Table of Contents

Advertisement

Quick Links

Download this manual
il suono italiano
XT-7
XT-7 full range 3 way speaker
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XT-7 and is the answer not in the manual?

Questions and answers

Related Manuals for Gold Note XT-7

Summary of Contents for Gold Note XT-7

  • Page 1 XT-7 XT-7 full range 3 way speaker OWNER’S MANUAL...

  • Page 2: Important Safety Information

    The power Chord supplied must be used only on this unit. Gold Note does not have responsibility for any improper use of this unit This appliance has a serial number located on the rear panel. Please record the model and serial number and retain them for your records.
  • Page 3 IMPORTANT SAFETY INFORMATION 1 Read these instructions. normally, or has been dropped. 2 Keep these instructions. • Do not expose this apparatus to drips or splashes. • Do not place any objects filled with liquids, such as vases, on 3 Heed all warnings. the apparatus.
  • Page 4 INTRODUCTION XT-7 full range, 3 way speaker with anti-turbu- The unique curved cone in ultra-hardened woven polypropylene allows an excellent internal damping lence rear bass reflex and ribbon tweeter factor while the moving parts are perfectly matched together for a smooth and extended frequency The unique XT curved design is based on a response.
  • Page 5 CROSSOVER For XT-7 we developed a deluxe crossover with state- of-the-art components all exclusively provided by Mundorf and Clarity: the passive Crossover Low-High Dual-Slope cuts at 280Hz & 3000Hz and features a...
  • Page 6 SPECIFICATION and KEY FEATURES SPECIFICATIONS Frequency response: 35 Hz – 30.000 Hz, Dual Slope Sensitivity: 90dB SPL (2.83V/1 m) Nominal impedence: 4 ohm semi-resistive Power handling: 30W – 300W Suggested min. listening distance: 1.5/2.0m Dimensions: 1110 H x 365 W x 525 mm D Weight: net weight 100 Kg (pair), shipping weight 120 Kg FINISHES...
  • Page 7 Unboxing the Speaker and Mounting the Foot Place the Woofer carton box as shown below. Open the Woofer carton box from the top. Gently turn upside down the Woofer carton box as shown in the in the picture. Pay attention to the flaps that must be as shown in fig.
  • Page 8 Unboxing the Speaker and Mounting the Foot Gently remove the carton box: the Woofer carton box should now be upside down. After the bottom protection is removed, you can go to fig. 6 being ready to assemble Take the foot as shown in the picture and use the the foot to the Woofer cabinet.

  • Page 9: Connecting The Speakers

    CONNECTING the SPEAKERS Example Connection n. 1 Standard wiring connection (No Bi-Wiring). The Gold Note speakers are all supplied with standard bridge. Special Exotic Bridge parts of the SIENA BRIDGE ENHANCER line are available on Demand Right Left Speaker Speaker Stereo Power Amplifier OWNER’S MANUAL...
  • Page 10 CONNECTING the SPEAKERS CONNECTING the SPEAKERS Example Connection n. 2 Bi-Wiring Connection Right Left Speaker Speaker Stereo Power Amplifier OWNER’S MANUAL OWNER’S MANUAL page 8 page 9...

  • Page 11: Speaker Positioning

    SPEAKER POSITIONING Identifying the ideal sound/acoustic room to play an audio system well is not that strictly related to the proportional dimensions of the rooms as many audiophiles believe. The sound played through an audio system is just “Energy diffused in a closed environment” that is all absorbed, reflected and dispersed.
  • Page 12 Though the best position of audio racks usually is not in the middle of the speakers, some special racks such like the Gold Note Galileo can beπlaced there because its special all curved shape helps diffracting the sound waves very well. If you are using standard racks placed in the middle of the speakers, it is preferable to have rather small ones which enhance a better sound focus.
  • Page 13 SPEAKER POSITIONING WIDER STEREO SOUND STAGE SPEAKER POSITION (for some instrumental music, symphonic orchestra, etc.) Listening Point WIDE STEREO IMAGE SPEAKER POSITION • The distance of both the speakers to the listening point should be the same (for some instrument music, synfonic orcherstra etc.) •...
  • Page 14 SPEAKER POSITIONING NARROWER STEREO SOUND STAGE SPEAKER POSITION (Eventually for solo instrument music like piano, guitar and voice etc.) Listening Point WIDE STEREO IMAGE SPEAKER POSITION The closer the two speakers stand the better the focus but worse the wide realistic sound (for some instrument music, synfonic orcherstra etc.) stage.
  • Page 15 SPEAKER POSITIONING DISTANCE BETWEEN SPEAKER AND LISTENING POINT ORIENTATION Listening Point The distance between the speakers should be the same of the one to the speakers. If the distance is shorter the speaker must be directed to the Listening point accordingly. Empirical tests are necessary to find the right proportion between wide stereo sound stage focus and crispy details.

  • Page 16: Warranty

    WARRANTY WARRANTY REGISTRATION To validate the warranty it is necessary to register the unit on the Gold Note inter- net web site within 15 days from the purchase on the appropriate area of the web site: http://www.goldnote.it/warranty If the unit is not registered correctly or has been purchased from a different coun- try of the purchaser origin/home the unit will not be covered by any warranty and the eventual registration refused.

  • Page 17: Faq And Troubleshooting

    •Connect them properly. connected to the speaker. •Verify the connectivity and that the music is played through a correct •The amplifier does not play music. source. For spare parts visit the official Gold Note store at: http://www.akamaiaudio.it/ OWNER’S MANUAL page 16...
  • Page 18 NOTES OWNER’S MANUAL page 17...
  • Page 19 NOTES OWNER’S MANUAL page 18...
  • Page 20 il suono italiano Via della Gora, 6 Montespertoli (Florence) Italy 50025 Tel. + 39 0571 675005 Fax. + 39 0571 675013 www.goldnote.it...
